土工袋层间摩擦特性试验研究

刘斯宏; 樊科伟; 陈笑林; 贾凡; 毛航宇; 林亚伟

doi:10.11779/CJGE201610017

土工袋层间摩擦特性试验研究 English Version

河海大学水利水电学院,江苏南京 210098

基金项目: 国家自然科学基金面上项目（51379066）

详细信息

作者简介:
刘斯宏(1964- ),男,教授,博士生导师,从事土石坝、粒状体力学、地基加固方面的研究。E-mail: sihongliu@hhu.edu.cn。

计量
- 文章访问数: 399
- HTML全文浏览量: 1
- PDF下载量: 294
出版历程
- 收稿日期: 2015-09-03
- 发布日期: 2016-10-24

Experimental studies on interface friction characteristics of soilbags

College of Water Conservancy and Hydropower Engineering, Hohai University, Nanjing 210098, China

摘要

摘要: 土工袋层间摩擦是土工袋柔性挡土墙设计中应该考虑的关键因素,其大小直接决定了土工袋挡墙的内稳定性。通过铝棒土工袋的摩擦试验说明柔性土工袋层间摩擦与刚性体间摩擦特征的不同,进行了不同袋内材料、土工袋排列方式以及运行环境（水上或水下）等条件下的土工袋层间摩擦试验。结果表明：土工袋层间摩擦力随着袋体沿受力方向变形的增大而逐渐增大,当层间发生整体滑动时达到最大值,并趋于稳定;土工袋层间摩擦不仅与编织袋体的摩擦有关,而且受袋内材料粒径大小及排列方式的影响;土工袋浸泡于水下时,由于水的润滑作用使得编织袋间的摩擦作用减小,袋内材料为细颗粒的土工袋层间摩擦作用减小,而袋内材料为粗颗粒的土工袋层间摩擦变化不大。
- 土工袋 /
- 摩擦试验 /
- 层间摩擦 /
- 袋内材料 /
- 排列方式 /
- 水下
Abstract: The stability of retaining walls constructed with soilbags is closely related to their interlayer friction. The difference of the interlayer friction of flexible soilbags from that of rigid bodies is investigated through the tests on the bags filled with aluminum rods. A series of laboratory tests are conducted to study the influences of the materials filled into bags, the inter-layered arrangements of soilbags and the water on the interlayer friction of soilbags. It is indicated from the experimental results that (1) The frictional force between two flexible soilbags increases with the interlayer displacement of soilbags, and reaches the maximum value at the beginning of the whole slippage between two soilbags and then tends to be stable; (2) The interlayer friction of soilbags is influenced by the bag friction, the grain sizes of filling materials and the interlayer arrangements of soilbags; (3) Owing to the lubricating effect of water on bags, the interlayer friction of the soilbags filled with fine materials decreases when they are placed underwater. However, the interlayer friction of soilbags filled with coarse meterials is slightly influenced by water.
- soilbag /
- friction test /
- interlayer friction /
- filling material /
- interlayer arrangement /
- underwater

HTML全文

参考文献(21)

[1]	MATSUOKA H, LIU Si-hong. A new earth reinforcement method using soilbags[M]. London: A.A. Balkema Publishers -Taylor & Francis, 2005.
[2]	刘斯宏, 松冈元. 土工袋加固地基新技术[J]. 岩土力学, 2007, 28(8): 1665-1670. (LIU Si-hong, MATSUOKA Hajime. A new earth reinforcement method by soilbags[J]. Rock and Soil Mechanics, 2007, 28(8): 1665-1670. (in Chinese))
[3]	刘斯宏, 汪易森. 土工袋技术及其应用前景[J].水利学报(增刊), 2007: 644-648. (LIU Si-hong, WANG Yi-shen. Reinforcement mechanism of soilbags and its applications[J]. Journal of Hydraulic Engineering, 2007: 644-648. (in Chinese))
[4]	刘斯宏, 白福青, 汪易森. 膨胀土土工袋浸水变形及强度特性试验研究[J]. 南水北调与水利科技, 2009, 7(6): 54-58. (LIU Si-hong, BAI Fu-qing, WANG Yi-shen. Experimental study on wetting induced deformation and strength characteristics of soilbag filled with expansive soil[J]. South to North Water Transfers and Water Science & Technology, 2009, 7(6): 54-58. (in Chinese))
[5]	刘斯宏, 汪易森. 岩土新技术在南水北调工程中的应用研究[J]. 水利水电技术, 2009, 40(8): 61-66. (LIU Si-hong, WANG Yi-shen. Application of new geotechnologies to South-to-North Water Diversion Project[J]. Water Resources and Hydropower Engineering, 2009, 40(8): 61-66. (in Chinese))
[6]	刘斯宏, 王柳江, 李卓. 土工袋加固软土地基现场荷载试验的数值模拟[J]. 水利水电科技进展, 2012, 32(1): 78-82. (LIU Si-hong, WANG Liu-jiang, LI Zhuo. Numerical simulation of in-situ loading tests on a soilbag-reinforced soft foundation[J]. Advances in Science and Technology of Water Resources, 2012, 32(1): 78-82. (in Chinese))
[7]	毕东涛. 加筋土挡墙静动力稳定性研究[D]. 兰州: 兰州理工大学, 2011. (BI Dong-tao. The static and dynamical stability research of reinforcement retaining wall[D]. Lanzhou: Lanzhou University of Technology, 2011. (in Chinese))
[8]	刘斯宏, 薛向华, 樊科伟, 等. 土工袋柔性挡墙位移模式及土压力研究[J]. 岩土工程学报, 2014, 12(36): 2267-2273. (LIU Si-hong, XUE Xiang-hua, FAN Ke-wei, et al. Study on the earth pressure and deformation mode of a retaining wall constructed with soilbags[J]. Chinese Joumal of Geotechnical Engineering, 2014, 12(36): 2267-2273. (in Chinese))
[9]	LEE K M, MANJUNATH V R. soil-geotextile interface friction by direct shear tests[J]. Ganadian Geotechnical Journal, 2000, 37(1): 238-252.
[10]	LING H I, PAMUK A, DECHASAKULSOM M, et al Interactions between PVC geomembranes and compacted clays[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2001, 127(11): 950-954.
[11]	HSIEH Chi-wan, HSIEH Ming-wen. Load plate rigidity and scale effects on the frictional behavior of sand/geomembrane interfaces[J]. Geotextiles and Geomembranes, 2003, 121(1): 25-47.
[12]	吴景海, 陈环, 王玲娟, 等. 土工合成材料与土界面作用特性的研究[J]. 岩土工程学报, 2001, 23(1): 89-93. (WU Jing-hai, CHEN Huan, WANG Ling-juan, et al. Study on soil interaction characteristics of geosynthetics[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(1): 89-93. (in Chinese))
[13]	尹光志, 张东明, 魏作安, 等. 土工合成材料与细粒尾矿界面作用特性的试验研究[J]. 岩土力学与工程学报, 2004, 23(3): 426-429. (YI Guang-zhi, ZHANG Dong-ming, WEI Zuo-an, et al. Testing study on interaction characteristics between fine grained tailings and geosynthetics[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(3): 426-429. (in Chinese))
[14]	MIZYAL IZGIM, YIDIZ WASTI. Geomembrane-sand interface frictional properties as determined by inclined board and shear box tests[J]. Geotextiles and Geomembranes, 1998(16): 207-219.
[15]	YIDIZ WASTI, BAHADIR OGZDUZGUN Z. Geo- membrane-geotextile board and direct properties as determined by inclined board and direct shear box tests[J]. Geotextiles and Geomembranes, 2001, 19: 45-57.
[16]	徐超, 赵春风, 叶观宝. 关于土与土工合成材料界面的实验研究[J]. 同济大学学报, 2004, 32(3): 307-311. (XU Chao, ZHAO Chun-feng, YE Guan-bao. Research on interface between soil and geosythetics[J]. Journal of Tongji University, 2004, 32(3): 307-311. (in Chinese))
[17]	李萍, 唐延东, 李辉山. HDPE膜与土工布界面摩擦特性的斜板仪试验[J]. 兰州理工大学学报, 2012, 38(5): 121-124. (LI Ping, TANG Yan-dong, LI Hui-shan. Experiment of frictional properties of HDPE geomembrane against and geotextile using tilt table device[J]. Journal of Lanzhou University of Technology, 2012, 38(5): 121-124. (in Chinese))
[18]	潘洋, 秦庆娟. 土工编织袋摩擦角的试验研究[J]. 上海水务, 2007, 23(3): 43-46. (PAN Yang, QIN Qing-juan. Study on the friction angle of soilbags[J]. Shanghai Water, 2007, 23(3): 43-46. (in Chinese))
[19]	蓝日彦, 王保田, 魏军扬, 等. 生态当涂结构面层与加筋连接强度的试验研究[J]. 广西大学学报 (自然科学版), 2013, 38(1): 62-66. (LAN Ri-yan, WANG Bao-tian, WEI Jun-yang, ZHAO Bo. Experimental Study on connection strength between soil bag surface and reinforced geotextile for ecological retaining wall[J]. Journal of Guangxi University (Nat Sci Ed), 2013, 38(1): 62-66. (in Chinese))
[20]	朱君星, 张默, 曹作忠, 等. 尾矿土工织物编织袋层间界面摩擦强度特性研究[J]. 金属矿山, 2013, 404: 114-117. (ZHU Jun-xing, ZHANG Mo, CAO Zuo-zhong, et al. Study on the layer interface friction strength characteristics of tailings geotextiles woven bags[J]. Metal Mine, 2013, 404: 114-117. (in Chinese))
[21]	祝士媛. 学前教育百科全书-学科教育卷[M]. 沈阳: 沈阳出版社, 1995. (ZHU Shi-yuan. Encyclopedia for preschool school education-discipline education volume[M]. Shenyang: Shenyang Press, 1995. (in Chinese))
