基于光纤监测的边坡应变场可视化系统研究

许星宇; 朱鸿鹄; 张巍; 张诚成; 施斌

doi:10.11779/CJGE2017S1019

基于光纤监测的边坡应变场可视化系统研究 English Version

南京大学地球科学与工程学院,江苏南京 210023

基金项目: 国家自然科学基金青年基金项目（41302217）; 国家自然科学基金重点项目（41230636）; 国家重大科研仪器研制项目（41427801）

详细信息

作者简介:
许星宇(1993-),男,江苏苏州人,硕士研究生,主要从事工程地质方面的研究工作。E-mail:xuxy@smail.nju.edu.cn。

通讯作者:
朱鸿鹄，E-mail：zhh@nju.edu.cn

计量
- 文章访问数: 0306
- HTML全文浏览量: 0
- PDF下载量: 0368
出版历程
- 收稿日期: 2016-11-27
- 发布日期: 2017-11-19

Development of fiber optic monitoring-based visualization system for strain fields of slopes

School of Earth Sciences and Engineering,Nanjing University, Nanjing 210023, China

摘要

摘要: 近年来分布式光纤传感技术已成为土工测试领域的一股新生力量,在岩土体尤其是边坡的变形监测中发挥了日益重要的作用。基于该技术构建的边坡智能监测系统能捕捉坡表和坡体内部应变场的时空分布特征。由于光纤监测可获取海量数据,如何对其进行高效的提取、处理和挖掘是该技术应用中的瓶颈。基于MATLAB开发的边坡应变场可视化系统通过用户界面实现了对海量光纤监测数据的识别、去噪、预测分析和可视化展示,并具有边坡稳定状态诊断及预警的功能。在一组室内边坡模型试验中,采用该系统成功实现了边坡应变场监测数据的可视化,并对边坡稳定性相关的预警阈值进行了回归分析,体现了其处理数据方便、快捷、高效、直观等特点。该系统未来将在现场边坡的监测和滑坡预警预报中发挥重要的作用。
- 光纤监测 /
- 边坡 /
- 数据处理 /
- 可视化 /
- MATLAB
Abstract: In recent years, the distributed fiber optic sensing technology has become a new tool in the research area of geotechnical tests and measurements and played an increasingly important role in deformation monitoring of geo-structures, especially slopes. Based on this technology, a smart slope monitoring system is established, which enables the collection of temporal and spatial distribution characteristics of surface and subsurface strain fields within slopes. As the fiber optic monitoring data are exceedingly huge, it brings great difficulties to data processing and mining. A visualization system for strain fieldsis of slopes developed using MATLAB. Through software interface, this system allows the identification, denoising, prediction, analysis and visualization of massive fiber optic monitoring data and has various functions of slope stability diagnosis and warning. In the laboratory model tests, this system is successfully used to shows the strain fields within the slope model and to predict the thresholds related to the slope stability condition, which demonstrate the benefits of the system such as convenient, quick, efficient and orderly charalteristics. The proposed system is of great potential in the field monitoring of slopes and landslide warning.
- fiber optic monitoring /
- slope /
- data processing /
- visualization /
- MATLAB

HTML全文

参考文献(11)

[1]	贾明涛, 王李管, 潘长良. 基于监测数据的边坡位移可视化分析系统[J]. 岩石力学与工程学报, 2003, 22(8): 1324-1328. (JIA Ming-tao, WANG Li-guan, PAN Chang-liang. Visual analysis system for slope displacement based on monitored data[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(8): 1324-1328. (in Chinese))
[2]	梁桂兰, 徐卫亚, 何育智, 等. 边坡工程监测信息可视化分析系统研发及应用[J]. 岩土力学, 2008(3): 849-853. (LIANG Gui-lan, XU Wei-ya, HE Yu-zhi, et al. Visual system development and application of data analysis for slope engineering[J]. Rock and Soil Mechanics, 2008(3): 849-853. (in Chinese))
[3]	徐卫亚, 孟永东, 田斌, 等. 复杂岩质高边坡三维地质建模及虚拟现实可视化[J]. 岩石力学与工程学报, 2010, 29(12): 2385-2397. (XU Wei-ya, MENG Yong-dong, TIAN Bin, et al. Three-dimensional geological modeling and visualization based on virtual reality for complicated high rock slope[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(12): 2385-2397. (in Chinese))
[4]	孟永东, 蔡征龙, 徐卫亚, 等. 边坡工程中监测数据场三维云图实时动态可视化方法[J]. 岩石力学与工程学报, 2012(增刊2): 3482-3490. (MENG Yong-dong, CAI Zheng-long, XU Wei-ya, et al. A method for three- dimensional nephogram real-time dynamic visualization of safety monitoring data field in slope engineering[J]. Chinese Journal of Rock Mechanics and Engineering, 2012(S2):3482-3490. (in Chinese))
[5]	施斌, 徐洪钟, 张丹, 等. BOTDR 应变监测技术应用在大型基础工程健康诊断中的可行性研究[J]. 岩石力学与工程学报, 2004, 23(3): 493-499.(SHI Bin, XU Hong-zhong, ZHANG Dan, et al. Feasibility study on application of BOTDR to health monitoring for large infrastructure engineering[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(3): 493-499. (in Chinese))
[6]	李焕强, 孙红月, 刘永莉, 等. 光纤传感技术在边坡模型试中的应用[J]. 岩石力学与工程学报, 2008, 27(8): 1703-1708. (LI Huan-qiang, SUN Hong-yue, LIU Yong-li, et al. Application of optical fiber sensing technology to slope model test[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(8): 1703-1708. (in Chinese))
[7]	ZHU H H, HO A N L, YIN J H, et al. An optical fiber monitoring system for evaluating the performance of a soil nailed slope[J]. Smart Structures and Systems, 2012, 9(5): 393-410.
[8]	朱鸿鹄, 施斌, 严珺凡, 等. 基于分布式光纤应变感测的边坡模型试验研究[J]. 岩石力学与工程学报, 2013, 32(4): 821-828. (ZHU Hong-hu, SHI Bin, YAN Jun-fan, et al. Physical model testing of slope stability based on distributed fiber-optic strain sensing technology[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(4): 821-828. (in Chinese))
[9]	ZHU H H, WANG Z Y, SHI B, et al. Feasibility study of strain based stability evaluation of locally loaded slopes: Insights from physical and numerical modeling[J]. Engineering Geology, 2016, 208: 39-50.
[10]	ITEN M, PUZRIN A M, SCHMID A. Landslide monitoring using a road-embedded optical fiber sensor[C]// Proceedings of 15th International Symposium on Smart Structures and Materials & Nondestructive Evaluation and Health Monitoring. SanDiego, 2008.
[11]	徐洪钟, 施斌, 张丹, 等. 基于小波分析的BOTDR光纤传感器信号处理方法[J]. 光电子·激光, 2003(7): 737-740. (XU Hong-zhong, SHI Bin, ZHANG Dan, et al. Signal processing of the fiber optic BOTDR sensor based on wavelet analysis[J]. Journal of Optoelectronics·Laser, 2003(7): 737-740. (in Chinese))
