光电编码器在深水离岸结构沉降测量中的应用

曹永勇; 关云飞; 李文轩

doi:10.11779/CJGE2017S1037

光电编码器在深水离岸结构沉降测量中的应用 English Version

南京水利科学研究院岩土工程研究所,江苏南京 210024

基金项目: 国家自然科学基金项目（51609147）; 南京水利科学研究院院基金项目（Y316010）

详细信息

作者简介:
曹永勇(1987-),男,博士,工程师,主要从事土与结构相互作用研究。E-mail:yycao@nhri.cn。

计量
- 文章访问数: 248
- HTML全文浏览量: 5
- PDF下载量: 311
出版历程
- 收稿日期: 2016-11-27
- 发布日期: 2017-11-19

Application of photoelectric encoder in measurement of deepwater offshore structure

Department of Geotechnical Engineering, Nanjing Hydraulic Research Institute, Nanjing 210024, China

摘要

摘要: 新型桶式结构防波堤是位于开敞式海域的深水离岸结构,对于该结构的沉降监测是原位试验中的一大难题。结合该结构的原位观测试验研究了离岸深水结构沉降的量测技术,利用光电编码器实现了沉降观测,并通过与同步实施的GNSS变形监测系统的结果进行对比,证明了将光电编码器用到深水离岸结构的沉降测量中是可行的,其测量精度受被测结构的倾角影响较大。开发了适用于开敞式离岸深水结构的自动化测试系统,利用该系统实现了沉降测量和数据传输。
- 深水离岸结构 /
- 光电编码器 /
- 沉降测量 /
- 自动化测量系统
Abstract: The new bucket structure breakwater is one kind of deepwater offshore structure in the open sea area. The settlement monitoring of the bucket structure has been a major problem in the in-situ tests. Combined with the in-situ tests of the structure, the settlement measurement technology of offshore deepwater structure is investigated, and the settlement measurement can be achieved using the photoelectric encoder. According to the comparison with the synchronized results of GNSS deformation monitoring system, it is proved that it is feasible to use the photoelectric encoder to measure the settlement of offshore deepwater structure, and the measurement accuracy is mainly affected by the inclination of the measured structure. An automated test system is developed for open offshore deepwater structure, which realizes settlement measurement and data transmission.
- deep-water offshore structure /
- photoelectric encoder /
- settlement measurement /
- automatic measuring system

HTML全文

参考文献(7)

[1]	TSCHERNING C C, MADSEN F. The use of height differences determined by the GPS in the construction process of the fixed link across the Great Belt[C]// FIG XIX Int. Congress. 1984.
[2]	FIALKO Y, SIMONS M, AGNEW D. The complete (3-D) surface displacement field in the epicentral area of the 1999 M W 7.1 Hector Mine Earthquake, California, from space geodetic observations[J]. Geophysical Research Letters, 2001, 28(16): 3063-3066.
[3]	唐子阳, 张志满. 箱筒下沉施工及下沉调平和纠偏[J]. 水运工程, 2009(2): 135-137. (TANG Zi-yang, ZHANG Zhi-man. Box tube’s submersion construction, sinking leveling and deviation rectification[J]. Port & Waterway Engineering, 2008(5): 48-50. (in Chinese))
[4]	孙庆祥. 基于GPS RTK技术实现海上三维高精度动态测量[J]. 测绘通报, 2008(5): 48-50. (SUN Qing-xiang. Precise 3D dynamic survey on the sea based on GPS RTK technique[J]. Bulletin of Surveying and Mapping, 2008(5): 48-50. (in Chinese))
[5]	黄醒春, 寇新建, 徐张生. 大型沉井施工过程的数字化摄影监测[J]. 岩土工程学报, 1999, 21(5): 559-563. (HUANG Xing-chun, KOU Xin-jian, XU Zhang-sheng. Monitoring of dynamic displacement of large scale well-sinking by close-up photogrammetry[J]. Chinese Journal of Geotechnical Engineering, 1999, 21(5): 559-563. (in Chinese))
[6]	曹永勇, 张海文, 丁大志, 等. 新型桶式基础防波堤在负压下沉中的结构内力观测及分析[J]. 中国港湾建设, 2014(4): 26-29. (CAO Yong-yong, ZHANG Hai-wen, DING Da-zhi, et al. Test and analysis on the structural internal force of the new bucket-based breakwater driven by negative pressure[J]. China Harbour Engineering, 2014(4): 26-29. (in Chinese))
[7]	曹永勇, 蔡正银, 关云飞, 等. 新型桶式基础防波堤在负压下沉中的稳定性试验[J]. 水运工程, 2014(7): 41-45. (CAO Yong-yong, CAI Zheng-yin, GUAN Yun-fei, et al. Stability tests for new bucket-based breakwater driven by negative pressure[J]. Port & Waterway Engineering, 2014(7): 41-45. (in Chinese))
