抗液化排水刚性桩沉桩过程中的孔压响应

王翔鹰; 刘汉龙; 江强; 陈育民

doi:10.11779/CJGE201704008

抗液化排水刚性桩沉桩过程中的孔压响应 English Version

王翔鹰^{1, 2},
刘汉龙^{1, 2, 3},
江强^{1, 2, 4},
陈育民^{1, 2}

1. 河海大学岩土力学与堤坝工程教育部重点实验室,江苏南京210098;
2. 河海大学土木与交通学院,江苏南京 210098;
3. 重庆大学土木工程学院,重庆 400045;
4. 江阴市人民政府重点工程建设办公室,江苏江阴 214400

基金项目: 国家自然科学基金面上项目（51379067）; 重点国际合作研究项目（51420105013）; 中央高校基本科研业务费项目（2015B17314）

详细信息

作者简介:
王翔鹰 (1988- ),男,安徽庐江人,博士研究生,从事抗液化排水刚性桩相关研究。E-mail: wxy5407@163.com。

计量
- 文章访问数: 357
- HTML全文浏览量: 4
- PDF下载量: 318
出版历程
- 收稿日期: 2016-01-25
- 发布日期: 2017-05-19

Field tests on response of excess pore water pressures of liquefaction resistant rigid-drainage pile

WANG Xiang-ying^{1, 2},
LIU Han-long^{1, 2, 3},
JIANG Qiang^{1, 2, 4},
CHEN Yu-min^{1, 2}

1. Key Laboratory of Ministry of Education for Geomechanics and Embankment Engineering, Hohai University, Nanjing 210098, China;
2. College of Civil and Transportation Engineering, Hohai University, Nanjing 210098, China;
3. School of Civil Engineering, Chongqing University, Chongqing 400045, China;
4. Jiangyin Construction Project Management Office, Jiangyin 214400, China

摘要

摘要: 抗液化排水刚性桩是一种将刚性桩与竖向排水体相结合的新桩型,可用于提升饱和土地基在地震作用下的抗液化能力。基于某建筑桩基工程,首次开展了抗液化排水刚性桩和不含排水体的普通刚性桩的沉桩对比现场试验,分析了沉桩过程中桩周土体超孔隙水压力的增长及消散规律。试验结果表明：沉桩过程中,抗液化排水刚性桩对桩周超孔压的消散作用对于可液化土层所在的桩侧深部埋深处最明显（试验测点距桩心2倍桩径、埋深-15 m）,该处排水桩的超孔压峰值为普通桩的1/4到1/2,排水桩消散70%峰值超孔压所需时间仅为普通桩的1/3;在深部埋深（-15 m）,排水桩的最大影响半径为2~4倍桩径,在上中部埋深（-5 m、-10 m）,排水桩的最大影响半径为4~8倍桩径;在影响范围内,同位置排水桩对深部可液化土层超孔压的消散作用要大于上中部埋深土层。现场试验数据为抗液化排水刚性桩的桩间距选择提供了有力的设计参考依据。
- 抗液化 /
- 排水刚性桩 /
- 超孔压 /
- 现场试验
Abstract: The liquefaction resistant rigid-drainage pile is a new type of pile which can be used in geotechnical earthquake engineering. The pile combines the bearing capacity of rigid pile and the drain-ability of gravel pile. Based on the pile foundation engineering of Jiangyin No.1 High School's new campus, the pile-driving field tests on liquefaction resistant rigid-drainage pile are carried out for the first time. The excess pore water pressures around drainage piles and ordinary piles are recorded during field tests, depending on various data from different locations in depths and displacements. According to these test results, the maximum excess pore water pressure around the ordinary piles is larger than that around the drainage piles during the pile driving. When the pile driving is finished, the excess pore water pressures around the drainage piles dissipate faster than those around the ordinary piles. In the influence area, the excess pore water pressure dissipation of drainage piles at deep depths where a liquefiable soil layer is located is more obviously than that at shallow depths. The data of piles tests may provide other engineers with reliable evidences.
- liquefaction resistance /
- rigid-drainage pile /
- excess pore water pressure /
- field test

HTML全文

参考文献(18)

[1]	YASUDA S, HARADA K. Measures developed in Japan after the 1964 Niigata earthquake to counter the liquefaction of soil[C]//10th U.S. National Conference on Earthquake Engineering. Anchorage, 2014.
[2]	ASHOUR M, NORRIS G. Lateral loaded pile response in liquefiable soil[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2003, 129(6): 404-414.
[3]	CHEN Y, LIU H, CHEN Z. Working mechanism and numerical simulation of assembly coastal building techniques[J]. Journal of Central South University of Technology, 2008, 15(S2): 180-185.
[4]	MOAYEDI H, HUAT B B K, MOKHBERI M, et al. Using stone column as a suitable liquefaction remediation in Persian Gulf coast[J]. Electronic Journal of Geotechnical Engineering, 2010, 15P: 1757-1767.
[5]	PARK Y H, KIM S R, KIM S H, et al. Liquefaction of embankments on sandy soils and the optimum countermeasure against the liquefaction[C]// 12th World Conference on Earthquake Engineering. Auckland, New Zealand, 2000(1): 1-5.
[6]	ADALIER K, ELGAMAL A. Mitigation of liquefaction and associated ground deformations by stone columns[J]. Engineering Geology, 2004, 72(3/4): 275-291.
[7]	TSUKAMOTO Y, ISHIHARA K, YAMAMOTO M, et al. Soil densification due to static sand pile installation for liquefaction remediation[J]. Soils and Foundations, 2000, 40(2): 9-20.
[8]	KRISHNA a. M, MADHAV M R, LATHA G M. Liquefaction mitigation of ground treated with granular piles: densification effect[J]. ISET Journal of Earthquake, 2006, 43(473): 105-120.
[9]	SADREKARIMI A, GHALANDARZADEH A. Evaluation of gravel drains and compacted sand piles in mitigating liquefaction[J]. Proceedings of the ICE-Ground Improvement, 2005, 9(3): 91-104.
[10]	TANAKA H, KITA H, IIDA T, SAIMURA Y, TAKANO Y. Liquefaction countermeasure using steel sheet pile with drain capability[J]. The Sumitomo Search, 1996(58): 72-81.
[11]	TANAKA H, KITA H, IIDA T, et al. Countermeasure using steel sheet pile with drain capability[C]// Eleventh World Conference on Earthquake Engineering. Acapulco, 1996.
[12]	OTSUSHI K, KATO T, HARA T, et al. Study on a liquefaction countermeasure for flume structure by sheet-pile with drain[J]. Ground Improvement Technologies and Case Histories, 2009: 437-443.
[13]	KITA H, IIDA T, NISHITANI M, et al. Experimental study on countermeasures for liquefaction by steel piles with drain[J]. Earthquake Engineering, Tenth World Conference, 1992: 1701-1706.
[14]	ADALIER K, PAMUK A, ZIMMIE T F. Earthquake retrofit of highway/railway embankments by sheet-pile walls[J]. Geotechnical and Geological Engineering, 2004, 22(1): 73-88.
[15]	OTSUSHI K, KATO T, HARA T, et al. Analytical study on mitigation of liquefaction-related damage to flume channel using sheet-pile with drain[J]. GeoFlorida 2010: Advances in Analysis, Modeling & Design, 2010(GSP 199): 3062-3071.
[16]	刘汉龙. 岩土工程技术创新方法与实践[J]. 岩土工程学报, 2013, 35(1): 34-58. (LIU Han-long. Technological innovation methods and practices in geotechnical engineering[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(1): 34-58. (in Chinese))
[17]	刘汉龙. 一种抗液化排水刚性桩: 中国, CN 2873886Y[P]. 中国: 2007: 0-5. (LIU Han-long. Liquefaction resistant rigid-drainage pile: China, CN 2873886Y[P]. China: 2007: 0-5. (in Chinese))
[18]	陈育民, 刘汉龙, 赵楠. 抗液化刚性排水桩振动台试验的数值模拟研究[J]. 土木工程学报, 2010, 43(12): 114-119. (CHEN Yu-min, LIU Han-long, ZHAO Nan. Laboratory test on anti-liquefaction characteristics of rigidity-drain pile[J]. China Civil Engineering Journal, 2010, 43(12): 114-119. (in Chinese))
