岩体裂隙面粗糙度对其渗流特性的影响研究

王志良, 申林方, 徐则民, 李邵军

王志良, 申林方, 徐则民, 李邵军. 岩体裂隙面粗糙度对其渗流特性的影响研究[J]. 岩土工程学报, 2016, 38(7): 1262-1268. DOI: 10.11779/CJGE201607013
引用本文: 王志良, 申林方, 徐则民, 李邵军. 岩体裂隙面粗糙度对其渗流特性的影响研究[J]. 岩土工程学报, 2016, 38(7): 1262-1268. DOI: 10.11779/CJGE201607013
shu
WANG Zhi-liang, SHEN Lin-fang, XU Ze-min, LI Shao-jun. Influence of roughness of rock fracture on seepage characteristics[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(7): 1262-1268. DOI: 10.11779/CJGE201607013
Citation: WANG Zhi-liang, SHEN Lin-fang, XU Ze-min, LI Shao-jun. Influence of roughness of rock fracture on seepage characteristics[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(7): 1262-1268. DOI: 10.11779/CJGE201607013
shu

岩体裂隙面粗糙度对其渗流特性的影响研究  English Version

  • 1. 昆明理工大学建筑工程学院,云南 昆明 650500；
    2. 中国科学院武汉岩土力学研究所岩土力学与工程国家重点实验室,湖北 武汉 430071

Influence of roughness of rock fracture on seepage characteristics

  • 1. Faculty of Civil Engineering and Mechanics, Kunming University of Science and Technology, Kunming 650500, China;
    2. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China

摘要

    摘要
  • 摘要: 为了研究岩体裂隙面的粗糙程度与渗流机制间的相互关系,将裂隙沿长度方向均匀分割成若干段,通过设置每一段末端的随机高度,生成两侧对称的粗糙裂隙面。基于格子Boltzmann方法,采用不可压缩流体的D2G9模型,验证了经典的Poiseuille流,计算了不同相对粗糙度岩体裂隙的渗流特性,讨论了裂隙面粗糙度对渗流流态的影响。研究结果表明：裂隙结构壁面对流体的阻碍作用,使得流体在壁面附近的流动产生急剧调整,同时随着裂隙相对粗糙度的增加,在裂隙隙宽急剧变化的部位,局部伴随着旋涡的形成,导致流体内部摩擦阻力作用增大。在单位时间截面渗流流量及每一段平均隙宽相等的条件下,将本数值解与多平行板理论解进行了对比,对于相对粗糙度δ=0.01674的裂隙方案,由于多平行板理论解忽略了粗糙裂隙隙宽变化而引起的局部压降,其裂隙中线处压降产生的最大误差达到15.2%。当相对粗糙度较小时,裂隙中线处的压力与光滑平板流相类似,近似呈线性变化。随着裂隙相对粗糙度增大,压力变化偏离直线方向,且在断面由窄突然变宽的部位,压力变化偏离线性尤为显著。
    Abstract: In order to study the relationship between surface roughness of rock fracture and seepage mechanism, the rock fracture is divided into several segments along length direction, and the symmetric rough fracture surface is generated by setting random height at the end of each segment. Based on the D2G9 model, which is used for simulating incompressible fluid, the classic Poiseuille flow is verified using the lattice Boltzmann method, the seepage characteristics of rock fracture with different relative roughnesses are calculated, and the influence of surface roughness on the flow state of fluid is discussed. The results show that the fracture wall blocks the flow of fluid, and flow state near wall changes dramatically. At the same time, with the increase of the relative roughness, there are vortices in the local area, where the changes of fracture width are dramatic, which induces the increase of internal friction in the fluid. Under the equal flow discharge of section in unit time and average fracture width, the present numerical solution is compared with the theoretical one of multi-parallel plate. Because the multi-parallel plate theory neglects the partial pressure drop caused by changes of fracture width, the maximum error of the pressure drop in the middle section is 15.2% less than the numerical solution for fracture scheme with relative roughness δ=0.01674. When the relative roughness is small, the pressure in the middle of fracture is similar to that of the smooth plate model, and the trend is almost linear. The pressure deviates from the line direction with the increase of relative roughness, and the changes are larger at the section, where the fracture width changes from narrowness to broadness suddenly.
    • HTML全文
    • 参考文献(16)
  • [1] 耿克勤, 陈凤翔, 刘光廷, 等. 岩体裂隙渗流水力特性的实验研究[J]. 清华大学学报（自然科学版）, 1996, 36(1): 102-106. (GENG Ke-qin, CHEN Feng-xiang, LIU Guang-ting, et al. Experimental research of hydraulic properties of seepage flow in fracture[J]. Journal of Tsinghua University (Science and Technology), 1996, 36(1): 102-106. (in Chinese))
    [2] 许光祥, 张永兴, 哈秋舲. 粗糙裂隙渗流的超立方和次立方定律及其试验研究[J]. 水利学报, 2003(3): 74-79. (XU Guang-xiang, ZHANG Yong-xing, HA Qiu-ling. Super-cubic and sub-cubic law of rough seepage and its experiment study[J]. Journal of Hydraulic Engineering, 2003(3): 74-79. (in Chinese))
    [3] 鞠 杨, 张钦刚, 杨永明, 等. 岩体粗糙单裂隙流体渗流机制的实验研究[J]. 中国科学（技术科学）, 2013, 43(10): 1144-1154. (JU Yang, ZHANG Qin-gang, YANG Yong-ming, et al. An experimental investigation on the mechanism of fluid flow through singe rough fracture of rock[J]. Science China (Technological Sciences), 2013, 43(10): 1144-1154. (in Chinese))
    [4] 朱红光, 谢和平, 易 成, 等. 破断岩体裂隙的流体流动特性分析[J]. 岩石力学与工程学报, 2013, 32(4): 657-663. (ZHU Hong-guang, XIE He-ping, YI Cheng, et al. Analysis of properties of fluid flow in rock fractures[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(4): 657-663. (in Chinese))
    [5] LOMIZE G M. Flow in fractured rock[M]. Moscow: Gosemergoizdat, 1951.
    [6] LOUIS C. Rock hydraulics in rock mechanics[M]. York: Spring-New Verlag, 1974.
    [7] BARTON N, BANDIS S, BAKHTER K. Strength deformation and conductivity coupling of rock joints[J]. International Journal of Rock Mechanics and Mining Science & Geomechanics Abstracts, 1985, 22(3): 121-140.
    [8] 速宝玉, 詹美礼, 赵 坚. 仿天然岩体裂隙渗流的实验研究[J]. 岩土工程学报, 1995, 17(5): 19-24. (SU Bao-yu, ZHAN Mei-li Fan, ZHAO Jian. Study on fracture seepage in the limitative nature rock[J]. Chinese Journal of Geotechnical Engineering, 1995, 17(5): 19-24. (in Chinese))
    [9] JAVADI M, SHARIFZADEH M, SHAHRIAR K. A new geometrical model for non-linear fluid flow through rough fractures[J]. Journal of Hydrology, 2010, 389: 18-30.
    [10] 张 鹏. 裂隙表面几何形态对裂隙介质力学、水力学特性的影响规律研究[D]. 西安: 西安理工大学, 2007. (ZHANG Peng. Research on influence of the morphology of the joint surface of the deformation and seepage[D]. Xi'an: Xi'an University of Technology, 2007. (in Chinese))
    [11] 盛金昌, 王 璠, 张 霞, 等. 格子Boltzmann方法研究岩石粗糙裂隙渗流特性[J]. 岩土工程学报, 2014, 36(7): 1213-1217. (SHENG Jin-chang, WANG Fan, ZHANG Xia, et al. Lattice Boltzmann method for rough fracture seepage characteristics of rock[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(7): 1213-1217. (in Chinese))
    [12] 郭照立, 郑楚光. 格子Boltzmann方法的原理及应用[M]. 北京: 科学出版社, 2008. (GUO Zhao-li, ZHENG Chu-guang. Theory and application of lattice Boltzmann method[M]. Beijing：Science Press, 2008. (in Chinese))
    [13] 何雅玲, 王 勇, 李 庆. 格子Boltzmann方法的理论及应用[M]. 北京: 科学出版社, 2008. (HE Ya-ling, WANG Yong, LI Qing. Lattice Boltzmann method: theory and applications[M]. Beijing: Science Press, 2008. (in Chinese))
    [14] GUO Zhao-li, SHI Bao-chang, WANG Neng-chao. Lattice BGK model for incompressible Navier-Stokes equation[J]. Journal of Computational Physics, 2000, 165: 288-06.
    [15] SUKOP M C, THORNE D T. Lattice Boltzmann Modeling: An introduction for geoscientists and engineers[M]. Berlin: Springer Verlag, 2006.
    [16] GUO Z L, ZHENG C G, SHI B C. Non-equilibrium extrapolation method for velocity and pressure boundary conditions in the lattice Boltzmann method[J]. Chinese Physics, 2002, 11(4): 366-374.
