基于参考模型的三维电阻率约束反演方法研究

王传武; 李术才; 刘斌; 聂利超; 张凤凯; 宋杰; 郭谦; 任玉晓

doi:10.11779/CJGE201609016

基于参考模型的三维电阻率约束反演方法研究 English Version

山东大学岩土与结构工程研究中心,山东济南 250061

基金项目: 国家重点基础研究发展计划（“973”计划）项目（2013CB036002,2014CB046901,2015CB058101）; 国家重大科研仪器设备研制专项（51327802）; 国家自然科学基金面上项目（51479104）; 国家自然科学基金青年项目（41502279）

详细信息

作者简介:
王传武(1990- ),男,博士研究生,主要从事勘探地球物理与地下工程灾害防控方面的研究。E-mail：wangcw17@163.com。

通讯作者:
聂利超，E-mail：lichaonie@163.com

中图分类号: TU43
计量
- 文章访问数: 0318
- HTML全文浏览量: 0
- PDF下载量: 0291
出版历程
- 收稿日期: 2015-11-15
- 发布日期: 2016-09-24

3D constrained electrical resistivity inversion method based on reference model

Research Center of Geotechnical & Structural Engineering, Shandong University, Jinan 250061, China

摘要

摘要: 三维电阻率探测存在反演多解性问题,易造成地质解译困难甚至判断错误。针对该问题,提出将多种地球物理探测手段获得的已知信息构建为参考模型约束施加到电阻率反演方程中的解决思路。以地质钻探获得介质电阻率信息,以地质雷达法获得异常体界面信息,将得到的已知信息映射到三维电阻率反演得到参考模型,在电阻率反演中施加参考模型约束,形成了基于参考模型的三维电阻率约束反演方法,其中携带有已知先验信息的参考模型约束,具有定向引导电阻率反演方向的作用,理论上有助于压制反演多解性。开展相应的数值试验和工程应用,结果表明上述电阻率反演方法实现了对异常体形态、规模、电阻率值等的较好反映,是实现多元地球物理探测信息融合、压制多解性的一条可行途径。
- 三维电阻率探测 /
- 约束反演 /
- 参考模型 /
- 地质钻探 /
- 地质雷达 /
- 信息融合
Abstract: The results of 3D electrical resistivity detection are non-unique, and could easily lead to errors in geological interruption and even misjudgment. A solution is proposed to solve this problem, in which the reference model constraints constructed by the known information from other geological methods are applied to the inversion equation. The electrical resistivity information is gained by the geological drilling, and the boundary information of anomalous bodies is obtained from ground penetrating radar (GPR). All the known information is mapped into the 3D inversion and then the reference model is obtained, which is introduced to the electrical inversion. Then the 3D constrained electrical resistivity inversion method based on the reference model is got. In this method, the reference model constraints containing the prior information can guide the direction of the inverse progress and make the inversion avoid falling into local optimization. This method can reduce the multiplicity of the inverse solutions in theory. The numerical tests and engineering applications are implemented. The results show that the proposed inversion method can map the shape, size, resistivity of the abnormal body well, and is a practical way to integrate information from multiple geophysical explorations and to suppress the multiplicity.
- 3D electrical resistivity detection /
- constrained inversion /
- reference model /
- geological drilling /
- ground penetrating radar /
- information integration

HTML全文

参考文献(18)

[1]	ZHANG J, MACKIE R L, MADDEN T R. 3-D resistivity forward modeling and inversion using conjugate gradients[J]. Geophysics, 1995, 60(5): 1313-1325.
[2]	阮百尧, 村上峪, 徐世浙. 电阻率/激发极化率数据的二维反演程序[J]. 物探化探计算技术, 1999, 21(2): 116-125. (RUAN Bai-yao, MURAKAMI Y, XU Shi-zhe. 2D inversion program of induced polarization data[J]. Computing Techniques for Geophysical and Geochemical Exploration 1999, 21(2): 116-125. (in Chinese))
[3]	吴小平, 徐果明. 利用共轭度法的电阻率三维反演研究[J]. 地球物理学报, 2000, 43(3): 420-426. (WU Xiao-ping, XU Guo-ming. Study on 3D resistivity inversion using conjugate gradient method[J]. Chinese Journal of Geophysics, 2000, 43(3): 420-426. (in Chinese))
[4]	底青云, 王妙月. 积分法三维电阻率成像[J]. 地球物理学报, 2001, 44(6): 843-851. (DI Qing-yun, WANG Miao-yue. 3D resistivity tomography by integral method[J]. Chinese Journal of Geophysics, 2001, 44(6): 843-851. (in Chinese))
[5]	宛新林, 席道瑛, 高尔根, 等. 用改进的光滑约束最小二乘正交分解法实现电阻率三维反演[J]. 地球物理学报, 2005, 48(2): 439-444. (WAN Xin-lin, XI Dao-ying, GAO Er-gen, et al. 3-D resistivity inversion by the least-squares QR factorization method under improved smoothness constraint condition[J]. Chinese Journal of Geophysics, 2005, 48(1): 439-444. (in Chinese))
[6]	PIDLISECKY A, HABER E, KNIGHT R. RESINVM3D: A 3D resistivity inversion package[J]. Geophysics, 2007, 72(2): H1-H10.
[7]	SASAKI Y. 3-D resistivity inversion using the finite-element method[J]. Geophysics, 1994, 59(12): 1839-1848.
[8]	吴小平, 刘洋, 王威. 基于非结构网格的电阻率三维带地形反演[J]. 地球物理学报, 2015, 58(8): 2706-2717. (WU Xiao-ping, LIU Yang, WANG Wei. 3D resistivity inversion incorporating topography based on unstructured meshes[J]. Chinese Journal of Geophysics, 2015, 58(8): 2706-2717. (in Chinese))
[9]	OLDENBURG D W, LI Y. Inversion of induced polarization data[J]. Geophysics, 1994, 59(9): 1327-1341.
[10]	LI Y, Oldenburg D W. 3-D inversion of induced polarization data[J]. Geophysics, 2000, 65(6): 1931-1945.
[11]	刘斌, 李术才, 聂利超, 等. 矿井突水灾变过程电阻率约束反演成像实时监测模拟研究[J]. 煤炭学报, 2012, 37(10): 1722-1731. (LIU Bin, LI Shu-cai, NIE Li-chao, et al. Research on simulation of mine water inrush real-time monitoring of using electrical resistivity constrained inversion imaging method[J]. Journal of China Coal Society, 2012, 37(10): 1722-1731. (in Chinese))
[12]	刘斌, 李术才, 李树忱, 等. 基于不等式约束的最小二乘法三维电阻率反演及其算法优化[J]. 地球物理学报, 2012, 55(1): 260-268. (LIU Bin, LI Shu-cai, LI Shu-chen, et al. 3D electrical resistivity inversion with least-squares method based on inequality constraint and its computation efficiency optimization[J]. Chinese Journal of Geophysics, 2012, 55(1): 260-268. (in Chinese))
[13]	SAUNDERS J H, HERWANGER J V, PAIN C C, et al. Constrained resistivity inversion using seismic data[J]. Geophysical Journal International, 2005, 160(3): 785-796.
[14]	KAIPIO J P, KOLEHMAINEN V, VAUHKONEN M, et al. Inverse problems with structural prior information[J]. Inverse Problems, 1999, 15(3): 713-729.
[15]	李术才, 刘斌, 孙怀凤, 等. 隧道施工超前地质预报研究现状及发展趋势[J]. 岩石力学与工程学报, 2015, 33(6): 1090-1113. (LI Shu-cai, LIU Bin, SUN Huai-feng, et al. State of art and trends of advanced geological prediction in tunnel construction[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 33(6): 1090-1113. (in Chinese))
[16]	聂利超. 隧道施工含水构造激发极化定量超前地质预报理论及其应用[D]. 济南: 山东大学, 2014. (NIE Li-chao. Quantitative identification theory and its application of advanced geological prediction for water-bearing structure using induced polarization in tunnel construction period[D]. Jinan: Shandong University, 2014. (in Chinese))
[17]	文武, 高玉文, 刘洪臣, 等. 黔西南贞丰背斜卡林型金矿的综合地球物理勘查—钻孔岩芯物性研究[J]. 黄金科学技术, 2013, 21(2): 1-7. (WEN Wu, GAO Yu-wen, LIU Hong-chen, et al. The integrated geophysical exploration of Zhenfeng anticline carline - type gold deposit in southwest of Guizhou: a study of the drilling core physical property[J]. Gold Science and Technology, 2013, 21(2): 1-7. (in Chinese))
[18]	LI Shu-cai, NIE Li-chao, LIU Bin, et al. 3D electrical resistivity inversion using prior spatial shape constraints[J]. Applied Geophysics, 2013, 10(4): 361-372.
