软黏土中上覆荷载对注浆抬升长期效果影响的模型试验研究

郑刚, 张晓双

郑刚, 张晓双. 软黏土中上覆荷载对注浆抬升长期效果影响的模型试验研究[J]. 岩土工程学报, 2016, 38(6): 969-977. DOI: 10.11779/CJGE201606001
引用本文: 郑刚, 张晓双. 软黏土中上覆荷载对注浆抬升长期效果影响的模型试验研究[J]. 岩土工程学报, 2016, 38(6): 969-977. DOI: 10.11779/CJGE201606001
ZHENG Gang, ZHANG Xiao-shuang. Laboratory model tests on effect of overlying load on long-term effectiveness of grouting uplift in soft clay[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(6): 969-977. DOI: 10.11779/CJGE201606001
Citation: ZHENG Gang, ZHANG Xiao-shuang. Laboratory model tests on effect of overlying load on long-term effectiveness of grouting uplift in soft clay[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(6): 969-977. DOI: 10.11779/CJGE201606001

软黏土中上覆荷载对注浆抬升长期效果影响的模型试验研究  English Version

基金项目: 国家重点基础研究发展计划(“ 973 ” 计划) 项目(2010CB732106)
详细信息
    作者简介:

    郑 刚(1967- ),男,博士,教授,博士生导师,从事土力学及岩土工程教学与科研工作。E-mail:zhenggang1967@163.com。

Laboratory model tests on effect of overlying load on long-term effectiveness of grouting uplift in soft clay

  • 摘要: 利用注浆模型试验装置进行了一系列室内注浆试验,研究在不同上覆荷载条件下,软黏土中注浆抬升长期效果的变化规律,以及注浆间隔时间、土体超固结比和软黏土中加固措施对注浆抬升长期效果的影响。结果表明:正常固结土的最终补偿注浆率随上覆荷载的增大而减小,注浆峰值压力随上覆荷载的增大而增大,且与上覆荷载呈线性关系;总注浆量相同时,采用重复注浆方式时,上覆荷载较小时最终补偿注浆率小于连续注浆时最终补偿注浆率,上覆荷载较大时则大于连续注浆时最终补偿注浆率;相同上覆荷载条件下,重复注浆间隔时间越长,最终补偿注浆率越小;对超固结土,注浆抬升效果较好,最终补偿注浆率随超固结比的增大而增大,当上覆荷载大于75 kPa或者超固结比增大到2.0后,最终补偿注浆率几乎不随上覆荷载的变化而变化;对软黏土进行预先加固后再进行抬升注浆,可显著提高其最终补偿注浆率,注浆抬升效果明显。
    Abstract: A series of laboratory grouting tests are performed to study the change rules of the long-term effectiveness of grouting uplift under various overlying loads by using a set of grouting experimental setup. The effects of interval time, overconsolidation ratio and reinforcement measures of soft clay on the long-term efficiency of grouting uplift under various overlying loads are also studied. The results show that the final compensation grouting efficiency of normally consolidated soils decreases with the increase of overlying load. The peak grouting pressure increases linearly with the increase of overlying load. When the total grouting volume is the same and regrouting is conducted, the single injection with large injection volume results in the best final compensation grouting efficiency under small overlying load, whereas the final compensation grouting efficiency of single injection is less than that of regrouting under large overlying load. In addition, the larger the interval time, the lower the final compensation grouting efficiency when the overlying load is the same. For the over-consolidated soil, the efficiency of grouting uplift is significant and the final compensation grouting efficiency increases with the increase of over-consolidation ratio. The final compensation grouting efficiency almost has little change with the increase of the overlying load when the overlying load is larger than 75 kPa or the over-consolidation ratio is equal to 2.0. The reinforcement measures can significantly increase the final compensation grouting efficiency and the effect of grouting uplift is obvious.
  • [1] PECK R B. Deep excavation and tunneling in soft ground[C]// Proceedings of the 7th International Conference on Soil Mechanics and Foundation Engineering. Mexico City: State of the Art Volume, 1969: 225-290.
    [2] CORDING E J, HANSMIRE W H. Displacements around soft ground tunnels[C]// 5th Pan American Conference on Soil Mechanics and Foundation Engineering. Tomo, 1975: 571-632.
    [3] ATTEWELL P B, YEATES J, SELBY A R. Soil movement induced by tunneling and their effects on pipelines and structures[M]. Glasgow: Chapman & Hall, 1986.
    [4] 张晓丽, 张顶立, 王梦恕. 既有地铁注浆抬升合理位置的确定[J]. 岩土工程学报, 2008, 30(5): 712-717. (ZHANG Xiao-li, ZHANG Ding-li, WANG Meng-shu. Determination of proper position of grouting during lifting the existing subway[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(5): 712-717. (in Chinese))
    [5] MAIR R J, RANKIN W J, ESSLER, et al. Compensation grouting[J]. World Tunnelling and Subsurface Excavation, 1997, 7(1): 39-41.
    [6] SCHEWEIGER H F, KUMMERER C. Numerical modeling of settlement compensation by means of fracture grouting[J]. Soils and Foundations, 2004, 44(1): 71-86.
    [7] WISSER C, AUGARDE C E, BURD H J. Numerical modeling of compensation grouting above shallow tunnels[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2005, 29: 443-471.
    [8] 唐智伟, 赵成刚, 张顶立. 地下工程抬升注浆设计方法及其抬升效果预测研究[J]. 土木工程学报, 2007, 40(8): 79-84. (TANG Zhi-wei, ZHAO Cheng-gang, ZHANG Ding-li. Design of displacement grouting and prediction of the effect for construction of underground structures[J]. China Civil Engineering Journal, 2007, 40(8): 79-84. (in Chinese))
    [9] 孙 峰, 张顶立, 王 臣. 劈裂注浆抬升既有管道效果分析及工程应用[J]. 岩土力学, 2010, 31(3): 932-938. (SUN Feng, ZHANG Ding-li, WANG Chen. Analysis of raising pipeline by fracture grouting and its application[J]. Rock and Soil Mechanics, 2010, 31(3): 932-938. (in Chinese))
    [10] AU S K A, SOGA K, JAFARI M R. Factors affecting long-term efficiency of compensation grouting in clays[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2003, 129(3): 254-262.
    [11] SOGA K, AU S K A, BOLTON M D. Laboratory investigation of multiple grout injections into clay[J]. Géotechnique, 2004, 54(2): 81-90.
    [12] 易小明, 张顶立, 逄铁铮. 房屋注浆抬升实践与监测分析[J]. 岩土力学, 2009, 30(12): 3776-3782. (YI Xiao-ming, ZHANG Ding-li, PANG Tie-zheng. Practice and monitoring analysis of building lifting due to grouting[J]. Rock and Soil Mechanics, 2009, 30(12): 3776-3782. (in Chinese))
    [13] BAI Y, YANG Z, JIANG Z. Key protection techniques adopted and analysis of influence on adjacent buildings due to the bund tunnel construction[J]. Tunnelling and Underground Space Technology, 2014, 41: 21-34.
    [14] WANG S Y, CHAN D H, LAM K C. A new laboratory apparatus for studying dynamic compaction grouting into granular soils[J]. Soils and Foundations, 2013, 53(3): 462-468.
    [15] WANG S Y, CHAN D H, LAM K C. Experimental study of the effect of fines content on dynamic compaction grouting in completely decomposed granite of Hong Kong[J]. Construction and Building Materials, 2009, 23: 1249-1264.
    [16] SHIRLAW J N, DAZHI W, GANESHAN V. A compensation grouting trial in Singapore marine clay[M]// Geotechnical Aspects of Underground Construction in Soft Ground. KUSAKABE O, FUJITA K, MIYAZAKI Y, eds. Rotterdam: Balkema, 1999: 149-154.
    [17] ZHANG D, FANG Q, HOU Y. Protection of buildings against damages as a result of adjacent large-span tunneling in shallowly buried soft ground[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2013, 139: 903-913.
    [18] ZHANG F, DAMJANAC B, HUANG H. Coupled discrete element modeling of fluid injection into dense granular media[J]. Journal of Geophysical Research: Solid Earth, 2013, 118: 2703-2722.
    [19] LEE C J, WU B R, CHEN H T. Tunnel stability and arching effects during tunneling in soft clayey soil[J]. Tunnelling and Underground Space Technology, 2006, 21: 119-132.
    [20] HORPIBULSUK S, MIURA N, BERGADO D T. Undrained shear behavior of cement admixed clay at high water content[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2004, 130(10): 1096-1105.
