致密岩石气体渗流滑脱效应试验研究

王环玲; 徐卫亚; 巢志明; 孔茜

doi:10.11779/CJGE201605002

致密岩石气体渗流滑脱效应试验研究 English Version

1. 河海大学港口海岸与近海工程学院,江苏南京 210098;
2. 河海大学岩土工程科学研究所,江苏南京 210098

基金项目: 江苏省青蓝工程、国家自然科学基金项目（11172090,11272113,51479049,11572110）; 江苏省自然科学基金项目（BK2012809）

详细信息

作者简介:
王环玲(1976- ),女,教授,博士生导师,主要从事岩石力学与岩石工程等方面的教学和科研。E-mail：whl_hm@163.com。

中图分类号: TU451
计量
- 文章访问数: 570
- HTML全文浏览量: 4
- PDF下载量: 427
出版历程
- 收稿日期: 2015-08-10
- 发布日期: 2016-05-24

Experimental study on slippage effects of gas flow in compact rock

1. College of Harbour, Coastal and Offshore Engineering, Hohai University, Nanjing 210098, China;
2. Institute of Geotechnical Engineering, Hohai University, Nanjing 210098, China

摘要

摘要: 由于致密结构和低的渗透率,气体在孔隙喉道小的致密岩石中流动会受到滑脱效应的影响。以湖南某试验场地致密砂岩为研究对象,对岩样进行了微观结构的SEM分析,通过一系列围压和孔隙压力作用下的砂岩气体流量和渗透率测试,研究气体在致密岩石中渗流特征,证明了致密砂岩气体流动存在滑脱效应现象,其渗流不符合Darcy定律。分析了孔压对滑脱效应的影响、滑脱效应对气测渗透率的影响以及滑脱因子与绝对渗透率的函数关系。研究结果表明,滑脱效应对气测渗透率的影响随着围压和气体孔隙压力的变化有所不同。同等围压下,孔隙压力越小,滑脱效应越明显,导致气测渗透率大于砂岩绝对渗透率。同等孔压下,当围压达到某一值后,其对滑脱效应的影响有限,同时也说明围压对岩石的压密是有限的。砂岩的平均气体孔隙压力与气测渗透率关系更加符合二次项曲线方程。计算获得的克努森数K_n说明了在相对高的围压和低的孔隙压力条件下,气体渗流过程位于滑脱流和过渡流之间,传统的N-S方程可能不再适用,应用Knudsen扩散方程更加合理,特别是当克努森数K_n比较高时。
- 致密砂岩 /
- 气体渗透率 /
- 滑脱效应 /
- 试验研究 /
- 克努森数
Abstract: Due to low porosity structure and low permeability, the gas flow in small pore throats in compact rock is usually affected by the gas slippage effects. In this study, the compact sandstone at a test site in Hunan Province is taken as an example, the micro-structure is studied using the scanning electron microscopy (SEM), and the permeability and flow rate of the sandstone under different pore pressures and confining pressures are measured. It is verified by the experiment that the gas flow in the compact rock does not meet the Darcy’s law due to the effect of gas slippage, and that the measured permeability should be corrected by the gas slippage effects. The results show that the impact of slippage on the gas permeability is different due to the change of the confining pressure and pore pressure. Under the same confining pressure, when the pore pressure is smaller, the gas slippage effects are more obvious, leading to that the measured permeability is greater than the absolute permeability. Under the same pore pressure, after the confining pressure reaches a certain value, it has a limited impact on the slippage, and the confining pressure has a limited impact on the rock compaction. The relationship between the average pore pressure and the gas permeability obeys the quadratic term equation of Knudsen’s permeability. The calculated Knudsen number (K_n) states that under relatively high confining pressure and low pore pressure, the gas flow is between slip flow and transitional flow, the traditional fluid dynamics N-S equation starts to fail, and it is safer to use Knudsen’s diffusion equation.
- compact rock /
- gas permeability /
- slippage effect /
- experimental study /
- Knudsen number
