Fractal characteristics of micro-seismic volume for different types of immediate rock-bursts in deep tunnels
-
摘要: 根据即时型岩爆孕育及发生过程中微震信息的自相似性,提出了一种震源体积的分形计算方法。运用上述方法,基于锦屏二级水电站施工排水洞及4条引水隧洞施工过程中的大量不同类型、等级的即时型岩爆案例,展开微震事件震源体积分布的分形行为研究。研究结果表明：即时型岩爆孕育及发生过程中的微震信息震源体积分布是具有分形结构的;即时性应变型岩爆体积分形维数大于0.7,即时性应变-结构面滑移型岩爆体积分形维数小于0.6,这意味着根据微震事件体积分形维数可以对即时性岩爆的类型进行区分;对于即时型岩爆来说,岩爆等级越强则微震体积分形维数值越大;对于即时性应变-结构面滑移型岩爆,结构面数越多则震源体积分形维数值越小。上述研究结果可以为高地应力条件下不同类型岩爆的预测与防治提供合理的科学依据。Abstract: A fractal method is put forward to study the self-similarity of the volume distribution of micro-seismic events during the development of different types of immediate rock-bursts. The proposed method is used to study the fractal behaviours of the volume distribution of micro-seismic events during the development of immediate rock-bursts that occur in four deep headrace tunnels and one drainage tunnel at the Jinping II Hydropower Station. The results indicate that the volume distribution of micro-seismic events during the evolution of immediate rock-bursts displays fractal properties. The fractal dimension of volume can be used as the basis for estimating rock-burst type, that is, the fractal dimensions of immediate strain rock-bursts are >0.7 and <1, but those of immediate strain-structure slip rock-bursts are >0.2 and <0.6. For the immediate strain rock-bursts and the immediate strain-structure slip rock-bursts, if the intensity is lower, the fractal dimensions of volume will be smaller. For the immediate strain-structure slip rock-bursts, the more the number of structure planes, the smaller the fractal dimensions of volume. These conclusions can be used as the guideline to develop a warning system and to reduce the risk of rock-bursts during construction of deep, hard-rock tunnels.
-
[1] 冯夏庭, 陈炳瑞, 张传庆, 等. 岩爆孕育过程的机制、预警与动态调控[M]. 北京: 科学出版社, 2013. (FENG Xia-ting, CHEN Bing-rui, ZHANG Chuan-qing, et al. Mechanism warning and dynamic control of rock-burst development processes[M]. Beijing: China Social Sciences Publishing House, 2013. (in Chinese)) [2] MENDECKI A J. Real time quantitative seismology in mines[M]// Rock-bursts and Seismicity in Mines. Rotterdam: Balkema, 1993: 287-295. [3] MENDECKI A J. Principles of monitoring seismic rockmass response to mining[C]// Rock-bursts and Seismicity in Mines. Balkema, 1997: 69-79. [4] 陈炳瑞, 冯夏庭, 曾雄辉, 等. 深埋隧洞TBM掘进微震实时监测与特征分析[J]. 岩石力学与工程学报, 2011, 30(2): 275-283. (CHEN Bing-rui, FENG Xia-ting, ZENG Xiong-hui, et al. Real-time micro-seismic monitoring and its characteristic analysis during TBM tunneling in deepburied tunnel[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(2): 275-283. (in Chinese)) [5] MANDELBROT B B. The Fractal geometry of nature[M]. London: W H Freeman and Company, 1982. [6] KAGAN Y Y, KNOPOFF. Stochastic synthesis of earthquake catalogs[J]. Geophys Royal Economic Society, 1981, 86(B4): 2853-2862. [7] KAGAN Y Y, KNOPOFF. Statistical study of the occurrence of shallow earthquakes[J]. Geophys Royal Economic Society, 1978, 55(1): 67-86. [8] FENG X T, STEO M. A new method of modeling the rock-microfracturing process in double torsion experiments using neural networks[J]. International Journal of Analytic and Numerical Methods in Geomechanics, 1999, 23(4): 905-923. [9] FORD A, BLENKINSOP T G. Combining fractal analysis of mineral deposit clustering with weights of evidence to evaluate patterns of mineralization: application to copper deposits of the Mount Isa Inlier, NW Queensland, Australia[J]. Ore Geology Reviews, 2008. 33: 435-450. [10] HIRATA T, SATOH T, ITO K. Fractal structure of spatial distribution microfracturing in rock[J]. Geophys J R astr Soc, 1987, 90: 367-374. [11] KATSUMATA K. A long-term seismic quiescence started 23 years before the 2011 off the Pacific coast of Tohoku Earthquake ( M =9.0)[J]. Earth Planets Space, 2011, 63: 709-712. [12] SETO M, NISHIZAWA O, KATSUYAMA K. The variation of hypocenter distribution of AE events in coal under triaxial compression[J]. Acoust Em, 1994, 11: 27-36. [13] MANDAL P, RODKIN M V. Seismic imaging of the 2001 Bhuj Mw7.7 earthquake source zone: b-value, fractal dimension and seismic velocity tomography studies[J]. Tectonophysics, 2011, 512: 1-11. [14] CAI M. Influence of stress path on tunnel excavation response-numerical tool selection and modeling strategy[J]. Tunnelling and Underground Space Technology, 2008, 23(6): 618-628. [15] 冯夏庭, 陈炳瑞, 明华军, 等. 深埋隧洞岩爆孕育规律与机制: 即时型岩爆[J]. 岩石力学与工程学报, 2012, 10(3): 447-451. (FENG Xia-ting, CHEN Bing-rui, MING Hua-jun, et al. Evolution law and mechanism of rock-bursts in deep tunnels: immediate rock-burst[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 10(3): 447-451. (in Chinese)) [16] 陈炳瑞, 冯夏庭, 明华军, 等. 深埋隧洞岩爆孕育规律与机制: 时滞型岩爆[J]. 岩石力学与工程学报, 2012, 31(3): 561-569. (CHEN Bing-rui, FENG Xia-ting, MING Hua-Jun, et al. Evolution law and mechanism of rock-bursts in deep tunnels: time delayed rock-burst[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 311(3): 561-569. (in Chinese)) [17] 江 权, 冯夏庭, 周 辉. 锦屏二级水电站深埋引水隧洞群允许最小间距研究[J]. 岩土力学, 2008, 29(3): 656-662. (JIANG Quan, FENG Xia-ting, ZHOU Hui. Study on acceptable minimum interval of long deep-buried hydropower tunnels in Jinping hydropower station[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 29(3): 656-662. (in Chinese)) [18] TANG Y. A new classification of rock-burst intensity[J]. Geol Rev, 1992, 38(5): 439-443. [19] WANG L S, LI T B, XU J, et al. Study on rock-burst and its intensity classifies in the tunnel of Erlang Mountain road[J]. Road, 1999, 2: 41-45. [20] AKI K. Estimation of earthquake moment, released energy, and stress strain drop from the G-wave spectrum[J]. Bulletin of Earthquake Research Institute, 1966, 44(12): 73-88. -
