考虑孔隙水盐分效应的人工软黏土工程特性与本构模型

张彤炜; 邓永锋; 吴子龙; 刘松玉; 刘垚

doi:10.11779/CJGE201809016

考虑孔隙水盐分效应的人工软黏土工程特性与本构模型 English Version

张彤炜^{1, 2},
邓永锋^2, ,,
吴子龙²,
刘松玉²,
刘垚²

1. 兰州大学土木工程与力学学院地质工程系西部灾害与环境力学教育部重点试验室,甘肃兰州 730000;
2. 东南大学交通学院岩土工程研究所,江苏南京 210096

基金项目: 国家自然科学基金项目（51378117,41572280,41807225,41790443）; 中央高校基本科研业务费专项资金项目（lzujbky-201-8）; 国家重点研发项目（2016YFC0800201）

详细信息

作者简介:
张彤炜(1983- ),男,博士,讲师,主要从事特殊土工程性质的研究工作。E-mail: ztw@lzu.edu.cn。

通讯作者:
邓永锋，E-mail：noden@seu.edu.cn

中图分类号: TU43
计量
- 文章访问数: 311
- HTML全文浏览量: 6
- PDF下载量: 165
出版历程
- 收稿日期: 2017-10-18
- 发布日期: 2018-09-24

Engineering behavior and constitutive model of artificial soft clay considering pore water salinity effect

1. School of Civil Engineering and Mechanics,Department of Geotechnical Engineering, Key Laboratory of Mechanics on Disaster and Environment in Western China, Lanzhou University, Lanzhou 730000, China;
2. Institute of Geotechnical Engineering, Transportation College, Southeast University, Nanjing 210096, China

摘要

摘要: 中国江苏北部连云港地区海相软土蒙脱石族矿物含量相对较高,且在海陆交互环境沉积形成,沉积过程中具有孔隙水盐分较高的特点,但在后沉积过程中由于地表和地下淡水入侵,会使孔隙水盐分发生变化。工程设计一般依据既有地下水环境中土体参数,未能考虑盐分变化后土体参数变化,会造成工程安全系数的冗余度不足,进而导致工程风险。为了解决江苏北部地区基础设施运营中,孔隙水盐分变动环境下软黏土地基长期性状与工程性质变异问题,需要深入了解矿物成分、孔隙水盐分在软黏土物理和力学特性中的作用机制。由于天然软黏土的矿物成分、孔隙水成分差异较大,在黏土矿物盐敏性的研究和当地地下水盐分测试基础上,试验材料采用矿物成分均一的商用高岭土与膨润土组成的人工黏土作为研究对象,配制不同浓度的NaCl溶液作为孔隙水,模拟孔隙水盐分变化。通过液塑限试验、常规固结试验和固结不排水剪切试验,发现对于含蒙脱石矿物的人工黏土,液限w_L、压缩指数C_c和回弹指数C_s随着孔隙水盐分的增加而减小,而内摩擦角随着孔隙水盐分的增加而增加;对于高岭石矿物为主的人工黏土,液限w_L、压缩指数C_c、回弹指数C_s和内摩擦角都基本不随孔隙水盐分的增加而改变。将孔隙水盐分效应采用渗透吸力进行表征,在试验规律、修正剑桥模型和BBM模型认知的基础上,建立了考虑盐分效应的人工软黏土本构模型,并对比了计算结果与试验结果,两者在趋势上较为接近,验证了本构模型的实用性,可为近海岩土工程设计提供参考。
- 人工软黏土 /
- 孔隙水盐分 /
- 矿物成分 /
- 工程特性 /
- 本构模型
Abstract: The soft marine clay, which is deposited under the marine environment in the north plain of Jiangsu Province, is rich of montmorillonite mineral and saline pore water. During the post-sedimentary period, the soil suffers the invasion of the surface and underground freshwater, leading to the alteration and reduction of pore water salinity. Presently, the safety evaluation is generally based on the in-situ soil strength in the current environment. Hence, this non-consideration of the pore water salinity alteration may result in insufficient redundancy and potential risk. To clarify the evolution of the hydro-mechanical behavior of soils due to the alteration of pore water salinity during the operation of the coastal infrastructure, the impact of pore water salinity and clay mineral on the soil behavior is necessary to be investigated. To simplify the mineralogical influence, commercial kaolin and bentonite are selected. The physical and mechanical properties of artificial clay changing with pore water salinities (NaCl solution) are investigated using the Atterberg limits tests, oedometer tests and tri-axial tests. The results show that the liquid limits, compression index C_c and swelling index C_s of the artificial clay containing bentonite decrease with the pore water salinity, and its internal friction angle increases with the pore water salinity. Meanwhile, the liquid limits, compression index C_c, swelling index C_s and consolidated undrained strength of Kaolin are not affected by the pore water salinity. Finally, based on the test results, modified Cambridge model and BBM model, an updated constitutive model considering pore water salinity effect represented by the osmotic suction is proposed, and the

HTML全文

参考文献(20)

[1]	李国刚. 中国近海表层沉积物中黏土矿物的组成、分布及其地质意义[J]. 海洋学报(中文版), 1990, 12(4): 470-479. (LI Guo-gang.Composition and distribution of clay minerals in surface sediments of Chinese offshore areas and their geological significance[J]. Acta Oceanologica Sinica, 1990, 12(4): 470-479. (in Chinese))
[2]	邓永锋, 岳喜兵, 张彤炜, 等. 连云港海相软土在孔隙水盐分溶脱环境下的固结特性[J]. 岩土工程学报, 2015, 37(1): 47-53. (DENG Yong-feng, YUE Xi-bing, ZHANG Tong-wei, et al.Consolidation behaviors of soft marine clay in Lianyungang under desalination environment of pore water[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(1): 47-53. (in Chinese))
[3]	BJERRUM L.Engineering geology of Norwegian normally- consolidated marine clays as related to settlements of buildings[J]. Géotechnique, 1967, 17(2): 83-118.
[4]	GENS A.Soil-environment interactions in geotechnical engineering[J]. Géotechnique, 2010, 60(1): 3-74.
[5]	张彤炜, 邓永锋, 刘松玉, 等. 渗透吸力对重塑黏土的压缩和渗透特性影响的试验研究[J]. 岩土工程学报, 2014, 36(12): 2260-2266. (ZHANG Tong-wei, DENG Yong-feng, LIU Song-yu, et al.Experimental investigation of osmotic suction effect on hydro-mechanical behaviour of remolded clay[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(12): 2260-2266. (in Chinese))
[6]	BURLAND J B.On the compressibility and shear strength of natural clays[J]. Géotechnique, 1990, 3(40): 329-378.
[7]	HONG Z S, BIAN X, CUI Y J, et al.Effect of initial water content on undrained shear behaviour of reconstituted clays[J]. Géotechnique, 2013, 63(6): 441-450.
[8]	SRIDHARAN A, RAO G V.Mechanisms controlling volume change of saturated clays and role effective stress concept[J]. Géotechnique, 1973, 23(3): 359-382.
[9]	SRIDHARAN A, RAO G V.Mechanisms controlling the liquid limit of clays[C]// Proceeding of the Istanbul Conference on Soil Mechanics and Foundation Engineering, 1975: 75-84.
[10]	MITCHELL J K.Fundamentals of soil behavior[M]. New York: Wiley, 1976.
[11]	WITTEVEEN P, FERRARI A, LALOUI L.An experimental and constitutive investigation on the chemo-mechanical behaviour of a clay[J]. Géotechnique, 2013, 63(3): 244-255.
[12]	TRASK P D, CLOSE J E H. Effecte of clay content on strength of soils[C]// Proceedings of Coastal Engineering, 1957.
[13]	WARKENTIN B P, YONG R N.Shear strength of montmorillonite and kaolinite related to interparticle forces[J]. Clays and Clay Minerals, 1962(9): 210-218.
[14]	DIMAIO C, FENELLI G B.Residual strength of kaolin and bentonite: the influence of their constituent pore fluid[J]. Géotechnique, 1994, 44(2): 217-226.
[15]	TIWARI B, AJMERA B.A new correlation relating the shear strength of reconstituted soil to the proportions of clay minerals and plasticity characteristics[J]. Applied Clay Science, 2011, 53(1): 48-57.
[16]	BARBOUR S L, FREDLUND D G.Mechanisms of osmotic flow and volume change in clay soils[J]. Canadian Geotechnical Journal, 1989, 26(4): 551-562.
[17]	LORET B, HUECKEL T, GAJO A.Chemo-mechanical coupling in saturated porous media: elastic-plastic behaviour of homoionic expansive clays[J]. International Journal of Solids and Structures, 2002, 39(10): 2773-2806.
[18]	WOOD D M.Soil behaviour and critical state soil mechanics[M]. London: Cambridge University Press, 1990.
[19]	罗汀, 姚仰平, 侯伟. 土的本构关系[M]. 北京: 人民交通出版社, 2010. (LUO Ting, YAO Yang-ping, HOU Wei.Soil constitutive models[M]. Beijing: China Communications Press, 2010. (in Chinese))
[20]	KENNEY T C.The influence of mineral composition on the residual strength of natural soils[C]// Proceedings of the Oslo Conference on Shear Strength Properties of Natural Soils and Rocks. Oslo, 1967: 123-129.
