高陡横坡段桩柱式桥梁双桩基础现场试验研究

赵明华; 杨超炜; 陈耀浩; 尹平保

doi:10.11779/CJGE201802014

高陡横坡段桩柱式桥梁双桩基础现场试验研究 English Version

1.湖南大学岩土工程研究所,湖南长沙 410082
2.长沙理工大学土木与建筑学院,湖南长沙 410114

基金项目: 国家自然科学基金项目（51278187,51408066）

详细信息

作者简介:
赵明华(1956-),男,湖南洞口人,教授,博士生导师,主要从事桩基础及软土地基处理等研究。E-mail: mhzhaohd@21cn.com。

中图分类号: TU443.1
计量
- 文章访问数: 364
- HTML全文浏览量: 3
- PDF下载量: 384
出版历程
- 收稿日期: 2016-11-14
- 发布日期: 2018-02-24

Field tests on double-pile foundation of bridges in high-steep cross slopes

1.Geotechnical Institute of Hunan University, Changsha 410082, China
2.School of Civil Engineering and Architecture, Changsha University of Science & Technology, Changsha 410114, China

摘要

摘要: 为分析高陡横坡段桩柱式桥梁双桩基础承载特性及荷载传递机理,依托湖南省张花（张家界—花垣）高速公路泗溪河一桥^#6桩开展了现场试验研究。通过采集施工过程中不同工况条件下桩身应力数据,分析了桩身轴力,桩侧摩阻力以及桩身弯矩分布规律。试验结果表明：试桩桩身所受轴向荷载全部由桩侧摩阻力承担,荷载较小时基本由上部土层承担;坡面以下2~5倍桩径范围内桩土极限摩阻力较小,土层与岩层所提供摩阻力之比随荷载增大而降低;桩顶存在负弯矩,前、后桩与横系梁为受力整体。基于有限杆单元方法建立了双桩结构整体分析模型,并通过反算拟合确定了前、后桩土压力分布规律及大小,计算结果与实测值吻合良好,可为同类工程提供参考。
- 桥梁工程 /
- 桩基础 /
- 高陡横坡 /
- 现场试验
Abstract: To analyze the bearing capacity and load transfer mechanism of double-pile bridge foundation in high-steep cross slopes, field tests are carried out located on pier No. 6 in Sixi bridge of Zhangjiajie-Huayuan highway. On the basis of the received measurements of stresses, the distribution rules of the axial force, shaft resistance and moment are obtained. The in-situ results indicate that all the applied loads can be carried by the shaft resistance. In particular, the upper soil layer carries most of the applied loads in the condition that the applied loads are relatively small. The ultimate shaft resistance in the depth whose range varies from 2 to 5 times the pile diameter is very small. The ratio of shaft resistances respectively supported by soils to rocks decreases with the increase of the loads. The negative bending moment occurs near the pile top, and the fact shows that the front pile, back pile as well as tie beam, as an integration, support the external load together. A double-pile analysis model is established based on the finite bar element method, and the distribution form and magnitude of earth pressure are proposed through fitting calculation. The calculated results match well with the measured values, which can provide a reference for similar projects.
- bridge engineering /
- pile foundation /
- high and steep cross slope /
- field test

HTML全文

参考文献(13)

[1]	杨明辉, 赵明华, 刘建华, 等. 高陡边坡桥梁基桩内力计算的幂级数解[J]. 中南大学学报(自然科学版), 2007, 38(3): 561-566. (YANG Ming-hui, ZHAO Ming-hua, LIU Jian-hua, et al.Power-progression solution for inner-force analysis of bridge pile in steep slope[J]. Journal of Central South University(Science and Technology), 2007, 38(3): 561-566. (in Chinese))
[2]	赵明华, 杨超炜, 杨明辉, 等. 基于有限杆单元法的陡坡段桥梁基桩受力分析[J]. 中国公路学报, 2014, 27(6): 51-58, 108.(ZHAO Ming-hua, YANG Chao-wei, YANG Ming-hui, et al. Mechanical analysis of bridge pile foundation in high and steep slopes based on finite bar element method[J]. China Journal of Highway and Transport, 2014, 27(6): 51-58, 108. (in Chinese))
[3]	尹平保, 赵明华, 杨明辉, 等. 考虑P-Δ效应的陡坡段桥梁双桩结构受力分析[J]. 湖南大学学报(自然科学版), 2012,39(1): 1-6. (YIN Ping-bao, ZHAO Ming-hua, YANG Ming-hui, et al.Force analysis of bridge double-pile in high and steep slope[J]. Journal of Hunan University (Natural Science) 2012,39(1): 1-6. (in Chinese))
[4]	SAWANT V A, SHUKLA S K.Three-dimensional finite element analysis of laterally loaded piles in sloping ground[J]. Indian Geotechnical Journal, 2012, 42(4): 278-286.
[5]	NG W W C, ZHANG L M. Three-dimensional analysis of performance of laterally loaded sleeved piles in sloping ground[J]. Journal of Geotechnical & Geoenvironmental Engineering, 2001, 127(6): 499-509.
[6]	陈仁朋, 顾明, 孔令刚, 等. 水平循环荷载下高桩基础受力性状模型试验研究[J]. 岩土工程学报, 2012,34(11): 1990-1996. (CHEN Ren-peng, GU Ming, KONG Ling-gang, et al.Large-scal model tests on high-rise platform pile groups under cyclic lateral loads[J]. Chinese Journal of Geotechnical Engineering, 2012,34(11): 1990-1996. (in Chinese))
[7]	尹平保, 赵明华, 杨超炜, 等. 复杂荷载下横坡段桥梁桩基承载特性试验研究[J]. 土木工程学报, 2014, 47(5): 110-117. (YIN Ping-bao, ZHAO Ming-hua, YANG Chao-wei, et al.Experimental study on bearing capacity of bridge piles in cross slopes under complex loads[J]. China Civil Engineering Journal, 2014, 47(5): 110-117. (in Chinese))
[8]	戴自航, 张晓咏, 邹盛堂, 等. 现场模拟水平分布式滑坡推力的抗滑桩试验研究[J]. 岩土工程学报, 2010, 32(10): 1513-1518. (DAI Zi-hang, ZHANG Xiao-yong, ZOU Sheng-tang, et al.Field modeling of laterally distributed landslide thrusts over anti-slide piles[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(10): 1513-1518. (in Chinese))
[9]	赵明华, 罗卫华, 雷勇, 等. 汨水河特大桥嵌岩桩承载特性试验研究[J]. 湖南大学学报(自然科学版), 2014, 41(3): 1-6. (ZHAO Ming-hua, LUO Wei-hua, LEI Yong, et al.In-site load-carrying characteristics test of Rock-socked piles of Mishui river bridge[J]. Journal of Hunan University (Natural Sciences), 2014, 41(3): 1-6. (in Chinese))
[10]	GB50081—2002 普通混凝土力学性能试验方法标准[S]. 2003. (GB50081—2002 Standard for test method mechanical properties on ordinary concrete[S]. 2003. (in Chinese))
[11]	JGJ94—2008 建筑桩基技术规范[S]. 2008. (JGJ94—2008 Technical code for building pile foundations[S]. 2008. (in Chinese))
[12]	JTGD63—2007 公路桥涵地基基础设计规范[S]. 2007. (JTGD63—2007 Code for design of ground base and foundation of highway bridge and culverts[S]. 2007. (in Chinese))
[13]	戴自航. 抗滑桩滑坡推力和桩前滑体抗力分布规律的研究[J]. 岩石力学与工程学报, 2002, 21(4): 517-521. (DAI Zi-hang.Study on distribution laws of landslide-thrust and resistance of sliding mass acting on anti-slide piles[J]. Chinese Journal of Rock Mechanics and Engineering, 2002, 21(4): 517-521. (in Chinese))
