黄土地层浸水湿陷对地铁隧道影响试验研究

翁效林; 王俊; 王立新; 张玉伟

doi:10.11779/CJGE201608003

黄土地层浸水湿陷对地铁隧道影响试验研究 English Version

翁效林¹,
王俊^{1, 2},
王立新^{1, 2},
张玉伟¹

1. 长安大学特殊地区公路工程教育部重点实验室,陕西西安 710064; 2. 中铁第一勘察设计院集团有限公司,陕西西安 710067

基金项目: 国家自然科学基金项目（51278063）

详细信息

作者简介:
翁效林(1980-),男,河南信阳人,副教授,从事特殊土性状及地下工程研究。E-mail: 49768532@qq. com。

计量
- 文章访问数: 454
- HTML全文浏览量: 2
- PDF下载量: 473
出版历程
- 收稿日期: 2015-07-29
- 发布日期: 2016-08-24

Experimental research on influence of loess collapsibility on subway tunnels

1. Key Laboratory for Special Area Highway Engineering of Ministry of Education, Changan University, Xi'an 710064, China; 2. China Railway First Survey and Design Institute Group Ltd, Xi'an 710067, China

摘要

摘要: 黄土地层浸水湿陷对地铁隧道结构的影响是较为突出的岩土工程问题之一,为深入研究黄土层湿陷变形对隧道衬砌结构的影响机制,通过改进长安大学离心机浸水装置和监测设备,系统开展了浸水条件下湿陷性黄土层对地铁隧道结构影响的离心模型试验,试验结果表明：地铁隧道周边黄土浸水湿陷会导致土层重度增加,隧道拱顶土层内部拱效应因湿陷而消散,土层自重压力增加且完全由隧道结构承担,从而会导致隧道结构受力和变形不利,传统的深埋隧道结构设计理论需考虑湿陷条件下拱顶土压力的不利增长因素;地铁隧道基底下黄土地基的浸水湿陷会明显诱发隧道结构的附加作用应力,但一定厚度的非湿陷性黄土或有效处理过湿陷性黄土层抵御下伏土体湿陷变形的能力不容忽略,非湿陷土层厚度越大,对于抵御湿陷变形的能力越强;隧道基底土层不均匀浸水湿陷会导致隧道拱顶部呈现受拉状态,底部呈现受压状态,隧道拱顶所承受的附加应力更大,约为拱底附加压应力的3倍,隧道基底的自重湿陷变形对隧道顶部衬砌结构所造成的破坏更严重。
- 隧道工程 /
- 自重湿陷性黄土 /
- 离心模型试验 /
- 浸水湿陷 /
- 隧道结构
Abstract: The influence of immersion collapse of the large-thickness loess layer on the subway tunnel structure is one of the prominent problems in geotechnical engineering problems. To study the problem in depth, centrifugal model tests are carried out by considering two factors (collapsible loess layer around the tunnel and collapsible loess layers with different thicknesses of tunnel bottom) with the improved centrifugal field immersion devices and test monitoring equipments. The test results show that the immersion collapse causes effective severe increase of the collapsible loess layer around the tunnel, and the arching effect of soil inside the tunnel vault disappears due to collapse. The weight of earth pressure on the tunnel structure increases significantly, which has bad influence on force and deformation of tunnel structure. The traditional design theory of deep-buried tunnel should consider these negative factors. The capacity of non-collapsible loess with a certain thickness and collapsible loess layer which are treated effectively against the deformation caused by the collapsible soil layer below tunnel should not be ignored. The greater the thickness of the foundation treatment, the stronger the ability to resist the deformation caused by the collapse. The thickness of the rest collapsible layer of tunnel structure base should be considered in the design of collapsible loess composite foundation.
- tunnel engineering /
- self-weight collapse loess /
- centrifuge test /
- immersion /
- tunnel structure

HTML全文

参考文献(12)

[1]	谢定义. 试论我国黄土力学研究中的若干新趋向[J]. 岩土工程学报, 2001, 23(1): 3-13. (XIE Ding-yi. Exploration of some new trendencies in research of loess soil mechanics[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(1): 3-13. (in Chinese))
[2]	黄雪峰, 杨校辉. 湿陷性黄土现场浸水试验研究进展[J].岩土力学, 2013, 34(增刊2): 222-228. (HUANG Xue-feng, YANG Xiao-hui. A study progress on in-situ soaking test on collapsible loess[J]. Rock and Soil Mechanics, 2013, 34(S2): 222-228. (in Chinese))
[3]	黄雪峰, 陈正汉, 方祥位, 等. 大厚度自重湿陷性黄土地基处理厚度与处理方法研究[J]. 岩石力学与工程学报, 2007, 26(增刊2): 4332-4338. (HUANG Xue-feng, CHEN Zheng-han, FANG Xiang-wei, et al. Study on foundation treatment thickness and treatment method for collapse loess with large thickness[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(S2): 4332-4338.
[4]	黄雪峰, 陈正汉, 哈双, 等. 大厚度自重湿陷性黄土场地湿陷变形特征的大型现场浸水试验研究[J]. 岩土工程学报, 2006, 28(3): 382-389. (HUANG Xue-feng, CHEN Zheng-han, HA Shuang, et al. Large area field immersion test on characteristics of deformation of dead weight collapse loess under overburden pressure[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(3): 382-389. (in Chinese))
[5]	王小军, 米维军, 熊治文, 等. 郑西客运专线黄土地基湿陷性现场浸水试验研究[J]. 铁道学报, 2012, 34(1): 83-90. (WANG Xiao-jun, MI Wei-jun, XIONG Zhi-wen, et al. Water immersion field of collapsibility of loess foundation of Zhengzhou-Xi'an passenger dedicated line[J]. Journal of China Railway Society, 2012, 34(1): 83-90. (in Chinese))
[6]	景韧, 王永刚. 某湿陷性黄土隧道施工过程力学特性及塌陷区施工控制[J]. 公路, 2009(2): 205-210. (JING Ren, WANG Yong-gang. Mechanical behavior during construction process and construction control for collapsing stratum of collapsible loess tunnel[J]. Highway, 2009(2): 205-210. (in Chinese))
[7]	邵生俊, 杨春鸣, 焦阳阳, 等. 湿陷性黄土隧道的工程性质分析[J]. 岩土工程学报, 2013, 35(9): 1580-1590. (SHAO Sheng-jun, YANG Chun-ming, JIAO Yang-yang, et al. Engineering properties of collapsible loess tunnel[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(9): 1580-1590. (in Chinese))
[8]	罗俊忠, 张志强, 刘春龙, 等. 西安地铁临潼线、五号线穿越大厚度湿陷性黄土地基处理原则与措施研究[R]. 西安:中铁第五勘察设计院集团有限公司, 西安理工大学, 2014. (LUO Jun-zhong, ZHANG Zhi-qiang, LIU Chun-long, et al. Study on the principles and measures for the treatment of Lintong metro line and line 5 of Xi'an metro cut through the large thickness collapsible loess foundation[R]. Xi'an: China Railway Fifth Survey and Design Institute Group Co, Ltd & Xi'an University of Technology, 2014. (in Chinese))
[9]	郑建国, 高虎艳, 邓国华, 等. 西安地铁工程穿越湿陷性黄土工程特性及应对措施研究[R] 西安: 机械工业勘察设计研究院, 广州地铁设计研究院有限公司, 2013. (ZHENG Jian-guo, GAO Hu-yan, DENG Guo-hua, Research on engineering characteristics and countermeasures of Xi'an metro cut through collapsible loess foundation[R] Xi'an: China Jikan Research Institute of Engineering Investigations and Design, Co, Ltd & Guangzhou Metro Design & Research Institute Co, Ltd, 2013. (in Chinese))
[10]	廖少明, 侯学渊, 彭芳乐. 隧道纵向剪切传递效应及其一维解析[J]. 岩石力学与工程学报, 2005, 24(7): 1110-1116. (LIAO Shao-ming, HOU Xue-yuan, PENG Fang-le. Longitudinal shear transfer of tunnel and its 1D analytical solution[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(7): 1110-1116. (in Chinese))
[11]	TAYLOR R N. Buried structures and underground excavations, geotechnical centrifuge technology[M]. London: Blackie Academic and Professional, 1995.
[12]	SHUHEI Shibayama, JUN Izawa, Akihiro Takahashi, et al. Observed behaviour of a tunnel in sand subjected to shear deformation in a centrifuge[J]. Soils and Foundations, 2010, 50(2): 281-294.
