波散射问题求解中消除多次透射公式漂移失稳的一种措施

唐晖; 李小军; 周国良

doi:10.11779/CJGE201605023

波散射问题求解中消除多次透射公式漂移失稳的一种措施 English Version

唐晖¹,
李小军^{2, 3},
周国良¹

1. 环境保护部核与辐射安全中心,北京 100082;
2. 北京工业大学建筑工程学院,北京 100124;
3. 中国地震局地球物理研究所,北京 100081

基金项目: 国家科技重大专项课题项目（2013ZX06002001-9）; 国家自然科学基金项目（51421005,91215301）; 国家重点基础研究发展计划项目（2011CB013601）; 北京市属高等学校创新团队建设提升计划项目

详细信息

作者简介:
唐晖(1978- ),女,副研究员,主要从事场地地震反应分析,核电站结构抗震分析等相关地震工程领域的科研。E-mail: tanghui1978@163.com。

中图分类号: TU43
计量
- 文章访问数: 0334
- HTML全文浏览量: 0
- PDF下载量: 0275
出版历程
- 收稿日期: 2015-04-29
- 发布日期: 2016-05-24

Measure for eliminating drift instability of multi-transmission formula in solution of scattering problems

1. Nuclear and Radiation Safety Center, MEP, Beijing 100082, China;
2. College of Architecture and Civil Engineering, Beijing University of Technology, Beijing 100124, China;
3. Institute of Geophysics, China Earthquake Administration, Beijing 100081, China

摘要

摘要: 在采用多次透射公式求解结构–地基体系地震反应等波散射问题时,其稳定性是人们所关注和研究的重要方面。针对其漂移失稳机制的研究表明,在将总波场分离为入射波场和散射波场从而实现波动输入和多次透射边界条件施加的过程中,采用连续介质解析解给出的入射波场与计算中的实际入射波场存在较大差别,会导致漂移失稳现象的出现。基于此,提出了一种直观的改进措施,即利用多次透射边界建立边界计算区,从而获得入射波离散数值解,并应用于波动的输入过程。数值实验验证了该措施可以有效地消除计算中的漂移失稳现象,给出更为合理的计算结果。
- 多次透射公式 /
- 散射问题 /
- 波动输入方法 /
- 漂移失稳 /
- 入射波场
Abstract: Using the multi-transmitting boundary formula to solve scattering problems such as seismic response analysis of soil-structure interactive system, and instability of the multi-transmitting boundary formula is an important aspect which is needed to be studied and focused on. The studies on the drift instability mechanism of multi-transmitting boundary formula show that when the total wave field is separated into incident wave field and scattered wave field for wave motion input and applying the multi-transmitting boundary condition, there is difference of incident wave field between the analytical solution in continuous medium and the real one in discrete grids, which may result in drift instability. For this problem, an improvement measure is proposed, that is , the numerical solution of incident wave is obtained by establishing the computation model for the boundary region with the multi-transmitting boundary formula, which is used in wave motion input process. The numerical experiments show that the proposed measure can effectively eliminate the drift instability in the calculation and give more reasonable results.
- multi-transmission formula /
- scattering problem /
- wave input process /
- drift instability /
- incident wave

HTML全文

参考文献(15)

[1]	LIAO Z P, WONG H L. A transmitting boundary for the numerical simulation of elastic wave propagation[J]. Soil Dynamics and Earthquake Engineering, 1984, 3(4): 174-183.
[2]	廖振鹏, 周正华, 张艳红. 波动数值模拟中透射边界的稳定实现[J]. 地球物理学报, 2002, 45(4): 533-545. (LIAO Zhen-peng, ZHOU Zheng-hua, ZHANG Yan-hong. Stable implementation of transmitting boundary in numerical simulation of wave motion[J]. Chinese Journal of Geophysics, 2002, 45(3): 533-545. (in Chinese))
[3]	李小军, 廖振鹏. 时域局部透射边界的计算漂移失稳[J]. 力学学报, 1996, 28(5): 627-632. (LI Xiao-jun, LIAO Zhen-peng. The drift instability of local transmitting boundary in time domain[J]. Chinese Journal of Theoretical and Applied Mechanics, 1996, 28(5): 627-632. (in Chinese))
[4]	周正华, 廖振鹏. 消除多次透射公式漂移失稳的措施[J]. 力学学报, 2001, 33(4): 550-554. (ZHOU Zheng-hua, LIAO Zhen-peng. A measure for eliminating drift instability of the multi-transmitting formula[J]. Chinese Journal of theoretical and applied mechanics, 2001, 33(4): 550-554. (in Chinese))
[5]	李小军, 杨宇. 透射边界稳定性控制措施探讨[J]. 岩土工程学报, 2012, 34(4): 641-645. (LI Xiao-jun, YANG Yu. Measures for stability control of transmitting boundary[J]. Chinese Journal of Theoretical and Applied Mechanics, 2012, 34(4): 641-645. (in Chinese))
[6]	杨宇, 李小军, 贺秋梅, 等. 散射问题中消除多次透射边界漂移失稳措施比较分析[J]. 地震工程与工程振动, 2014, 34(5): 1-6. (YANG Yu, LI Xiao-jun, HE Qiu-mei, et al. Comparison of measures for eliminating drift instability of transmitting boundary in scattering problems[J]. Earthquake Engineering and Engineering Dynamics, 2014, 34(5): 1-6. (in Chinese))
[7]	景立平, 廖振鹏, 邹经相. 多次透射公式的一种高频失稳机制[J]. 地震工程与工程振动, 2002, 22(4): 7-14. (JING Li-ping, LIAO Zhen-peng, ZOU Jing-xiang. A high-frequency instability mechanism in numerical realization of multi-transmitting formula[J]. Earthquake Engineering and Engineering Dynamics, 2002, 22(4): 7-14. (in Chinese))
[8]	景立平, 吴兆营, 邹经相. 近场波动数值模拟稳定性问题分析[J]. 地震工程与工程振动, 2002, 22(2): 17-21. (JING Li-ping, WU Zhao-ying, ZOU Jing-xiang. Stability analysis for numerical simulation of near-field wave motion[J]. Earthquake Engineering and Engineering Dynamics, 2002, 22(2): 17-21. (in Chinese))
[9]	李小军, 唐晖. 结构体系动力方程求解的显式积分格式的能耗特性[J]. 工程力学, 2007, 24(2): 28-33. (LI Xiao-jun, TANG Hui. Numerical dissipation property of an explicit integration scheme for dynamic equation of structural system[J]. Engineering mechanics, 2007, 24(2): 28-33. (in Chinese))
[10]	唐晖, 李小军, 亓兴军, 等. 动力方程求解的显式积分格式对数值模拟波动特性的影响分析[J]. 地震学报, 2009, 31(5): 526-536. (TANG Hui, LI Xiao-jun, QI Xing-jun, et al. Effect of an explicit integration formula for dynamic equation on wave property of numerical simulation[J]. Acta Seismologica Sinica, 2009, 31(5): 526-536. (in Chinese))
[11]	唐晖, 李小军, 李真. 显式积分格式对局部透射边界高频失稳的抑制和消除作用[J]. 世界地震工程, 2010, 26(4): 50-54. (TANG Hui, LI Xiao-jun, LI Zhen. The effect of the explicit integration for depressing and eliminating the high-frequency instability induced by Local Transmitting Boundary[J]. World Earthquake Engineering, 2010, 26(4): 50-54. (in Chinese))
[12]	谢志南, 廖振鹏. 多次透射公式在波动数值模拟中的一种实现方案[J]. 固体力学学报, 2010, 31(4): 422-426. (XIE Zhi-nan, LIAO Zhen-peng. An implementation of multi-transmission formula for numerically simulating wave motions[J]. Chinese Journal of Solid Mechanics, 2010, 31(4): 422-426. (in Chinese))
[13]	谢志南, 廖振鹏. 透射边界高频失稳机理及其消除方法 ——SH波动[J]. 力学学报, 2012, 44(4): 745-752. (XIE Zhi-nan, LIAO Zhen-peng. Mechanism of high frequency instability caused by transmitting boundary and method of its elimination——SH wave[J]. Chinese Journal of theoretical and applied mechanics, 2012, 44(4): 745-752. (in Chinese))
[14]	李小军, 廖振鹏, 关慧敏. 黏弹性场地地形对地震动影响分析的显式有限元-有限差分方法[J]. 地震学报, 1995, 17(3): 362-369. (LI Xiao-jun, LIAO Zhen-peng, Guan Hui-min. The explicit finite element - finite difference method for viscoelastic site seismic response anlysis[J]. Acta Seismologica Sinica, 1995, 17(3): 362-369. (in Chinese))
[15]	廖振鹏. 工程波动理论导论[M]. 北京: 科学出版社, 2002. (LIAO Zhen-peng. Introduction to wave motion theories for engineering[M]. Beijing: Science Press, 2002. (in Chinese))
