盾构隧道开挖及补偿注浆对地层扰动影响的室内试验及数值模拟研究

郑刚; 张扶正; 张天奇; 查万理

doi:10.11779/CJGE201610001

盾构隧道开挖及补偿注浆对地层扰动影响的室内试验及数值模拟研究 English Version

郑刚^1,2,
张扶正^1,2,
张天奇^1,2,
查万理^1,2

1. 滨海土木工程结构与安全教育部重点试验室,天津 300072；
2. 天津大学土木工程系,天津 300072

详细信息

作者简介:
郑刚（1967- ）,男,贵州人,博士,教授,博士生导师,从事土力学及岩土工程的教学与科研工作。E-mail: zhenggang1967@163.com。

计量
- 文章访问数: 584
- HTML全文浏览量: 3
- PDF下载量: 1021
出版历程
- 收稿日期: 2015-07-19
- 发布日期: 2016-10-24

Disturbance of shield tunnel excavation and compensation grouting to surrounding soil: laboratory tests and numerical simulations

1. MOE Key Laboratory of Coast Civil Structure Safety, Tianjin 300072, China;
2. Department of Civil Engineering, Tianjin University, Tianjin 300072, China

摘要

摘要: 针对盾构法施工过程中产生的土体损失,补偿注浆是一种应用广泛的沉降控制措施。通过模型试验及数值模拟,研究了盾构隧道开挖及补偿注浆对周围土体的扰动影响。将开挖和补偿注浆连续考虑,重点研究了既有土体损失情况下补偿注浆对地表沉降和周围土体应力的影响规律,研究结果表明,盾构隧道开挖过程中,地表沉降可以用Peck公式有效预测,且沉降最大值与土体损失率呈线性关系,隧道周围土体按照应力变化情况分为正拱区、卸荷区、塑性区。补偿注浆过程中,土体按应力变化情况分为抬升挤压区和正拱补偿区。应用小应变本构模型（HSS）进行数值模拟,模拟结果与试验规律对应良好,进一步验证了模型试验揭示的隧道开挖和补偿注浆对土体的扰动机理。
- 盾构隧道 /
- 模型试验 /
- 地表沉降 /
- 土体应力变化 /
- 小应变本构 /
- 砂土
Abstract: Compensation grouting, as an effective remedial measure, is often adopted to deal with the soil loss engendered in shield tunneling. The model tests with two different scales in dry sand are performed to investigate the disturbance of tunnel excavation and compensation grouting to the surrounding soil. By “tunneling” and “grouting” sequentially in the test, the effect of compensation grouting on both surface settlements and soil stresses in the presence of soil loss is studied. The test data indicate that the surface settlements caused by tunnel excavation can be effectively predicted by the Peck formula, and the maximum settlement value is approximately proportional to the volume loss. During the stage of tunneling, the soil can be divided into three zones corresponding to the stress changes, i.e., the positive arching zone, the unloading zone and the plastic zone. During the stage of grouting, the soil can be divided into two zones according to the stress changes, i.e., the effective upheaval zone and the arching compensation zone. The two-dimensional finite element analysis considering small-strain behavior of the soil is carried out to reproduce the test data, and the simulated results correspond well to the test data, helping to further validate the disturbance mechanism by both “tunneling” and “grouting” revealed in model tests.
- shield tunnel /
- model test /
- surface settlement /
- soil stress change /
- small-strain constitutive model /
- sand

HTML全文

参考文献(16)

[1]	魏纲, 魏新江, 龚慈, 等. 软土中盾构法隧道引起的土体移动计算研究[J]. 岩土力学, 2006, 27(6): 995-999. (WEI Gang, WEI Xin-jiang, GONG Ci, et al. Study on calculation for shield tunneling-induced ground movements in clays[J]. Rock and Soil Mechanics, 2006, 27(6) : 995-999. (in Chinese))
[2]	PECK R B. Deep excavations and tunneling in soft ground[C]// Proceedings of 7th International Conference on Soil Mechanics and Foundation Engineering. Mexico City, 1969: 225-290.
[3]	LEE K M, ROWE R K, LO K Y. Subsidence owing to tunneling. I: Estimating the gap parameter[J]. Canadian Geotechnical Journal, 1992, 29(6): 929-940.
[4]	O’REILLY M P, NEW B M. Settlements above tunnels in the United Kingdom-their magnitude and prediction[C]// Proc Tunnelling 82, Institution of Mining and Metallurgy. London, 1982: 173-181.
[5]	王振信. 盾构施工对环境的影响[C]// 海峡两岸轨道交通建设与环境工程高级技术论坛. 北京: 人民交通出版社, 2008. (WANG Zheng-xin. The environmental impact of shield tunnel construction[C]// Strait Rail Construction and Environmental Engineering Advanced Technology Forum. Beijing: China Communications Press, 2008. (in Chinese))
[6]	KNOTHE S. Observations of surface movements under influence of mining and their theoretical interpretation[C]// Proceedings of European Congress on Ground Movement. Leeds. UK: University of Leeds, 1957: 210-218.
[7]	ATTEWELL P B, FARMER I W. Ground deformations resulting from shield tunnelling in London clay[J]. Canadian Geotechnical Journal, 1974, 11(3): 380-395.
[8]	廖红建, 卿伟宸, 张志刚, 等. 黄土地层盾构隧道开挖对地表沉降影响的有限元分析[J]. 西安交通大学学报, 2006, 40(11): 1343-1347. (LIAO Hong-jian, QING Wei-chen, ZHANG Zhi-gang, et al. Finite element analysis for influence of shield tunneling on settlement of ground surface in loess strata[J]. Journal of Xi'an Jiaotong University, 2006, 40(11): 1343-1347. (in Chinese))
[9]	魏纲. 盾构法隧道统一土体移动模型的建立[J]. 岩土工程学报, 2007, 29(4): 554-559. (WEI Gang. Establishment of uniform ground movement model for shield tunnels[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(4): 554-559. (in Chinese))
[10]	LEE K M. Ground response to the construction of shanghai metro Tunnel-line 2[J]. Soils and Foundations, 1999, 39(3): 113-134.
[11]	ALTAEE A, FENLLENIUS B H. Physical modeling in sand[J]. Canadian Geotechnical Journal, 1994, 31: 420-431.
[12]	BURLAND J B. Ninth laurits bjerrum memorial lecture: “small is beautiful”―the siffness of soils at small strains[J]. Canadian Geotechnical Journal, 1989, 26(4): 499-516
[13]	罗富荣, 国斌. 北京地铁天安门西站“暗挖逆筑法”施工技术[J]. 岩土工程学报, 2001, 23(1): 32-37. (LUO Fu-rong, GUO Bin. Construction technology of “tunneling and top-down method” at west tian’anmen station in metro of Beijing[J]. Chinese Journal of Geotechnical Engineering, 1998, 35(1): 159-168. (in Chinese)).
[14]	SHAHIN H M, NAKAI T F, ZHANG M, et al. Behavior of ground and response of existing foundation due to tunneling[J]. Soils and Foundations, 2011, 51(3): 395-405.
[15]	MARSHALL A M, FARRELL R, KLAR A, et al. Tunnels in sands: the effect of size, depth and volume loss on greenﬁeld displacements[J]. Géotechnique, 2012, 62(5): 385-399.
[16]	LEE C J, WU B R, CHEN H T, et al. Tunnel stability and arching effects during tunneling in soft clayey soil[J]. Tunnelling and Underground Space Technology, 2006, 21: 119-32.
