矿震震动传播与响应规律

杜涛涛

doi:10.11779/CJGE201803004

矿震震动传播与响应规律 English Version

杜涛涛^1,2

1. 天地科技股份有限公司开采设计事业部,北京 100013;
2. 煤炭科学研究总院开采研究分院,北京100013

基金项目: 国家自然科学基金项目（51704155,51574149,51304116）; 国家重点研发计划项目（2017YFC0804209,2017YFC0804204,2016YFC0801401,2016YFC0801403）; 天地科技开采设计事业部青年创新基金项目（KJ-2015-TDKC-11）

详细信息

作者简介:
杜涛涛(1984-),男,山东枣庄人,硕士,助理研究员,主要从事冲击地压防治研究方面的工作。E-mail：yl_dutt@126.com。

计量
- 文章访问数: 369
- HTML全文浏览量: 3
- PDF下载量: 349
出版历程
- 收稿日期: 2016-03-22
- 发布日期: 2018-03-24

Propagation and response laws of mine seism

DU Tao-tao^1,2

1.Coal Mining & Designing Department, Tiandi Science & Technology Co., Ltd., Beijing 100013, China;
2. Coal Mining Branch, China Coal Research Institute, Beijing 100013, China

摘要

摘要: 针对距离震源不同距离的采掘区域冲击地压显现响应程度不同的问题,采用ARAMIS M/E微震监测系统、PASAT-M便携式微震监测系统和冲击地压多参量过程监测系统开展了矿震发生与响应过程规律研究,并通过井下爆破激发震动试验研究了震动传播衰减规律。结果表明：①冲击地压多参量过程监测系统监测到矿震的单参量（煤体应力）、多参量（煤体应力、围岩位移及锚杆受力）的响应过程,实现了震动与响应信号捕捉与记录;②矿震单参量响应规律,响应时间短（368 ms）,响应过程引起距震源75 m的煤体应力最大升高0.9 MPa,响应终值为煤体应力升高0.5 MPa,矿震的响应并非都是多参量同时响应;③矿震引起多参量响应规律,响应时间不同步,响应时间几百毫秒至几分钟不等,响应过程引起距震源150 m的煤体应力整体降低0.7~0.8 MPa、锚杆受力降低7~8 kN、顶煤位移增加4 mm,且捕捉到矿震发生10 h前的岩层位移信息,持续时间1000 ms,位移量最大24 mm,可作为矿震前兆信息;④矿井围岩介质中震动能量传播呈指数E=E₀e^ηD关系衰减,距震源200 m范围能量衰减快;震动主频的衰减变化规律也呈指数f=f₀e^ηD关系。距离震源200 m范围的采场、巷道对矿震响应比较显著,与矿震诱发冲击显现区域比较吻合。矿震发生至响应的传播衰减过程的定量关系研究,对进一步提高冲击地压监测预警与防治技术水平具有一定的现实意义。
- 矿震 /
- 冲击地压 /
- 震动响应过程 /
- 震动衰减规律
Abstract: In order to analyze the response degree problem that seismic waves of surrounding rock are different at places with different distances from mine seism source, the ARAMIS M/E microseismic monitoring system, PASAT-M portable microseismic system and rockburst multi-parameter process monitoring system are employed to study the propagation and response laws of mine seism. The results show that: (1) The rockburst multi-parameter process monitoring system can capture variations of single-parameter (coal stress) and multi-parameter (coal stress, displacement of roadway and anchored bolt force) at the moment of mine seism; (2) For the single parameter laws of mine seism, the response time is short (368 ms), the mine seism-induced increase of the maximum coal stress reaches 0.9 MPa, which is 75 m from seism source, the final increase value of coal stress is 0.5 MPa, and not all the response of mine seism is multi-parameter simultaneous response; (3) For the multi-parameter laws of mine seism, the response time is not synchronized and varies from a few hundred milliseconds to a few minutes. At the place 150 m from the seism source, the coal stress decreases by 0.7~0.8 MPa, the anchored bolt force decreases by 7~8 kN, and the top-coal displacement increases by 4 mm. The displacement data of strata within 10 hours before the mine seism is captured with the duration time of 1000 ms and the maximum displacement of 24 mm, and they can be used as the prediction information for mine seism; (4) The attenuation of seismic energy propagation in the surrounding rock of the mine is exponential, that is E=E₀e^ηD. The energy attenuation is fast, within 200 m range of seism source. The attenuation of main frequency in the surrounding rock is exponential' f=f₀e^ηD. The response of mining field and roadway within 200 m-range of the seism source is quite obvious, and the area is quite consistent with that of rockburst induced by mine seism. The quantitative study on the process of the propagation attenuation of mine seism to the response is important to the further improvement of the monitoring, early warning, prevention and control technology of rockbursts.
- mine seism /
- rockburst /
- mine seism response process /
- attenuation law

HTML全文

参考文献(22)

[1]	窦林名, 何学秋. 冲击矿压防治理论与技术[M]. 徐州: 中国矿业大学出版社, 2001. (DOU Lin-ming, HE Xue-qiu.Theory and technique of rockburst prevention[M]. Xuzhou: China University of Mining and Technology Press, 2001. (in Chinese))
[2]	蓝航. 浅埋煤层冲击地压发生类型及防治对策[J]. 煤炭科学技术, 2014, 42(1): 9-13. (LAN Hang.Prevention measures and types of mine strata pressure bump occurred in shallow depth seam[J]. Coal Science and Technology, 2014, 42(1): 9-13. (in Chinese))
[3]	蓝航, 齐庆新, 潘俊锋, 等. 我国煤矿冲击地压特点及防治技术分析[J]. 煤炭科学技术, 2011, 39(1): 11-15. (LAN Hang, QI Qing-xin, PAN Jun-feng, et al.Analysis on features as well as prevention and control technology of mine strata pressure bumping in China[J]. Coal Science and Technology, 2011, 39(1): 11-15. (in Chinese))
[4]	李铁, 张建伟, 吕毓国, 等. 采掘活动与矿震关系[J].煤炭学报, 2011, 36(12): 2127-2132. (LI Tie, ZHANG Jian-wei, LÜ Yu-guo, et al.Relationship between mining and mining-induced seismicity[J]. Journal of China Coal Society, 2011, 36(12): 2127-2132. (in Chinese))
[5]	窦林名, 何江, 曹安业, 等.煤矿冲击矿压动静载叠加原理及其防治[J]. 煤炭学报, 2015, 40(7): 1469-1476. (DOU Lin-ming, HE Jiang, CAO An-ye, et al.Rock burst prevention methods based on theory of dynamic and static combined load induced in coal mine[J]. Journal of China Coal Society, 2015, 40(7): 1469-1476. (in Chinese))
[6]	曹安业, 范军, 牟宗龙, 等. 矿震动载对围岩的冲击破坏[J]. 煤炭学报, 2010, 35(12): 2006-2010. (CAO An-ye, FAN Jun, MU Zong-long, et al.Burst failure effect of mining-induced tremor on roadway surrounding rock[J]. Journal of China Coal Society, 2010, 35(12) : 2006-2010. (in Chinese))
[7]	姜耀东, 赵毅鑫, 宋彦琦, 等. 放炮震动诱发煤矿巷道动力失稳机制分析[J]. 岩石力学与工程学报, 2005, 24(17): 3131-3136. (JIANG Yao-dong, ZHAO Yi-xin, SONG Yan-qi, et al.Analysis of blasting tremor impact of roadway stability in coal mining[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(17): 3131-3136. (in Chinese))
[8]	阳生权, 周健, 吕中玉. 地下结构及其围岩爆破震动效应[J]. 工程爆破, 2006, 12(1): 82-86. (YANG Sheng-quan, ZHOU Jian, LÜ Zhong-yu.Blasting seismic effects of underground structure and country rock[J]. Engineering Blasting, 2006, 12(1): 82-86. (in Chinese))
[9]	张雪亮, 黄数棠. 爆破地震效应[M]. 北京: 地震出版社, 1981. (ZHANG Xue-liang, HUANG Shu-tang.Blasting seismic effect[M]. Beijing: Earthquake Press, 1981. (in Chinese))
[10]	寇绍金, 虞吉林, 杨根宏. 石灰岩中应力衰减机制的试验研究[J]. 力学学报, 1982, 14(6): 583-588. (KOU Shao-jin, YU Ji-lin, YANG Gen-hong.Testing studies on attenuation mechanics of stress wave in limestone[J]. Journal of Mechanics, 1982, 14(6): 583-588. (in Chinese))
[11]	郭学彬, 肖正学, 张继春, 等. 论爆破地震波在传播过程中的衰减特性[J]. 中国矿业, 2006, 15(3): 51-53, 57.(GUO Xue-bin, XIAO Zheng-xue, ZHANG Ji-chun, et al. On attenuating characteristic of blasting seismic waves in propagating process[J]. China Mining Magazine, 2006, 15(3): 51-53, 57. (in Chinese))
[12]	郭履灿, 赵凤竹. 震级与震源参数测定[M]. 北京: 中国科学技术出版社, 1986. (GUO Lu-can, ZHAO Feng-zhu.Earthquake magnitude and earthquake source parameter determination[M]. Beijing: China Science and Technique Press, 1986. (in Chinese))
[13]	李夕兵, 古德生. 岩石冲击动力学[M]. 长沙: 中南工业大学出版社, 1994. (LI Xi-bing, GU De-sheng.Rock impact dynamics[M]. Changsha: Central South University of Technology Press, 1994. (in Chinese))
[14]	GRADY D E, KIPP M E.The micromechanics of impact fracture of rock[J]. International Journal of Rock Mechanics and Mining Sciences and Geomechanics Abstracts, 1979, 16(6): 293-302.
[15]	TRUNIN R F.Shock compressibility of condensed materials in strong shock waves generated by underground nuclear explosive[J]. Physics Uspekhi, 1994, 37(11): 1123-1146.
[16]	吴文, 徐松林, 杨春和, 等. 盐岩冲击特性试验研究[J]. 岩石力学与工程学报, 2004, 23(21): 3613-3620. (WU Wen, XU Song-lin, YANG Chun-he, et al.Testing studies on response behaviour of rock salt to impacting[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(21): 3613-3620. (in Chinese))
[17]	高明仕, 窦林名, 张农, 等. 岩土介质中冲击震动波传播规律的微震试验研究[J]. 岩石力学与工程学报, 2007, 26(7): 1365-1371. (GAO Ming-shi, DOU Lin-ming, ZHANG Nong, et al.Experimental study on earthquake tremor for transmitting law of rock burst in geomate-rials[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(7): 1365-1371. (in Chinese))
[18]	高明仕, 赵国栋, 刘波涛, 等. 煤巷围岩冲击矿压震动效应的爆破类比试验研究[J]. 煤炭学报, 2014, 39(4): 637-643. (GAO Ming-shi, ZHAO Guo-dong, LIU Bo-tao, et al.Blasting analogical experiment study on the vibration effects of rock burst in coal roadway[J]. Journal of China Coal Society, 2014, 39(4): 637-643. (in Chinese))
[19]	叶根喜, 姜福兴, 郭延华, 等. 煤矿深部采场爆破地震波传播规律的微震原位试验研究[J]. 岩石力学与工程学报, 2008, 27(5): 1053-1058. (YE Gen-xi, JIANG Fu-xing, GUO Yan-hua, et al.Experimental research on seimic wave attenuation by field microseimic monitoring in a deep coal mime[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(5): 1053-1058. (in Chinese))
[20]	曹安业, LUO Xun, 窦林名, 等. 采动煤岩体中冲击震动波传播的微震效应试验研究[J]. 采矿与安全工程学报, 2011, 28(4): 530-535. (CAO An-ye, LUO Xun, DOU Lin-ming, et al.Experimental research on seismic wave transmission and attenuation assoiated with underground longwall coal mining[J]. Journal of Mining & Safty Engineering, 2011, 28(4): 530-535. (in Chinese))
[21]	LU Cai-ping, DOU Lin-ming, WU Xing-rong, et al.Case study of blast-induced shock wave propagation in coal and rock[J]. Int J Rock Mech Min Sci, 2010, 47: 1046-1054.
[22]	LU Cai-ping, DOU Lin-ming, ZHANG Nong, et al.Microseismic frequency-spectrum evolutionary rule of rockburst triggered by roof fall[J]. Int J Rock Mech Min Sci, 2013, 64: 6-16.
