基于裂纹扩展模式的岩质斜坡阶梯状滑移破裂机制研究

朱雷; 黄润秋; 严明; 陈国庆

doi:10.11779/CJGE201707007

基于裂纹扩展模式的岩质斜坡阶梯状滑移破裂机制研究 English Version

成都理工大学地质灾害防治与地质环境保护国家重点实验室,四川成都 610059

基金项目: 国家自然科学基金项目（41130745,41272330,41572283）

详细信息

作者简介:
朱雷(1987- ),男,博士,主要从事工程地质等方面的科研工作。E-mail: aaclee@126.com。

计量
- 文章访问数: 499
- HTML全文浏览量: 6
- PDF下载量: 304
出版历程
- 收稿日期: 2016-03-08
- 发布日期: 2017-07-24

Step-path failure mechanism of rock slopes based on crack coalescence modes in rock mass

State Key Laboratory of Geohazard Prevention and Geoenvironment Protection, Chengdu University of Technology, Chengdu 610059, China

摘要

摘要: 阶梯状滑移破裂作为节理斜坡的一种典型破坏模式,裂隙间裂纹的扩展模式对其变形破裂机制及斜坡破裂面形态具有重要的意义。通过颗粒流程序研究了不同岩桥倾角（0°,45°,90°,135°）和围压条件下双裂隙间裂纹的贯通模式、基本特征与影响因素,揭示含双裂隙岩体在不同围压作用下裂纹扩展的细观力学机制,并推广到含多裂隙岩体裂纹扩展模式中。主要成果如下：①双裂隙的贯通主要通过次生共面裂纹、次生倾斜裂纹和翼裂纹;②裂纹扩展具有明显的围压效应,低围压条件下,裂隙的贯通主要通过翼裂纹和次生倾斜裂纹,高围压条件下,裂隙的贯通主要通过次生共面裂纹和次生倾斜裂纹;③裂隙的贯通应力受岩桥倾角影响较大,岩桥倾角为45°时,裂隙的贯通应力最小,裂隙最容易贯通。结合双裂隙贯通模式的研究,对多裂隙岩体贯通模式进行研究,多裂隙岩体贯通模式可以理解为多组双裂隙的贯通模式的不同组合,同时,在多裂隙贯通模式中,裂纹会寻找贯通应力最小路径扩展。最后,结合一实际斜坡案例,对阶梯状破坏斜坡的基本破裂特征进行了总结分析,并提出了相应的破裂模式分区。
- 裂隙岩体 /
- 裂纹扩展 /
- 应力状态 /
- 阶梯状斜坡 /
- 破裂机制
Abstract: The crack propagation and coalescence mode play an important role in the step-path failure mechanism of rock slopes. By using the discrete element method (DEM), the coalescence modes between two pre-existing cracks with different geometries (rock bridge angle) and confining stresses under biaxial compression are performed. Three types of cracks can be identified during the tests, which are the secondary coplanar cracks, secondary inclined cracks and wing cracks. Meanwhile, the wing cracks and secondary inclined cracks occur under a low confining stress biaxial compression and almost disappear under a high confining stress. Based on the above, the step-path failure mechanism of multiple flaws is investigated. It is found that the crack coalescence modes depend on the coalescence stress severely, and the extended modes are carried out and show the homologous view. Finally, taking a rock slope as an example, the mechanism of rock slope step-path failure is generalized. The coalescence of the joints is from bottom to upper, and the coalescence mode of the joints is subjected to the slope stress conditions. Based on the modes of crack coalescence and correlation between crack coalescence modes and stress, three zones of the failure surface are divided.
- jointed rock /
- crack propagation /
- stress state /
- step-path slope /
- failure mechanism

HTML全文

参考文献(14)

[1]	黄润秋. 岩石高边坡发育的动力过程及其稳定性控制[J]. 岩石力学与工程学报, 2008, 27(8): 1525-1544. (HUANG Run-qiu. Geodynamical process and stability control of high rock slope development[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(8): 1525-1544. (in Chinese))
[2]	EBERHARDT E, STEAD D, COGGAN J S. Numerical analysis of initiation and progressive failure in natural rock slopes - the 1991 Randa rockslide[J]. International Journal of Rock Mechanics and Mining Sciences, 2004(41): 68-87.
[3]	LAJTAI E. Z. Brittle fracture in compression[J]. International Journal of Fracture, 1974, 10(4): 525-536.
[4]	PiNG Cao a, TAOYING Liua b, CHENGZHI Pu a b, et al. Crack propagation and coalescence of brittle rock-like specimens with pre-existing cracks in compression[J]. Engineering Geology, 2015, 187: 113-121.
[5]	WONG L, EINSTEIN H. Crack coalescence in molded gypsum and carrara marble: part 1 macroscopic observations and interpretation[J]. Rock Mechanics and Rock Engineering, 2008, 42(3): 475-511.
[6]	朱维申, 陈卫忠, 申晋. 雁形裂纹扩展的模型试验及断裂力学机制研究[J]. 固体力学学报, 1998(4): 355-360. (ZHU Wei-shen, CHEN Wei-zhong, SHEN Jin. Simulation experiment and fracture mechanism study on propagation of echelon pattern cracks[J]. Acta Mechanica Solida Sinica, 1998(4): 355-360. (in Chinese))
[7]	付金伟, 朱维申, 王向刚, 等. 节理岩体裂隙扩展过程一种新改进的弹脆性模拟方法及应用[J]. 岩石力学与工程学报, 2012, 31(10): 2088-2095. (FU Jin-wei, ZHU Wei-shen, WANG Xiang-gang, et al. An improved elastic-brittle simulation method of crack propagation process in jointed rock mass and its application[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(10): 2088-2095. (in Chinese))
[8]	LUIS Arnaldo Mejía Camones, EURÍPEDES do Amaral Vargas Jr, RODRIGO Peluci de Figueiredo, et al. Application of the discrete element method for modeling of rock crack propagation and coalescence in the step-path failure mechanism[J]. Engineering Geology, 2013, 153: 80-94.
[9]	岑夺丰, 黄达, 黄润秋. 岩质边坡断续裂隙阶梯状滑移模式及稳定性计算[J]. 岩土工程学报, 2016, 36(4): 695-706. (CEN Duo-feng, HUANG Da, HUANG Run-qiu. Step-path failure mode and stability calculation of jointed rock slopes[J]. Chinese Journal of Geotechnical Engineering, 2016, 36(4): 695-706. (in Chinese))
[10]	SAGONG M, BOBET A. Coalescence of multiple flaws in a rock-model material in uniaxial compression[J]. International Journal of Rock Mechanics & Mining Sciences, 2002, 39: 229-241.
[11]	ZHOU X P, CHENG H, FENG Y F. An experimental study of crack coalescence behaviour in rock-like materials containing multiple flaws under uniaxial compression[J]. Rock Mech Rock Eng, 2014, 47: 1961-1986.
[12]	WANG C, TANNANT D D, LILLY P A. Numerical analysis of the stability of heavily jointed rock slopes using PFC 2D [J]. International Journal of Rock Mechanics and Mining Sciences, 2003, 40(3): 415-424.
[13]	ZHOU X P, CHENG H, FENG Y F. An experimental study of crack coalescence behaviour in rock-like materials containing multiple flaws under uniaxial compression[J]. Rock Mech Rock Eng, 2014, 47: 1961-1986.
[14]	WONGA R H C, CHAUA K T, TANGB C A, et al. Analysis of crack coalescence in rock-like materials containing three flaws: part I experimental approach[J]. International Journal of Rock Mechanics & Mining Sciences, 2001, 38: 909-924.
