真空加载方式对排水板滤膜淤堵影响试验研究

徐锴; 林生法; 耿之周; 韩冉冉

doi:10.11779/CJGE2016S2020

真空加载方式对排水板滤膜淤堵影响试验研究 English Version

1. 南京水利科学研究院岩土工程研究所,江苏南京 210024;
2. 福建省建筑设计研究院,福建福州 350000;
3. 交通运输部天津水运工程科学研究院,天津 300456

基金项目: 水利部公益性行业科研专项经费项目（201401006）; 水利部公益性行业科研专项经费项目（201501043）; 国家自然科学基金项目（51408381）

详细信息

作者简介:
徐锴（1982- ）,男,博士,主要从事软土地基处理、淤泥固化以及环境土工等方面的研究,E-mail: kxu@nhri.cn。

计量
- 文章访问数: 376
- HTML全文浏览量: 3
- PDF下载量: 312
出版历程
- 收稿日期: 2016-05-18
- 发布日期: 2016-10-19

Experimental study on effects of vacuum loading modes on clogging of drainage board filtration membranes

1. Geotechnical Engineering Department, Nanjing Hydraulic Research Institute, Nanjing 210024, China;
2. Fujian Provincial Institute of Architectural Design and Research, Fuzhou 350000, China;
3. Tianjin Research Institute for Water Transport Engineering, Tianjin 300456, China

摘要

摘要: 塑料排水板滤膜的淤堵直接影响到真空预压排水固结法加固新近吹填淤泥的效果,而真空荷载加载方式是引起排水板滤膜淤堵的主要原因之一。通过室内模型试验,采用5种不同等效直径的排水板滤膜并通过控制不同的真空加载方式加固新近吹填淤泥。试验过程中对泥面沉降、排水板和土中不同深度的真空度进行监测,试验结束后测试排水板滤膜的渗透系数。试验结果表明：真空荷载不分级或者分级梯度太大,对真空预压排水固结法加固新近淤泥效果较差,排水板滤膜容易产生淤堵;排水板滤膜的等效孔径越小其淤堵情况越严重。排水板滤膜发生淤堵后其渗透系数将降低,对土体的排水固结产生不利的影响。作者建议：在真空预压处理新近吹填淤泥的工程实践中,宜选用较大的排水板滤膜等效孔,真空荷载宜采用分级加载方式,且每级真空梯度不宜过大。
- 新近吹填淤泥 /
- 真空加载方式 /
- 分级加载 /
- 滤膜 /
- 淤堵
Abstract: The clogging of drainage board filtration membranes directly affects the effects of newly-dredged mud reinforced by the vacuum preloading drainage consolidation method, and the vacuum loading mode is one of the main reasons that cause clogging of drainage board filtration membranes. The drainage board filtration membranes with 5 kinds of different equivalent diameters are used to reinforce newly-dredged mud by controlling vacuum loading modes in laboratory. The surface settlement and vacuum degree at different depths of drainage board and soil are monitored during the tests, and the permeability of drainage board filtration membranes are tested after tests. The results show that for the vacuum load without gradient or with large gradient, the effects of vacuum preloading drainage consolidation method to reinforce newly-dredged mud are poor, and drainage board filtration membranes are easily clogged. The smaller the equivalent diameter of drainage board filtration membrane the more severe the clogging. The permeability of drainage board filtration membranes decreases after clogging that causes unfavorable effects on soil drainage consolidation. It is suggested that the equivalent diameter of drainage board filtration membranes should be larger, the vacuum load should be graded, and each vacuum load gradient shouldn’t be too large in engineering practice by using the vacuum preloading method to treat newly-dredged mud.
- newly-dredged mud /
- vacuum loading mode /
- graded load /
- filter membrane /
- clogging

HTML全文

参考文献(10)

[1]	董志良, 张功新, 周琦, 等. 天津滨海新区吹填造陆浅层超软土加固技术研发及应用[J]. 岩石力学与工程学报, 2011, 30(5): 1073-1080. (DONG Zhi-liang, ZHANG Gong-xin, ZHOU Qi, et al. Research and application of improvement technology of shallow ultra-soft soil formed by dredged in tianjin binhai new area[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(5): 1073-1080. (in Chinese))
[2]	鲍树峰, 娄炎, 董志良, 等. 新近吹填淤泥地基真空固结失效原因分析及对策[J]. 岩土工程学报, 2014, 36(7): 1350-1359. (BAO Shu-feng, LOU Yan, DONG Zhi-liang, et al. Causes and countermeasures for vacuum consolidation failure of newly-dredged mud foundation[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(7): 1350-1359. (in Chinese))
[3]	PALMEIRA E M, FANNIN R J, VAID Y P. A study on the behaviour of soil geotextile systems in filtration tests[J]. Canadian Geotechnical Journal, 1997, 33(6): 899-912.
[4]	FAURE Y H, BAUDOIN A, PIERSON P, et al. A contribution for predicting geotextile clogging during filtration of suspended solids[J]. Geotextiles and Geomembranes, 2006, 24(1): 11-20.
[5]	WU Cho-sen. Soil-nonwoven geotextile filtration behavior under contact with drainage materials[C]// Geotextiles and Geomembranes 24. 2006: 1-10.
[6]	Haegeman, Wim, William Van Impe. Filtration performance testing of geotextiles for vacuum consolidation drains[J]. Geosynthetics International, 1999, 6(1): 41-51.
[7]	易华强. 土工织物反滤系统土体结构稳定性试验研究[D].北京: 清华大学, 2005. (YI Hua-qiang. Experimental study on the structure stability in soil-geotextile filtration[D]. Beijing: Tsinghua Univeresity, 2005. (in Chinese))
[8]	童朝霞. 土工织物-非连续级配土反滤系统的淤堵特性研究[D]. 北京: 清华大学, 2002. (TONG Zhao-xia. Study on clogging properties of geotextile-discontinuous graded soil filtration system[D]. Beijing: Tsinghua Univeresity, 2002. (in Chinese))
[9]	魏取福. 非织造土工布反滤性能的研究[J]. 安徽机电学院学报, 2002(3): 52-54. (WEI Qu-fu.Study on filtration properties of nonwovenv geotextile[J]. Journal of Anhui Institute of Mechanical and Electrical Engineering, 2002(3): 52-54. (in Chinese))
[10]	王钊, 陆士强. 土工织物滤层淤堵标准的探讨[J]. 水力发电学报, 1991(3): 55-63. (WANG Zhao, LU Shi-qiang. Discussion on clogging standard of geotextile filtration[J]. Journal of Hydroelectric Engineering, 1991(3): 55-63. (in Chinese))
