砾石土心墙料水力劈裂试验研究

凌华; 王伟; 王芳; 傅华; 韩华强

doi:10.11779/CJGE201808009

砾石土心墙料水力劈裂试验研究 English Version

凌华^{1, 2},
王伟^3, ,,
王芳^{1, 2},
傅华^{1, 2},
韩华强^{1, 2}

1. 南京水利科学研究院岩土工程研究所,江苏南京 210024;
2.水利部土石坝破坏机理与防控技术重点实验室,江苏南京 210029;
3. 绍兴文理学院,浙江绍兴 312000

基金项目: 国家重点研发计划项目（2017YFC0404800）; 国家自然科学基金面上项目（51679149）

详细信息

作者简介:
凌华(1977- ),男,江苏盐城人,博士,高级工程师,主要从事粗粒土力学特性研究工作。E-mail: hling@nhri.cn。

通讯作者:
王伟，E-mail：wellswang@usx.edu.cn

计量
- 文章访问数: 316
- HTML全文浏览量: 5
- PDF下载量: 140
出版历程
- 收稿日期: 2017-07-16
- 发布日期: 2018-08-24

Experimental study on hydraulic fracture of gravelly soil core

LING Hua^{1, 2},
WANG Wei^3, ,,
WANG Fang^{1, 2},
FU Hua^{1, 2},
HAN Hua-qiang^{1, 2}

1. Geotechnical Engineering Department of Nanjing Hydraulic Research Institute, Nanjing 210024, China;
2. Key Laboratory of Earth-Rock Dam Failure Mechanism and Safety Control Techniques, Ministry of Water Resources, Nanjing 210029, China;
3. School of Civil Engineering, Shaoxing University, Shaoxing 312000, China

摘要

摘要: 在改进的三轴仪上开展了两种不同级配砾石土心墙料的水力劈裂试验。根据试验结果得到了以下结论：砾石土心墙料的自身性质与围压是影响劈裂压力的关键性因素,水力劈裂破坏主要表现为击穿破坏;相同试验条件下,随围压、固结比和水压加荷速率的提高,水力劈裂试验的流量降低;对于砾石土心墙料,当粉粒与黏粒含量较高时,由于颗粒间的胶结力更强,相同围压、固结比和加载速率条件下试样的破坏劈裂应力要更高,但不同级配砾石土的劈裂压力随围压的增长幅度变化不大;固结比或轴向应力对砾石土心墙料的劈裂压力影响不大,在文中试验条件下,加荷速率对破坏劈裂压力影响也不大。
- 砾石土 /
- 水力劈裂 /
- 试验研究
Abstract: The hydraulic fracture tests on two kinds of graded gravelly soils are carried out by using the improved triaxial apparatus. For the hydraulic fracture pressures on the gravelly soils, the soil properties and confining pressure are the key influence factors. The hydraulic failure mode of gravelly soils is always shown as breakdown. The flow capacity in the tests decreases with the increase of the confining pressure, consolidation ratio and injection pressure rate. The hydraulic fracture pressure increases with the fine particle content of the gravelly soils because of the self-cohesiveness. However, the effect on the fracture pressure with the increasing confining pressure is similar for different graded gravelly soils. The consolidation ratio or axial stress has the slight effect on the fracture pressures, and so does the hydraulic pressure rate.
- gravelly soil /
- hydraulic fracture /
- experimental study

HTML全文

参考文献(16)

[1]	黄文熙. 对土石坝科研工作的几点看法[J]. 水利水电技术, 1982(4): 23-27. (HUANG Wen-xi.Some comments on research works related to rock-fill dam[J]. Water Resources and Hydropower Engineering, 1982(4): 23-27. (in Chinese))
[2]	SEED H B.The Teton dam failure: a retrospective review[C]// Proc 10^th ICSMFE. 1981: 219-238.
[3]	VAUGHAN P R, KLUTH P P, LEONARD M W, et al.Cracking and erosion of the rolled clay core of Balderhead dam and the remedial works adapted for its repair[C]// Proceedings 10^th ICOLD Congress. Montreal, 1970: 73-93.
[4]	朱俊高, 王俊杰, 张辉. 土石坝心墙水力劈裂机制研究[J]. 岩土力学, 2007, 28(3): 487-492. (ZHU Jun-gao, WANG Jun-jie, ZHANG Hui.Study on mechanism of hydraulic fracturing in core of earth rockfill dam[J]. Rock and Soil Mechanics, 2007, 28(3): 487-492. (in Chinese))
[5]	陈五一, 赵颜辉. 土石坝心墙水力劈裂计算方法研究[J]. 岩石力学与工程学报, 2008, 27(7): 1380-1386. (CHEN Wu-yi, ZHAO Yan-hui.Study of calculation method of hydraulic fracturing for core dam[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(7): 1380-1386. (in Chinese))
[6]	王俊杰, 朱俊高. 堆石坝心墙抗水力劈裂性能研究[J]. 岩石力学与工程学报, 2007, 26(增刊1): 2880-2886. (WANG Jun-jie, ZHU Jun-gao.Investigation on ability of rockfill dam core to resist hydraulic fracturing[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(S1): 2880-2886. (in Chinese))
[7]	NG A K, SMALL J C.A case study of hydraulic fracturing using finite element methods[J]. Canadian Geotechnical Journal, 1999, 36(7): 861-875.
[8]	NOBARI E S, LEE K L, DUNCAN J M.Hydraulic fracturing in zoned earth and rockfill dams[R]. Berkeley: University of California, 1973.
[9]	JAWOSKI W, DUNCAN J M, SEED H B.Laboratory study of hydraulic fracturing[J]. Journal of the Geotechnical Engineering Division, ASCE, 1981, 107(6): 713-732.
[10]	丁金粟, 杨斌. 击实黏性土水力劈裂性能研究[J]. 岩土工程学报, 1987, 9(3): 1-15. (TING Chin-su, YANG Bin.The study of hydraulic fracturing on compacted cohensive soil[J]. Chinese Journal of Geotechnical Engineering, 1987, 9(3): 1-15. (in Chinese))
[11]	张丙印, 李娜, 李全明, 等. 土石坝水力劈裂发生机理及模型试验研究[J]. 岩土工程学报, 2005, 27(11): 1277-1281. (ZHANG Bing-yin, LI Na, LI Quan-ming, et al.Mechanism analysis and model test of hydraulic fracturing in embankment dams[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(11): 1277-1281. (in Chinese))
[12]	袁俊平, 王启贵. 水力劈裂楔劈效应试验研究[J]. 岩土力学, 2016, 36(12): 3360-3364. (YUAN Jun-ping, WANG Qi-gui.An experimental study of wedge splitting effect of hydraulic fracturing[J]. Rock and Soil Mechanics, 2016, 36(12): 3360-3364. (in Chinese))
[13]	曾开华. 土质心墙水力劈裂机理及其影响因素的研究[D].南京: 河海大学, 2001. (ZENG Kai-hua.Factors affecting hydraulic fracturing of high earth core dams[D]. Nanjing: Hohai University, 2001. (in Chinese))
[14]	沈珠江, 易进栋, 左元明. 土坝水力劈裂的离心模型试验及其分析[J]. 水利学报, 1994, 25(9): 67-77. (SHEN Zhu-jiang, YI Jin-dong, ZUO Yuan-ming.Centrifuge model test of hydraulic fracture of earth dam and it’s analysis[J]. Journal of Hydraulic Engineering, 1994, 25(9): 67-77. (in Chinese))
[15]	冯晓莹, 徐泽平. 心墙水力劈裂机理的离心模型试验研究[J]. 水利学报, 2009, 40(10): 1259-1263. (FENG XIAO-ying, XU Ze-ping.Centrifugal model study on mechanism of hydraulic fracturing of clay core-wall in rockfill dams[J]. Journal of Hydraulic Engineering, 2009, 40(10): 1259-1263. (in Chinese))
[16]	刘令瑶, 崔亦昊, 张广文. 宽级配砾石土水力劈裂特性的研究[J]. 岩土工程学报, 1998, 20(3): 10-13. (LIU Ling-yao, CUI Yi-hao, ZHANG Guang-wen.The property of hydraulic fracture of wide grading gravelly soil[J]. Chinese Journal of Geotechnical Engineering, 1998, 20(3): 10-13. (in Chinese))
