不同开挖方式下深埋隧洞微震特性与岩爆风险分析

赵周能; 冯夏庭; 肖亚勋; 丰光亮

doi:10.11779/CJGE201605012

不同开挖方式下深埋隧洞微震特性与岩爆风险分析 English Version

赵周能^{1, 2},
冯夏庭^{2, 3},
肖亚勋³,
丰光亮³

1. 西南科技大学环境与资源学院,四川绵阳 621010;
2. 东北大学资源与土木工程学院,辽宁沈阳 110004;
3. 中国科学院武汉岩土力学研究所岩土力学与工程国家重点实验室,湖北武汉 430071

基金项目: 国家自然科学基金国际合作重大项目（41320104005）; 国家自然科学基金项目（11402218）; 西南科技大学博士研究基金项目（14zx7106）

详细信息

作者简介:
赵周能(1976- ),男,讲师,博士,主要从事采矿及深部岩石力学方面的研究工作。E-mail: zhzhneng@163.com。

中图分类号: TU45
计量
- 文章访问数: 0304
- HTML全文浏览量: 0
- PDF下载量: 0366
出版历程
- 收稿日期: 2015-05-05
- 发布日期: 2016-05-24

Microseismic characteristics and rockburst risk of deep tunnel constructed by different excavation methods

1. School of Environmental Engineering and Resources, Southwest University of Science and Technology, Mianyang 621010, China;
2. Northeastern University, Shenyang 110004, China;
3. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China

摘要

摘要: 在分析钻爆法和TBM法开挖下围岩应力状态的基础上,基于锦屏二级水电站深埋隧洞微震监测数据,对比研究了钻爆法和TBM法开挖条件下深埋隧洞的微震特性及岩爆风险。结果表明：①钻爆法开挖引起的围岩应力集中距洞壁较远,形成的应力梯度较小;而TBM法开挖引起的围岩应力集中临近洞壁,形成的应力梯度较大。②钻爆法开挖时围岩应变能主要集中在爆破后数小时,尤其是在1 h内释放,而TBM法以连续的方式开挖卸载,剧烈的能量释放伴随着施工全过程。③TBM法开挖导致的事件震级及震源破裂尺度均比钻爆法开挖引起的大。④钻爆法开挖时,围岩积聚的应变能大多以岩体破裂的形式耗散,以岩爆形式显现的较少;而TBM法开挖时,围岩应变能常逐次释放,导致事件频繁发生,而且部分应变能以岩爆形式显现,一般地,同一小范围内常多次发生轻微岩爆,高等级岩爆孕育过程中常伴有低等级岩爆,如中等岩爆发生前伴有轻微岩爆,强烈岩爆孕育过程中伴有轻微和（或）中等岩爆,以此类推。综合上述研究结果认为,在具有强岩爆风险的深埋隧洞中,就防治岩爆而言,钻爆法优于TBM法。
- 深埋隧洞 /
- 微震 /
- 岩爆 /
- 钻爆法 /
- TBM
Abstract: Based on the stress state analysis and microseismic monitoring data of the surrounding rock of JinpingⅡ Hydropower Station, microseismic characteristics and rockburst risk of deep tunnel constructed by TBM-drilling and blasting method are compared and studied. The results show that: (1) The stress concentration of the surrounding rock caused by the drilling- blasting method is far more away from the tunnel wall than that by TBM, and the stress gradient is small, while the stress gradient caused by TBM excavation is large. (2) The strain energy of the surrounding rock mainly releases in several hours after blasting, especially in the first hour. Under the condition of TBM excavation, the stress of the surrounding rock unloads with the continuous mode and the energy violently releases in whole construction process. (3) The Microseismic magnitude and seismic source fracture scale caused by TBM excavation are larger than those by drilling-blasting method. (4) By the drilling-blasting method, the strain energy of the surrounding rock rarely dissipates in the form of rockburst but mostly in the form of rock mass cracking. By TBM excavation, the strain energy of the surrounding rock successively dissipates, resulting in frequent microseismic events. Part of strain energy can dissipate in the form of rockburst. Generally, mild rockbursts often occur in the same range. The inoculation process of high-grade rockburst accompanies with the occurrence of low-grade rockburst. For instance, the occurrence of medium rockburst accompanies with mild rockburst and strong rockburst accompanies with medium rockburst and mild rockburst, and so on. In conclusion, the drilling-blasting method is superior to TBM for rockburst prevention and control of deep tunnel with strong rockburst risk
- deep tunnel /
- microseismicity /
- rockburst /
- drilling-blasting method /
- TBM

HTML全文

参考文献(28)

[1]	钱七虎. 地下工程建设安全面临的挑战与对策[J]. 岩石力学与工程学报, 2012, 31(10): 1945-1956. (QIAN Qi-hu. Challenges faced by underground projects construction safety and countermeasures[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(10): 1945-1956. (in Chinese))
[2]	MENDECKI A J. Seismic monitoring in mines[M]. 1st ed. London: Chapman and Hall, 1997.
[3]	DURRHEIM R J. The deep mine and future mine research programmes-knowledge and technology for deep gold mining in South Africa[C]// POTVIN Y, HADJIGEORGIOU J, STACEY D, eds. Challenges in Deep and High Stress Mining. Nedlands: AustralianCenter for Geomechanics, 2007: 130-140.
[4]	POTVIN Y, HUDYMA M R. Seismic monitoring in highly mechanized hardrock mines in Canada and Australia[C]// VAN ASWEGEN G, DURRHEIM R J, ORTLEPP W D, eds. Proceedings of the Sixth International Symposium on Rockburst and Seismicity in Mines. Johannesburg: The South Institute of Mining and Metallurgy, 2001: 267-280.
[5]	SIKORA M, WROBEL L. Application of rule induction algorithms for analysis of data collected by seismic hazard monitoring systems in coal mines[J]. Archives of Mining Sciences, 2010, 55(1): 91-114.
[6]	VALLEJOS J A, MCKINNON S D. Correlations between mining and seismicity for re-entry protocol development[J]. International Journal of Rock Mechanics and Mining Sciences, 2011, 48(4): 616-625.
[7]	赵兴东, 李元辉, 刘建坡, 等. 红透山矿深部开采岩爆潜在区微震活动性研究[J]. 东北大学学报(自然科学版) , 2009, 30(9): 1330-1333. (ZHAO Xing-dong, LI Yuan-hu, LIU Jian-po, et al. Study on microseismic activity in potential rockburst zone during deep excavation in Hongtoushan Mine[J]. Journal of Northeastern University (Natural Science), 2009, 30(9): 1330-1333. (in Chinese))
[8]	唐礼忠, 杨承祥, 潘长良. 大规模深井开采微震监测系统站网布置优化[J]. 岩石力学与工程学报, 2006, 25(10): 2036-2042. (TANG Li-zhong, YANG Cheng-xiang, PAN Chang-liang. Optimization of microseismic monitoring network for large-scale deep well mining[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(10): 2036-2042. (in Chinese))
[9]	唐绍辉, 潘懿, 黄英华, 等. 深井矿山地压灾害微震监测技术应用研究[J]. 岩石力学与工程学报, 2009, 28(2): 3597-3603. (TANG Shao-hui, PAN Yi, HUANG Ying-hua, et al. Application research of micro-seismic monitoring technology to geostress hazards in deep mining[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(2): 3597-3603. (in Chinese))
[10]	姜福兴, 杨淑华, 成云海, 等. 煤矿冲击地压的微地震监测研究[J].地球物理学报, 2006, 49(5): 1511-1516. (JIANG Fu-xing, YANG Shu-hua, CHENG Yun-hai, et al. A study on microseismic monitoring of rock burst in coal mine[J]. Chinese Journal of Geophysics, 2006, 49(5): 1511-1516. (in Chinese))
[11]	曹安业, 窦林名, 秦玉红, 等. 高应力区微震监测信号特征分析[J]. 采矿与安全工程学报, 2007, 24(2): 146-149. (CAO An-ye, DOU Lin-ming, QIN Yu-hong, et al. Characteristic ofmicroseismic monitoring signal in high stressed zone[J]. Journal of Mining & Safety Engineering, 2007, 24(2): 146-149. (in Chinese))
[12]	冯夏庭, 陈炳瑞, 明华军, 等. 深埋隧洞岩爆孕育规律与机制: 即时型岩爆[J].岩石力学与工程学报, 2012, 31(3): 433-444. (FENG Xia-ting, CHEN Bing-rui, MING Hua-jun, et al. Evolution law and mechanism of rockbursts at deep tunnels: immediate rockburst[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(3): 433-444. (in Chinese))
[13]	陈炳瑞, 冯夏庭, 明华军, 等. 深埋隧洞岩爆孕育规律与机制: 时滞型岩爆[J]. 岩石力学与工程学报, 2012, 31(3): 561-569. (CHEN Bing-rui, FENG Xia-ting, MING Hua-jun, et al. Evolution law and mechanism of rockbursts at deep tunnels: time delayed rockburst[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(3): 561-569. (in Chinese))
[14]	陈炳瑞, 冯夏庭, 曾雄辉, 等. 深埋隧洞TBM掘进微震实时监测与特征分析[J]. 岩石力学与工程学报, 2011, 30(2): 275-283. (CHEN Bing-rui, FENG Xia-ting, ZENG Xion-ghui, et al. Real-time microseismic monitoring and its characteristic analysis during TBM tunneling in deep-buried tunnel[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(2): 275-283. (in Chinese))
[15]	明华军, 冯夏庭, 陈炳瑞, 等. 基于矩张量的深埋隧洞岩爆机理分析[J]. 岩土力学, 2013, 34(1): 163–181. (MING Hua-jun, FENG Xia-ting, CHEN Bing-rui, et al. Rockburst mechanism analysis for deep-buried tunnel based on moment tensor[J]. Rock and Soil Mechanics, 2013, 34(1): 163–181. (in Chinese))
[16]	肖亚勋, 冯夏庭, 陈炳瑞, 等. 深埋隧洞极强岩爆段隧道掘进机半导洞掘进岩爆风险研究[J]. 岩土力学, 2011, 32(10): 3111-3118. (XIAO Ya-xun, FENG Xia-ting, CHEN Bing-rui, et al. Rockburst risk of tunnel boring machine part-pilot excavation in very strong rockburst section of deep hard tunnel[J]. Rock and Soil Mechanics, 2011, 32(10): 3111-3118. (in Chinese))
[17]	于群, 唐春安, 李连崇, 等. 基于微震监测的锦屏二级水电站深埋隧洞岩爆孕育过程分析[J]. 岩土工程学报, 2014, 36(12): 2315-2322. (YU Qun, TANG Chun-An, LI Lian-chong, et al. Nucleation process of rockbursts based on microseismic monitoring of deep-buried tunnels for Jinping Ⅱ Hydropower Station [J]. Chinese Journal of Geotechnical Engineering, 2014, 36(12): 2315-2322. (in Chinese))
[18]	李亮, 傅鹤林. TBM 破岩机制及刀圈改形技术研究[J].铁道学报, 2000, 22(增刊): 8-10. (LI Liang, FU He-li. Rock breaking mechanism by TBM and modification to pan knife ring[J]. Journal of the China Railway Society, 2000, 22(S0): 8-10. (in Chinese))
[19]	刘志杰, 腾弘飞, 史彦军, 等. TBM 刀盘设计若干关键技术[J]. 中国机械工程, 2008, 19(16): 1980-1985. (LIU Zhi-jie, TENG Hong-fei, SHI Yan-jun, et al. Cutter head design key issues of a full face rock tunnel boring machine(TBM)[J]. China Machine Engineering, 2008, 19(16): 1980-1985. (in Chinese))
[20]	BARTON N. TBM tunneling in jointed and faulted rock [M]. Rotterdam: Balkema, 2000: 61-64.
[21]	潘井澜. 爆破破岩机理的探讨[J]. 爆破, 1994(4): 1-6. (PAN Jing-lan. The discussion of rock mechanism by blasting[J]. Blasting, 1994(4): 1-6. (in Chinese))
[22]	薛备芳. 掘进机开挖法与钻爆法对围岩稳定性影响的比较[J]. 水利电力施工机械, 1995, 17(4): 16-17. (XUE Bei-fang. Comparison of the influence on the tunnel surrounding rock between TBM and blasting excavation[J]. Construction Machinery for Hydraulic Engineering and Power Station, 1995, 17(4): 16-17. (in Chinese))
[23]	赵周能, 冯夏庭, 丰光亮, 等. 深埋隧洞微震活动区与岩爆的相关性研究[J]. 岩土力学, 2013, 34(2): 491-497. (ZHAO Zhou-neng, FENG Xia-ting, FENG Gang-liang, et al. Study on relativity between rockburst and microseismic activity zone in deep-buried tunnel[J], Rock and Soil Mechanics, 2013, 34(2): 491-497. (in Chinese))
[24]	MENDECKI A J. Real time quantitative seismicity in mines[C]//YOUNG R P ed. Proceedings of Sixth International Symposium on Rockburst and Seismicity in Mines. Rotterdam: A. A. Balkema, 1993: 287-296.
[25]	GB 50287—2006水力发电工程地质勘查规范[S]. 2006. (GB 50287—2006 Code for hydropower engineering geological investigation[S]. 2006. (in Chinese))
[26]	冯夏庭, 陈炳瑞, 张传庆, 等. 岩爆孕育过程的机制、预警与动态调控[M]. 北京: 科学出版社, 2013: 118-141. (FENG Xia-ting, CHEN Bing-rui, ZHANG Chuan-qing, et al. Mechanism, warning and dynamic control of rockburst development processes[M]. Beijing: Science Press, 2013: 118-141. (in Chinese))
[27]	欧阳孝忠. 深埋隧洞岩爆特征及规律成因浅析[J]. 贵州水力发电, 1996, 27(4): 16-21. (OUYANG Xiao-zhong. Preliminary analysis on cause of regular pattern formation of rock burst in tunnels buried deeply[J]. Guizhou Water Power, 1996, 27(4): 16 -21. (in Chinese))
[28]	侯靖, 张春生, 单治钢. 锦屏Ⅱ级水电站深埋引水隧洞岩爆特征及防治措施[J]. 地下空间与工程学报. 2011, 7(6): 1251-1257. (HOU Jing, ZHANG Chun-sheng, SHAN Zhi-gang. Rockburst characteristics and the control measures in the deep diversion tunnel of Jinping II Hydropower Station[J]. Chinese Journal of Underground Space and Engineering, 2011, 7(6): 1251-1257. (in Chinese))
