粗粒土渗透变形特性的细观数值试验研究

蒋中明; 袁涛; 刘德谦; 李小凡

doi:10.11779/CJGE201804020

粗粒土渗透变形特性的细观数值试验研究 English Version

1. 长沙理工大学水利工程学院,湖南长沙 410004;
2. 水沙科学与水灾害防治湖南省重点实验室,湖南长沙410004;
3. 湖南平江抽水蓄能有限公司,湖南平江410400;

基金项目: 国家自然科学基金项目（51778070）; 水能资源利用关键技术湖南省重点实验室开放研究基金项目（2013001）

详细信息

作者简介:
蒋中明(1969- ),男,博士后,教授,主要从事岩土工程及水工结构工程方面研究工作。E-mail：zzmmjiang@163.com。

中图分类号: TU443
计量
- 文章访问数: 361
- HTML全文浏览量: 2
- PDF下载量: 305
出版历程
- 收稿日期: 2016-12-27
- 发布日期: 2018-04-24

Mesoscopic numerical tests on seepage failure characteristics of coarse grained soils

1. School of Hydraulic Engineering, Changsha University of Science & Technology, Changsha 410004, China;
2. Key Laboratory of Water-Sediment Sciences and Water Disaster Prevention of Hunan Province, Changsha 410004, China;
3. Hunan Pingjiang Pumped Storage Co., Ltd., Pingjiang 410400, China;

摘要

摘要: 为深入探究渗透变形对粗粒土渗透特性的影响,基于室内粗粒土渗透变形物理试验成果分析,利用颗粒流软件PFC3D对粗粒土的渗透性演化全过程进行细观数值仿真试验。数值试验研究成果表明：随着试验水头升高,试件中的细小颗粒从渗流“上游区”向“下游区”逐渐迁移、汇聚,形成渗透挤密区;渗透挤密现象的产生导致试件整体渗透系数减小;随着试验水头持续升高,渗透挤密区中的细颗粒在不断增加的渗透力作用下随水流被陆续带出,渗透系数逐渐增大。颗粒迁移导致原有孔隙增大,土骨架结构发生变化,进而导致粗粒土渗透性越来越大,最终形成渗透变形现象。细观数值试验方法可以较好地再现粗粒土的渗透变形过程。
- 粗粒土 /
- 细观数值试验 /
- 渗透变形 /
- 渗透性演化
Abstract: To deeply explore the influences of seepage failure on permeability feature of coarse grained soils, based on the analysis of indoor experiment results of seepage failure tests on coarse grained soil samples, the software named PFC^3D is employed to simulate the whole process of seepage failure with similar test situation. The research results show that the fine particles in the samples migrate from“upstream” to “downstream” location with the increment of water head. The fine particles are gathered at the downstream location of the seepage path in the test samples and the compaction area is formed due to seepage. The phenomenon of seepage compaction induces the decrease of permeability of the test samples. Under the action of the increasing water head, the fine particles in the compaction area migrate out of the samples with seepage water. The coefficient of permeability also increases gradually. The porosity of the test samples becomes large due to the loss of the fine particles. The skeleton structure of the soil test samples is also changed. This is the reason for the increase of permeability of the coarse grained soils due to seepage. When a larger mount of the particles are brought out of the soil samples, the phenomenon of seepage failure is then formed. It is also indicated that the mesoscopic numerical test method can recreate the process of seepage failure reasonably.
- coarse grain soil /
- mesoscopic numerical test /
- seepage failure /
- seepage evolution

HTML全文

参考文献(15)

[1]	刘杰. 土石坝渗流控制理论基础及工程经验教训[M]. 北京: 中国水利水电出版社, 2005. (LIU Jie.Theory and engineering experience of seepage controlling for rock and soil dam[M]. Beijing: China WaterPower Press, 2005. (in Chinese))
[2]	毛昶熙, 段祥宝, 蔡金傍, 等. 堤基渗流管涌发展的理论分析[J]. 水利学报, 2004, 35(12): 46-50. (MAO Chang-xi, DUAN Xiang-bao, CAI Jin-bang, et al.Theoretical analysis on piping development of levee foundation[J]. Journal of Hydraulic Engineering, 2004, 35(12): 46-50. (in Chinese))
[3]	蒋中明, 王为, 冯树荣, 等. 粗粒土渗透变形特性的应力状态相关性试验研究[J]. 水利学报, 2013, 44(12): 1498-1505. (JIANG Zhong-ming, WANG Wei, FENG Shu-rong, et al.Experimental study on the relevance between stress state seepage failure of sandy-gravel soil[J]. Journal of Hydraulic Engineering, 2013, 44(12): 1498-1505. (in Chinese))
[4]	蒋中明, 王为, 冯树荣, 等. 应力状态下含黏粗粒土渗透变形特性试验研究[J]. 岩土工程学报, 2014, 36(1): 98-104. (JIANG Zhong-ming, WANG Wei, FENG Shu-rong, et al.Experimental study on influence of stress state on seepage failure characteristics of coarse grained soil with cohesive particles[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(1): 98-104. (in Chinese))
[5]	TOMLINSON S S, VAID Y P.Seepage forces and confining pressure effects on piping erosion[J]. Canadian Geotechnical Journal, 2000, 37(1): 1-13.
[6]	CHANG D S, ZHANG L M, XU T H.Laboratory investigation of initiation and development of internal erosion in soils under complex stress states[C]// ICSE6 Paris. Paris, 2012: 895-902.
[7]	罗玉龙, 吴强, 詹美礼, 等. 考虑应力状态的悬挂式防渗墙-砂砾石地基管涌临界坡降试验研究[J]. 岩土力学, 2012(增刊1): 73-78. (LUO Yu-long, WU Qiang, ZHAN Mei-li, et al.Study of critical piping hydraulic gradient of suspended cut-off wall and sand gravel foundation under different stress states[J]. Rock and Soil Mechanics, 2012(S1): 73-78. (in Chinese))
[8]	周健, 姚志雄, 张刚. 砂土渗流过程的细观数值模拟[J]. 岩土工程学报, 2007, 29(7): 977-981. (ZHOU Jian, YAO Zhi-xiong, ZHANG Gang.Mesomechanical simulation of seepage flow in sandy soil[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(7): 977-981. (in Chinese))
[9]	吴凤元, 梁力, 樊赟赟, 等. 基于PFC^3D的无黏性土渗流临界水力梯度模拟分析[J]. 东北大学学报(自然科学版), 2015(3): 428-432. (WU Feng-yuan, LIANG Li, FAN Yun-yun, et al.Simulation of critical hydraulic gradient in no cohesive soil with PFC^3D[J]. Journal of Northeastern University (Natural Science), 2015(3): 428-432. (in Chinese))
[10]	BOUILARD J X, LYCZKOWSKI R W, GIDASOW D.Porosity distributions in a fluidized bed with an immersed obstacle[J]. AICHE Journal, 1989, 35(6): 908-922.
[11]	贝尔J. 多孔介质流体动力学[M]. 李竞生, 陈崇希, 译. 北京: 中国建筑工业出版社, 1983: 91-94. (JACOB BEAR.Dynamics of fluids in porous media[M]. LI Jing-sheng, CHEN Chong-xi, trans. Beijing: China Architecture & Building Press, 1983: 91-94. (in Chinese))
[12]	JACOB B.Hydraulics of groundwater[M]. New York: Dover Publications, McGrao-Hill, 1979.
[13]	ERGUN S.Fluid flow through packed columns[J]. Chemical Engineering Progress, 1952, 48(2): 89-94.
[14]	Itasca Consulting Group Inc. PFC^2D particle flow code in 2 dimensions-optional features[M]. Minneapolis: Itasca Consulting Group Inc, 2005.
[15]	WEN C Y, YU Y H.“Mechanics of fluidization” the chemical engineering progress symposium series[M]. New York: American Institute of Chemical Engineers, 1966, 162: 100-111.
