Calculation moisture content distribution around injection hole during in-situ leaching process of ion-adsorption rare earth mines
-
摘要: 考虑注液孔内积水产生的压力水头在土体中的传递,建立了积水条件下的一维垂直入渗的基本方程;将实测的饱和导水率等效为孔底一维入渗的饱和导水率,采用积水条件一维垂直入渗的基本方程计算注液孔孔底中心垂向的含水率分布;假设入渗过程中形成的湿润锋簇上的含水率增量相等,根据累积注液量等于湿润体内的水分增加量,确定湿润锋簇中各湿润锋的位置,结合注液孔孔底中心垂向的含水率分布,确定湿润体内含水率分布。在龙南足洞某稀土矿山选择一场地较平整的矿块进行单孔注液试验,在注液孔周布置4个测点,采用FDS-100水分传感器记录测点位置在入渗过程中不同时刻的含水率,与模型的计算值进行比较,结果发现,4个测点的实测值与计算值相关系数基本在0.900以上,模型的计算误差均在10%以下,满足工程误差要求,说明此方法能较为准确的计算出注液孔内水分入渗过程及湿润体内含水率分布。Abstract: Ponding in injection hole will generate pressure head in soil surface. Considering the transfer of the pressure head through the soil, a basic equation for one-dimensional vertical infiltration under ponding is developed. The measured saturated hydraulic conductivity is regarded to be equivalent to that of one-dimensional infiltration, and the distribution rules of moisture content along the vertical direction of the injection hole of the hole bottem is calculated by the basic equation for one-dimensional vertical infiltration under ponding. Assuming that the moisture content increment is equal in each wetting front which is formed during infiltration process, and according to that the cumulative liquid injection is equal to the moisture increment in the wetted region, each wetting front is obtained. Considering with the moisture content distribution along the vertical direction of the injection hole of the hole bottom, the moisture content distribution in the wetted region is determined. A smooth ore block in Zudong rare earth mine in China is chosen to perform single-hole injection tests, and 4 measuring points are arranged around the injection hole. During the infiltration process, the moisture contents at measuring points are recorded by FDS-100 moisture sensors. By comparing the values calculated by the proposed model with the test ones, it is found that the correlation coefficient between the calculated values and the requirements is satisfactory. During the infiltration process, the moisture content distribution in the wetted region is calculated accurately by the established model.
-
[1] 杜 雯. 离子型稀土原地浸矿工艺对环境影响的研究[J]. 有色金属科学与工程, 2001, 15(1): 41-44. (DU Wen. The impact of in-situ leaching on the natural environment of ion-type RE mine[J]. Nonferrous Metals Science and Engineering, 2001, 15(1): 41-44. (in Chinese)) [2] 袁长林. 中国南岭淋积型稀土溶浸采矿正压系统的地质分类与开采技术[J]. 稀土, 2010, 31(2): 75-79. (YUAN Chang-lin. Leaching mining positive pressure system's geological classification and corresponding mining technology of Chinese Nanling illuviation rare earth[J]. Chinese Rare Earths, 2010, 31(2): 75-79. (in Chinese)) [3] 池汝安, 田 君, 罗仙平, 等. 风化壳淋积型稀土矿的基础研究[J]. 有色金属科学与工程, 2012, 3(4): 1-13. (CHI Ru-an, TIAN Jun, LUO Xian-ping, et al. The basic research on the weathered crust elution-deposited rare earth ores[J]. Nonferrous Metals Science and Engineering, 2012, 3(4): 1-13. (in Chinese)) [4] 李永绣. 离子吸附型稀土资源与绿色提取[M]. 北京: 化学工业出版社, 2015. (LI Yong-xiu. Ion adsorption rare earth resources and their green extraction[M]. Beijing: Chemical Industry Press, 2015. (in Chinese)) [5] 池汝安, 王淀佐. 稀土矿物加工[M]. 北京: 科学出版社, 2014. (CHI Ru-an, WANG Ding-zuo. Rare-earth’s mineral processing[M]. Beijing: Science Press, 2014. (in Chinese)) [6] MISHRA S K, TYAGI J V, SINGH V P. Comparison of infiltration models[J]. Hydrological Processes, 2003, 17(13): 2629-2652. [7] GREEN W H, AMPT G A. Studies on soil physics: flow of air and water through soils[J]. Journal of Agricultural Science, 1911, 4(1): 1-24. [8] KALE R V, SAHOO B. Green-ampt infiltration models for varied field conditions: a revisit[J]. Water Resources Management, 2011, 25(14): 3505-3536. [9] CHU X, MARIÑO M A. Determination of ponding condition and infiltration into layered soils under unsteady rainfall[J]. Journal of Hydrology, 2005, 313(3): 195-207 . [10] 张 杰, 韩同春, 豆红强, 等. 探讨考虑气阻作用下分层假定的雨水入渗计算分析模型[J]. 岩土工程学报, 2013, 35(12): 2219-2225. (ZHANG Jie, HAN Tong-chun, DOU Hong-qiang, et al. Analysis model for rainwater infiltration considering gas resistance under stratified assumption [J]. Chinese Journal of Geotechnical Engineering, 2013, 35(12): 2219-2225. (in Chinese)) [11] CHU S T. Green‐ampt analysis of wetting patterns for surface emitters[J]. Journal of Irrigation & Drainage Engineering, 1994, 120(2): 414-421. [12] SEPASKHAH A R, CHITSAZ H. Validating the green-ampt analysis of wetted radius and depth in trickle irrigation[J]. Biosystems Engineering, 2004, 89(2): 231-236. [13] 张培文, 刘德富, 黄达海, 等. 饱和-非饱和非稳定渗流的数值模拟[J]. 岩土力学, 2003, 24(6): 927-930. (ZHANG Pei-wen, LIU De-fu, HUANG Da-hai, et al. Saturated-unsaturated unsteady seepage flow numerical simulation[J]. Rock and Soil Mechanics, 2003, 24(6): 927-930. (in Chinese)) [14] 付建新, 宋卫东, 杜建华. 考虑二维降雨入渗的非饱和土边坡瞬态体积含水率分析[J]. 工程科学学报, 2015, 37(4): 407-413. (FU Jian-xin, SONG Wei-dong, DU Jian-hua. Transient volume water content analysis of unsaturated soil slopes considering two-dimensional rainfall infiltration[J]. Chinese Journal of Engineering, 2015, 37(4): 407-413. (in Chinese)) [15] 雷志栋, 杨诗秀, 谢森传. 土壤水动力学[M]. 北京: 清华大学出版社, 1988. (LEI Zhi-dong, YANG Shi-xiu, XIE Seng-chuan. Soil water dynamics[M]. Beijing: Tsinghua University Press, 1988. (in Chinese)) [16] VAN GENUCHTEN M T. A closed-form equation for predicting the hydraulic conductivity of unsaturated soils[J]. Soil Science Society of America Journal, 1980, 44(5): 892-898. [17] NING L, WILLIAM J L. 非饱和土力学[M]. 北京: 高等教育出版社, 2012. (NING L, WILLIAM J L. Unsaturated soil mechanics[M]. Beijing: Higher Education Press, 2012. (in Chinese)) [18] 赵伟霞, 张振华, 蔡焕杰, 等. 恒定水头井入渗Green-Ampt模型的改进与验证[J]. 水利学报, 2010, 41(4): 464-470. (ZHAO Wei-xia, ZHANG Zhen-hua, CAI Huan-jie, et al. Improvement and verification of the Green-Ampt model for constant-head well permeameter[J]. Journal of Hydraulic Engineering, 2010, 41(4): 464-470. (in Chinese)) -
