被动土拱效应对土压力计匹配误差的影响

张海丰; 马保松; 王福芝

doi:10.11779/CJGE201602020

被动土拱效应对土压力计匹配误差的影响 English Version

中国地质大学（武汉）工程学院,湖北武汉 430074

基金项目: 国家自然科学基金面上项目（51074144）

详细信息

作者简介:
张海丰(1989- ),男,硕士研究生,主要从事地质工程和非开挖方面的学习和研究。E-mail: xfhaifeng@126.com。

通讯作者:
马保松

计量
- 文章访问数: 0279
- HTML全文浏览量: 0
- PDF下载量: 0244
出版历程
- 收稿日期: 2015-03-02
- 发布日期: 2016-02-24

Influence of passive soil arching effect on matching error of earth pressure cells

Faculty of Engineering, China University of Geosciences (Wuhan), Wuhan 430074, China

摘要

摘要: 土压力计在量测土体自由场应力时,由于土压力计壳体的刚度远大于周围土体介质的刚度,导致在土压力计壳体圆周的上方产生被动土拱效应。被动土拱效应使土压力计周围土体荷载部分传递到土压力计上,致使土压力计的量测值大于真实值。根据土拱理论推导了被动土拱效应引起的匹配误差计算公式,与传统的匹配误差计算公式相比,新推导公式考虑了土体的内摩擦角和黏聚力,揭示了土体与土压力计的相互作用。提高土压力计外侧土体的密实度,降低土压力计上部土体的密实度可以消减被土拱效应;增大土压力计直径与膜片直径的比值可以减小被动土拱效应对量测误差的影响。
- 土压力计 /
- 量测误差 /
- 被动土拱效应
Abstract: In measuring free-field in-situ stresses, the passive arching effect is aroused over the cylinder surface of earth pressure cells because the stiffness of the pressure cell shell is much greater than that of the surrounding soil. Partial soil weight is transformed to the pressure cells owing to the passive soil arching, resulting in larger measuring values of earth pressure. According to the soil arching theory, an equation for calculating the measuring error induced by the passive soil arching is deduced. Compared with the existing formulas, the new equation includes soil friction angle and cohesion rather than the elastic modulus, and reveals the interaction between the soil and the pressure cell. It is helpful to increase the compactness of the soil surrounding the pressure cells, and to decrease the density of the soil upon the pressure cells for weakening the passive soil arching effect. Moreover, enlarging the diameter ratio of pressure cells to cell diaphragm can diminish the influence of the passive soil arching.
- earth pressure cell /
- measuring error /
- passive soil arching effect

HTML全文

参考文献(21)

[1]	PEATTIE K R, SPARROW R W. The fundamental action of earth pressure cells[J]. Journal of the Mechanics and Physics of Solids, 1954, 2(3): 141-155.
[2]	张胜利. 土压力传感器与土介质相互作用特性分析[D]. 重庆: 西南交通大学, 2010. (ZHANG Sheng-li. Properties analysis on interaction of sensor and soil pressure soil medium[D]. Chongqing: Southwest Jiaotong University, 2010. (in Chinese))
[3]	丁世敬, 赵跃智, 汪恩清. 饱和土有效应力传感器的研制[J]. 传感技术学报, 2008, 21(10): 1704-1707. (DING Shi-jing, ZHAO Yue-zhi, WANG En-qing. Researcher on effective stress sensor in saturated soil[J]. Chinese Journal of Sensors and Actuators, 2008, 21(10): 1704-1707. (in Chinese))
[4]	余尚江, 曾辉. 饱和土有效应力传感器[J]. 传感器技术, 2003, 22(3): 10-13. (YU Shang-jiang, ZENG Hui. Effective stress transducer in saturated soils[J]. Journal of Transducer Technology, 2003, 22(3): 10-13. (in Chinese))
[5]	黄雨, 李光辉, 郑虎. 砂土流滑运动的模型试验研究[J]. 地下空间与工程学报, 2010, 50(6): 65-69. (HUANG Yu, LI Guang-hui, ZHENG Hu. Model tests on sand flow[J]. Chinese Journal of Underground Space and Engineering, 2010, 50(6): 65-69. (in Chinese))
[6]	余尚江, 曾辉. 土中自由场应力与结构表面压力测量的差异[J]. 岩土工程学报, 2003, 25(6): 654-657. (YU Shang-jiang, ZENG Hui. The difference between measurements of stress in soil and pressure on wall-surface[J]. Chinese Journal of Geotechnical Engineering, 2003, 25(6): 654-657. (in Chinese))
[7]	曾辉. 土中结构表面压力测试技术的研究[J]. 土木工程学报, 1998, 31(2): 59-68. (ZENG Hui. Surface pressure measurement for buried structures[J]. China Civil Engineering Journal, 1998, 31(2): 59-68. (in Chinese))
[8]	曾辉, 李欢秋. 岩土中结构表面刚性压力传感器动匹配问题的数值计算研究[J]. 岩石力学与工程学报, 1996, 15(增刊): 559-564. (ZENG Hui, LI Huan-qiu. On dynamic match of rigid pressure gauge mounted on the surface between structure and geo-material by FEM[J]. Chinese Journal of Rock Mechanics and Engineering, 1996, 15(S0): 559-564. (in Chinese))
[9]	曾辉, 余尚江, 陈佳妍. 岩土压力传感器静匹配问题的研究进展[J]. 岩土力学, 2005, 26(7): 1173-1176. (ZENG Hui, YU Shang-jiang, CHEN Jia-yan. Development of research on pressure transducer static matching error in rock and soil[J]. Rock and Soil Mechanics, 2005, 26(7): 1173-1176. (in Chinese))
[10]	曾辉, 余尚江. 岩土压力传感器匹配误差的计算[J]. 岩土力学, 2001, 22(1): 99-106. (ZENG Hui, YU Shang-jiang. The calculation of matching error of rock-soil pressure transducer[J]. Rock and Soil Mechanics, 2001, 22(1): 99-106. (in Chinese))
[11]	LABUZ J F, THEROUX B. Laboratory calibration of earth pressure cells[J]. Geotechnical Testing Journal, 2005, 28(2): 188-196.
[12]	TALESNICK M L, RINGEL M, AVRAHAM R. Measurement of contact soil pressure in physical modelling of soil-structure interaction[J]. International Journal of Physical Modelling in Geotechnics, 2014, 14(1): 3-12.
[13]	TALESNICK M. Measuring soil pressure within a soil mass[J]. Canadian Geotechnical Journal, 2013, 50(7): 716-722.
[14]	PARDO G S, SÁEZ E. Experimental and numerical study of arching soil effect in coarse sand[J]. Computers and Geotechnics, 2014, 57: 75-84.
[15]	MARSTON A, ANDERSON A O. The theory of loads on pipes in ditches: and tests of cement and clay drain tile and sewer pipe[R]. Ames: Iowa State College of Agriculture and Mechanic Arts, 1913.
[16]	TERZAGHI K. Theoretical soil mechanics[M]. New York: Wiley, 1943.
[17]	KOUTSABELOULIS N C, GRIFFITHS D V. Numerical modelling of the trap door problem[J]. Géotechnique, 1989, 39(1): 77-89.
[18]	COSTA Y D, ZORNBERG J G, BUENO B S, et al. Failure mechanisms in sand over a deep active trapdoor[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(11): 1741-1753.
[19]	TIEN H J S. The arching mechanism on the micro level utilizing photoelasticity modeling[D]. Lowell: University of Massachusetts, 2001.
[20]	陈仲颐. 土力学[M]. 北京: 清华大学出版社, 1994. (CHEN Zhong-yi. Soil mechanics[M]. Beijing: Tsinghua University Press, 1994. (in Chinese))
[21]	IGLESIA G R, EINSTEIN H H, WHITMAN R V. Validation of centrifuge model scaling for soil systems via trapdoor tests[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2011, 137(11): 1075-1089.
