约束条件下粗细混合颗粒动力机理分析

毕钰璋; 何思明; 李新坡; 吴永; 王东坡; 付跃升

doi:10.11779/CJGE201603017

约束条件下粗细混合颗粒动力机理分析 English Version

毕钰璋^{1, 2, 4},
何思明^1,2,3,,
李新坡^{1, 2},
吴永^{1, 2},
王东坡⁵,
付跃升⁴

1. 中国科学院山地灾害与地表过程重点实验室,四川成都 610041;
2.中国科学院水利部成都山地灾害与环境研究所,四川成都 610041;
3. 中国科学院青藏高原卓越中心,北京 100101;
4. 福州大学紫金矿业学院,福建福州 350116;
5. 成都理工大学地质灾害防治与地质环境保护国家重点实验室,四川成都 610059

基金项目: 国家自然科学基金项目(41272346,41472325,41202258,41472293,91430105); 中铁二院科学技术研究计划项目(院计划13164196(13-15))

详细信息

作者简介:
毕钰璋(1990- ),男,硕士,主要从事滑坡,崩塌方面的研究.E-mail: biyuzhang@imde.ac.cn.

通讯作者:
何思明

中图分类号: TU435
计量
- 文章访问数: 433
- HTML全文浏览量: 5
- PDF下载量: 424
出版历程
- 收稿日期: 2014-12-15
- 发布日期: 2016-03-24

Kinetic mechanism of mixed particles under constraint conditions

BI Yu-zhang^{1, 2, 4},
HE Si-ming^1,2,3,,
LI Xin-po^{1, 2},
WU Yong^{1, 2},
WANG Dong-po⁵,
FU Yue-sheng⁴

1. Key Laboratory of Mountain Hazards and Earth Surface Process, Chinese Academy of Sciences, Chengdu 610041, China;
2. Institute of Mountain Hazards and Environment, Chinese Academy of Sciences & Ministry of Water Resources, Chengdu 610041, China;
3. CAS Center for Excellence in Tibetan Plateau Earth Science, Beijing 100101, China;
4. College of Zijin Mining, Fuzhou University, Fuzhou 350116, China;
5. State Key Laboratory of Geohazard Prevention and Geoenvironment Protection, Chengdu University of Technology, Chengdu 610059, China

摘要

摘要: 混合颗粒的堆积问题一直是自然界以及工业界一个悬而未决的问题.研究的对象是相同密度不同尺寸的两相混合颗粒.通过三维离散元软件PFC3D建立高仿真数值模型并进行离散元数值试验,通过数值模拟和试验对比确定本次研究所用的参数.然后对不同条件斜槽下的颗粒堆积形态进行观察并总结其堆积规律;紧接着进一步测定相同体积条件下均匀颗粒和混合颗粒分别对结构体的动力荷载变化;最终通过研究不同斜槽约束条件下混合粒径条件下的颗粒流的运动情况并得到相应规律性的结果.通过研究发现,混合颗粒粒径条件下的颗粒流运动情况和均匀颗粒粒径条件下的颗粒流运动情况差异较大,颗粒分选对其动能的影响,有约束条件下的斜槽会增加颗粒流的滑程并提高其龙头的速度.该结论对于揭示碎屑流远程特性有一定的参考价值.
- 约束条件 /
- 混合颗粒 /
- 结构体 /
- 动能
Abstract: Granular materials flow remains an outstanding issue in both nature and industry where typically a range of particle sizes are involved. The mixing and segregation processes of binary granular mixture with particles of identical sizes and with different densities subjected to vertical oscillatory excitation are investigated. The DEM experiments are conducted in the PFC^3D, and the material parameters are fixed through the comparison between the numerical and laboratory experiments. Firstly, the deposition patterns of particles in different constraint chutes are studied. Secondly, the kinetic mechanism between uniform particles and mixed particles is compared, and the regular patterns are revealed. Finally, different kinetic mechanisms of the particles in different constraint chutes are studied, and it is proved that the mixed particles under constraint conditions get more kinetic energies and have a longer runout.
- constraint condition /
- mixed particle /
- structure /
- kinetic energy

HTML全文

参考文献(16)

[1]	YANG S C. Density effect on mixing and segregation processes in a vibrated binary granular mixture[J]. Powder Technology, 2006, 164: 65-74.
[2]	KOKELAAR B P, GRAHAM R L, GRAY J, et al. Fine-grained linings of leveed channels facilitate runout of granular flows[J]. Earth and Planetary Science Letters, 2014, 385: 172-180.
[3]	SAVAGE S B, LUN C K K. Particle size segregation in inclined chute flow of dry cohesionless granular solids[J]. Journal of Fluid Mechanics, 1988, 189: 311-335.
[4]	VALLANCE J W, SAVAGE S B. Particle segregation in granular flows down chutes[C]// IUTAM Symposium on Segregation in Granular flows. Springer Netherlands, 2000: 31-51.
[5]	SAVAGE S B. The mechanics of rapid granular flows[J]. Advances in Applied Mechanics, 1984, 24: 289-366.
[6]	DRAHUN J A, BRIDGWATER J. The mechanisms of free surface segregation[J]. Powder Technology, 1983, 36(1): 39-53.
[7]	IVERSON R M, LOGAN M, DENLINGER R P. Granular avalanches across irregular three‐dimensional terrain: 2. Experimental tests[J]. Journal of Geophysical Research: Earth Surface (2003-2012), 2004, 109(F1): 1-16.
[8]	IVERSON R M, LOGAN M, LAHUSEN R G, et al. The perfect debris flow? Aggregated results from 28 large‐scale experiments[J]. Journal of Geophysical Research: Earth Surface (2003-2012), 2010, 115(F3): 1-29.
[9]	SAVAGE S B, HUTTER K. The motion of a finite mass of granular material down a rough incline[J]. Journal of Fluid Mechanics, 1989, 199: 177-215.
[10]	WALTON O R. Particle-dynamics calculations of shear flow[C]//Presented at US-Japan Seminar on New Models and Constitutive Relations in the Mech of Granular Mater. Ithaca, 1982.
[11]	WIEDERSEINER S, ANDREINI N, ÉPELY-CHAUVIN G, et al. Experimental investigation into segregating granular flows down chutes[J]. Physics of Fluids, 2011, 23(1): 013301.
[12]	GRAY J, THORNTON A R. A theory for particle size segregation in shallow granular free-surface flows[J]. Proceedings of the Royal Society A: Mathematical, Physical and Engineering Science, 2005, 461(2057): 1447-1473.
[13]	PUDASAINI S P, HUTTER K, HSIAU S S, et al. Rapid flow of dry granular materials down inclined chutes impinging on rigid walls[J]. Physics of Fluids, 2007, 19(5): 053302.
[14]	周公旦, 孙其诚, 崔鹏. 泥石流颗粒物质分选机理和效应[J]. 四川大学学报 (工程科学版), 2013(1): 28-36. (ZHOU Gong-dan, SUN Qi-cheng, CUI Peng. Study on the mechanisms of solids segregation in granular debris flows[J]. Journal of Sichuan University(Engineering Science Edition), 2013(1): 28-36. (in Chinese))
[15]	季顺迎, 孙其诚, 严颖. 颗粒物质剪切流动的类固-液转化特性及相变图的建立[J]. 中国科学: 物理学, 力学, 天文学, 2011, 41(9): 1112-1125. (JI Shun-ying, SUN Qi-cheng, YAN Yin. Characteristics in quasi-solid-liquid phase transition of granular shear flow and its phase diagram[J]. Sci Sin Phys Mech Astron, 2011, 41(9): 1112-1125. (in Chinese))
[16]	VALENTINO R, BARLA G, MONTRASIO L. Experimental analysis and micromechanical modelling of dry granular flow and impacts in laboratory flume tests[J]. Rock Mechanics and Rock Engineering, 2008, 41(1): 153-177.
