基于浆液-岩体耦合效应的微裂隙岩体注浆理论研究

张连震; 张庆松; 刘人太; 李术才

doi:10.11779/CJGE201811006

基于浆液-岩体耦合效应的微裂隙岩体注浆理论研究 English Version

1. 中国石油大学（华东）储运与建筑工程学院,山东青岛 266580;
2. 山东大学岩土与结构工程研究中心,山东济南 250061

基金项目: 国家重点研发计划（2016YFC0801604）; 山东省自然科学基金项目（ZR2018BEE035）; 中央高校基本科研业务费专项资金资助项目（18CX02003A）

详细信息

作者简介:
张连震(1990- ),男,讲师,主要从事地下工程水灾害治理理论及工程应用方面的研究。E-mail：zhanglianzhen@upc.edu.cn。

中图分类号: TU45
计量
- 文章访问数: 306
- HTML全文浏览量: 24
- PDF下载量: 181
出版历程
- 收稿日期: 2017-07-14
- 发布日期: 2018-11-24

Grouting mechanism in fractured rock considering slurry-rock stress coupling effects

1. College of Pipeline and Civil Engineering, China University of Petroleum, Qingdao 266580, China;
2. Research Center of Geotechnical and Structural Engineering, Shandong University, Jinan 250061, China

摘要

摘要: 在微裂隙岩体注浆工程中,浆液-岩体耦合效应对注浆扩散过程影响显著。基于宾汉流体浆液本构模型并引入两阶段裂隙变形控制方程,建立考虑浆-岩耦合效应的裂隙注浆扩散理论模型。利用质量守恒条件实现浆液扩散锋面追踪与注浆流量分配,通过试错法实现压力场与速度场的迭代求解,建立可完整描述注浆扩散过程的步进式算法。利用所创建的理论模型及步进式算法,分析浆液压力场及裂隙开度的分布规律,并从浆液扩散半径、裂隙变形所吸收的浆液量两个方面分析不同裂隙开度条件下浆-岩耦合效应对裂隙注浆扩散过程的影响程度。研究结果表明：在微裂隙岩体注浆工程中,裂隙宽度越小,浆-岩耦合效应对注浆扩散过程的影响越显著,注浆压力取代裂隙初始隙宽成为影响浆液扩散半径的主控因素。最后结合青岛地铁花岗岩微裂隙注浆工程实例验证了理论模型及步进式算法的正确性。
- 裂隙岩体 /
- 注浆工程 /
- 应力耦合 /
- 步进式算法 /
- 裂隙开度
Abstract: The slurry-rock stress coupling effects have a great influence on the grouting process in fractured rock. In order to describe the dynamic grouting process, a piecewise equation is used to govern the deformation process of rock fissure, and a theoretical model for fissure grouting considering slurry-rock stress coupling effects is established with the slurry being assumed as Bingham liquid. A step-wise calculation method is established, in which the tracing of grouted zone front and distribution of grouting flow rate are realized by using the mass conservation condition. The try out method is adopted to compute the pressure and velocity fields in the grouted zone. The distribution of the pressure field and fracture aperture in the grouted zone and the effect degree of slurry-rock stress coupling on the grouting process with different fracture apertures are analyzed. The results show that in the micro-fracture grouting process, the slurry-rock stress coupling has greater effect on the grouting process when the fracture aperture becomes smaller. At the same time, the grouting pressure, replacing the fracture aperture, becomes the main controlling factor for the grouting radius. By comparing the theoretical results with the measured ones in a grouting project, the validity of the theoretical model and calculation method is verified.
- fractured rock /
- grouting engineering /
- stress coupling /
- step-wise calculation method /
- fracture aperture

HTML全文

参考文献(15)

[1]	GOTHÄLL R, STILLE H. Fracture dilation during grouting[J]. Tunnelling and Underground Space Technology, 2009, 24(3): 126-135.
[2]	阮文军. 基于浆液黏度时变性的岩体裂隙注浆扩散模型[J]. 岩石力学与工程学报, 2005, 24(15): 2709-2714. (RUAN Wen-jun.Spreading model of grouting in rock mass fissures based on time-dependent behavior of viscosity of cement-based grouts[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(15): 2709-2714. (in Chinese))
[3]	李术才, 刘人太, 张庆松, 等. 基于黏度时变性的水泥-玻璃浆液扩散机制研究[J]. 岩石力学与工程学报, 2013, 32(12): 2415-2421. (LI Shu-cai, LIU Ren-tai, ZHANG Qing-song, et al.Research on C-S slurry diffusion mechanism with time-dependent behavior of viscosity[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(12): 2415-2421. (in Chinese))
[4]	GUSTAFSON G, CLAESSON J, FRANSSON Å.Steering parameters for rock grouting[J]. Journal of Applied Mathematics, 2013, 22(5): 1-9.
[5]	RAFI J Y, STILLE H.Basic mechanism of elastic jacking and impact of fracture aperture change on grout spread, transmissivity and penetrability[J]. Tunnelling and Underground Space Technology, 2015, 49: 174-187.
[6]	郑卓, 李术才, 刘人太, 等. 裂隙岩体注浆中的浆液-岩体耦合效应分析[J]. 岩石力学与工程学报, 2015, 34(增刊2): 4054-4062. (ZHENG Zhuo, LI Shu-cai, LIU Ren-tai, et al.Analysis of coupling effect between grout and rock mass during jointed rock grouting[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34(S2): 4054-4062. (in Chinese))
[7]	王媛, 速宝玉. 单裂隙面渗流特性及等效水力隙宽[J].水科学进展, 2002, 13(1): 61-68. (WANG Yuan, SU Bao-yu.Research on the behavior of fluid flow in a single fracture and its equivalent hydraulic aperture[J]. Advances in Water Science, 2002, 13(1): 61-68. (in Chinese))
[8]	GOODMAN R E, TAYLOR R L, BREKKE T L.A model for the mechanics of jointed rock[J]. J Soil Mech and Found, Engrg Div, ASCE, 1968, 99(5): 637-660.
[9]	沈崇棠, 刘鹤年. 非牛顿流体力学及其应用[M]. 北京: 高等教育出版社, 1989: 23-29. (SHEN Chong-shang, LIU He-nian.Non-Newtonian fluid mechanics and its applications[M]. Beijing: Higher Education Press, 1989: 23-29. (in Chinese))
[10]	阮文军. 注浆扩散与浆液若干基本性能研究[J]. 岩土工程学报, 2005, 27(1): 69-73. (RUAN Wen-jun.Research on diffusion of grouting and basic properties of grouts[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(1): 69-73. (in Chinese))
[11]	杨秀竹, 王星华, 雷金山. 宾汉体浆液扩散半径的研究及应用[J]. 水利学报, 2004(6): 75-79. (YANG Xiu-zhu, WANG Xing-hua, LEI Jin-shan.Study on grouting diffusion radius of Bingham fluids[J]. Journal of Hydraulic Engineering, 2004(6): 75-79. (in Chinese))
[12]	JOHN D Anderson.Computational fluid dynamics[M]. New York: McGraw-Hill Education, 1995.
[13]	KIM J S, LEE I M, JANG J H, et al.Groutability of cement-based grout with consideration of viscosity and filtration phenomenon[J]. Int J Numer Anal Meth Geomech, 2009, 33: 1771-1797.
[14]	邹德宁, 雷永平, 梁工英, 等. 用数值计算技术和试错法确定金属材料表面对激光的吸收率[J]. 金属学报, 2001, 37(7): 737-740. (ZOU De-ning, LEI Yong-ping, LIANG Gong-ying, et al.Determination of laser absorptivity of metal by numerical calculation technique and trial-and-error method[J]. Acta Metallurgica Sinica, 2001, 37(7): 737-740. (in Chinese))
[15]	DL/T5331—2005 水电水利工程钻孔压水试验规程[S]. 2005. (DL/T5331—2005 Code of water pressure test in borehole for hydropower and water resources engineering[S]. 2005. (in Chinese))
