含砂垫层地基二维固结自由应变解

雷国辉; 李赞; 徐梨丹

doi:10.11779/CJGE201602001

含砂垫层地基二维固结自由应变解 English Version

雷国辉^{1, 2},
李赞^{1, 2},
徐梨丹^{1, 2}

1. 河海大学岩土力学与堤坝工程教育部重点实验室,江苏南京 210098; 2. 河海大学岩土工程科学研究所,江苏南京 210098

基金项目: 国家自然科学基金项目（51278171,51578213）; 中央高校; 基本科研业务费专项资金项目（2015B06014）

详细信息

作者简介:
雷国辉（1972- ）,男,江西丰城人,教授,从事土力学与地基基础工程教学与科研工作。E-mail: leiguohui@hhu.edu.cn。

计量
- 文章访问数: 478
- HTML全文浏览量: 1
- PDF下载量: 526
出版历程
- 收稿日期: 2015-01-31
- 发布日期: 2016-02-24

Free-strain solutions for two-dimensional consolidation with sand blankets

LEI Guo-hui^{1, 2},
LI Zan^{1, 2},
XU Li-dan^{1, 2}

1. Key Laboratory of Geomechanics and Embankment Engineering of Ministry of Education, Hohai University, Nanjing 210098, China; 2. Geotechnical Research Institute, Hohai University, Nanjing 210098, China

摘要

摘要: 为分析含水平向排水砂垫层地基的固结问题,针对平面应变条件下的二维自由应变固结微分方程,分别考虑待固结土体顶底双面和顶面单面含有砂垫层的工况,采用分离变量法,推求得到了超静孔压和整体平均固结度的显式解析解答,并与有限元法的计算结果对比,验证了其正确性。同时,分析了待固结土体不同渗透系数、土层宽度和厚度条件下,砂垫层渗透系数和厚度对其固结的影响。结果表明：砂垫层渗透系数与待固结土层渗透系数的比值是砂垫层设计中的关键参数。要使砂垫层接近或达到完全透水边界条件,该比值应介于10⁴~10⁵之间,待固结土层越宽、渗透系数越小,所要求的比值越大。
- 砂垫层 /
- 水平向排水体 /
- 自由应变 /
- 不完全透水边界 /
- 渗透系数
Abstract: To analyze the consolidation with horizontal sand drainage blankets, the partial differential equation for two-dimensional free-strain consolidation under plane strain conditions is solved. Two cases are considered. One is with sand blankets on both the top and the bottom surfaces of the consolidating soil, and the other is with a single sand blanket on the top surface of the consolidating soil. By using the method of separation of variables, explicitly expressed analytical solutions are obtained for calculating the excess pore-water pressure and the overall average degree of consolidation. Their validity is verified by comparing the calculated results obtained from the proposed solutions with those from finite element analyses. The effects of the hydraulic conductivity and thickness of sand blanket on consolidation are investigated for the consolidating soil with various hydraulic conductivities, widths and thicknesses. It is shown that the key parameter for the design of sand blanket is the ratio of the hydraulic conductivity of sand blanket to that of consolidating soil. For the sand blanket close to or reaching a fully drained boundary condition, this ratio is required to be within 10⁴~10⁵, with higher values for the consolidating soil with larger width or lower hydraulic conductivity.
- sand blanket /
- horizontal drainage /
- free strain /
- impeded drainage boundary /
- hydraulic conductivity

HTML全文

参考文献(15)

[1]	LEI G H, ZHENG Q, NG C W W, et al. An analytical solution for consolidation with vertical drains under multi-ramp loading[J]. Géotechnique, 2015, 65(7): 531-547.
[2]	郭霄, 谢康和, 吕文晓, 等. 井阻随深度和时间变化的竖井地基固结解析解[J]. 岩土工程学报, 2015, 37(6): 996-1001. (GUO Xiao, XIE Kang-he LÜ Wen-xiao, et al. Analytical solutions for consolidation by vertical drains with variation of well resistance with depth and time[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(6): 996-1001. (in Chinese))
[3]	郭彪, 龚晓南, 卢萌盟, 等. 真空联合堆载预压下竖井地基固结解析解[J]. 岩土工程学报, 2013, 35(6): 1045-1054. (GUO Biao, GONG Xiao-nan, LU Meng-meng, et al. Analytical solution for consolidation of vertical drains by vacuum-surcharge preloading[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1045-1054. (in Chinese))
[4]	雷国辉, 许波, 张旭东. 堆载预压径竖向固结等体积应变解答[J]. 岩土工程学报, 2013, 35(1): 76-84. (LEI Guo-hui, XU Bo, ZHANG Xu-dong. Equal volumetric strain solutions for radial and vertical consolidation with vertical drains under surcharge preloading[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(1): 76-84. (in Chinese))
[5]	许波, 雷国辉, 郑强, 等. 考虑涂抹区压缩及渗透系数变化的堆载预压固结解[J]. 岩土力学, 2014, 35(6): 1607-1616. (XU Bo, LEI Guo-hui, ZHENG Qiang, et al. Solution of consolidation by surcharge preloading considering compressibility and varying hydraulic conductivities in smear zone[J]. Rock and Soil Mechanics, 2014, 35(6): 1607-1616. (in Chinese))
[6]	GIBSON R E, SHEFFORD G C. The efficiency of horizontal drainage layers for accelerating consolidation of clay embankments[J]. Géotechnique, 1968, 18(3): 327-335.
[7]	TAN S A, LIANG K M, YONG K Y, et al. Drainage efficiency of sand layer in layered clay-sand reclamation[J]. Journal of Geotechnical Engineering, ASCE, 1992, 118(2): 209-228.
[8]	JANG W Y, MIMURA M. Effect of permeability and compressibility of sandwiched gravelly sand layers on subsequent settlement of Pleistocene deposits[J]. Soils and Foundations, 2005, 45(6): 111-119.
[9]	CHAI J C, MIURA N. Investigation of factors affecting vertical drain behavior[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 1999, 125(3): 216-226.
[10]	李玲玲, 陈振华, 王立忠. 软弱滩涂上堤基细砂垫层的适用性研究[J]. 岩石力学与工程学报, 2009, 28(12): 2577-2584. (LI Ling-ling, CHEN Zhen-hua, WANG Li-zhong. Applicability of fine sand cushions for embankments on soft foundation[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(12): 2577-2584. (in Chinese))
[11]	王路军, 李锐, 卢永金. 淤泥堤基上粉细砂排水垫层特性研究[J]. 岩土力学, 2012, 33(增刊1): 129-135. (WANG Lu-jun, LI Rui, LU Yong-jin. Study of characteristics of silty sand drainage mat of sea dyke on muck foundation[J]. Rock and Soil Mechanics, 2012, 33(S1): 129-135. (in Chinese))
[12]	MESRI G, FUNK J R. Settlement of the Kansai International Airport Islands[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2015, 141(2): 04014102.
[13]	卢廷浩. 土力学[M]. 2版. 南京: 河海大学出版社, 2005. (LU Ting-hao. Soil mechanics[M]. 2nd ed. Nanjing: Hohai University Press, 2005. (in Chinese))
[14]	TERZAGHI K. Theoretical soil mechanics[M]. New York: John Wiley & Sons, Inc., 1943.
[15]	TAVENAS F, JEAN P, LEBLOND P, et al. The permeability of natural soft clays. part 2: Permeability characteristics[J]. Canadian Geotechnical Journal, 1983, 20(4): 645-660.
