特大断面隧道分步施工动态压力拱分析研究

郑康成; 丁文其; 金威; 罗云

doi:10.11779/CJGE2015S1015

特大断面隧道分步施工动态压力拱分析研究 English Version

郑康成^{1, 2},
丁文其^{1, 2},
金威^{1, 2},
罗云³

1. 同济大学土木工程学院地下建筑与工程系,上海 200092; 2. 同济大学岩土及地下工程教育部重点实验室,上海 200092; 3. 深圳市交通公用设施建设中心,广东深圳 518000

基金项目: 国家“863”计划项目（2012AA112502）; 国家“973”计划项目（2014CB046905）

详细信息

作者简介:
郑康成(1992- ),男,硕士研究生,主要从事隧道及地下建筑方向研究。

计量
- 文章访问数: 319
- HTML全文浏览量: 5
- PDF下载量: 447
出版历程
- 收稿日期: 2015-03-25
- 发布日期: 2015-07-24

Experimental and numerical study on staged construction pressure arch of super large section tunnel

ZHENG Kang-cheng^{1, 2},
DING Wen-qi^{1, 2},
JIN Wei^{1, 2},
LUO Yun³

1. Department of Geotechnical Engineering, College of Civil Engineering, Tongji University, Shanghai 200092, China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China; 3. Shenzhen Public Traffic Facilities Construction Center, Shenzhen 518000, China

摘要

摘要: 特大断面隧道的建设越来越多,传统规范荷载计算方法未考虑特大断面隧道施工的实际情况,计算结果偏大。在确定隧道压力拱判别方法的基础上,采用大型二维模型试验探究开挖过程中特大断面隧道压力拱的动态发展。从开挖洞周应力随开挖步变化的情况可以看出,大断面隧道压力拱是随着开挖步分区域、分阶段形成的,并采用数值分析对试验中的规律进行验证总结。为得到支护对压力拱发展的限制作用,采用二维精细化数值模型,模拟施工工况,探究支护对限制压力拱扩展的作用,得到大断面隧道复杂施工过程下压力拱的动态变化、压力拱高度折减系数,用于指导设计计算。
- 特大断面隧道 /
- 动态压力拱 /
- 模型试验 /
- 数值分析 /
- 支护作用
Abstract: There are more and more super large section tunnels. However, the calculated results by the traditional load calculation method are much larger than the real ones without considering the actual construction steps and support. Based on the method for discriminating the tunnel pressure arch, the dynamic development of pressure arch during the process of construction is studied by utilizing the large-scale two-dimensional model tests. It can be seen from the stress change around the hole that the pressure arch of large section tunnel forms in different regions by stages, along with the excavation steps. Then numerical analysis is conducted to verify and summarize the law found in the model tests. To study the restriction effect on pressure arch of support, a fine numerical model is established to simulate the construction conditions. The restriction effect on pressure arch of support is analyzed. Finally, the dynamic change of pressure arch and the reduction coefficient of arch height, which can be adopted to guide the design and calculation, are obtained.
- super large section tunnel /
- dynamic pressure arch /
- model test /
- numerical analysis /
- support action

HTML全文

参考文献(7)

[1]	曲海锋. 扁平特大断面公路隧道荷载模式及应用研究[D].上海: 同济大学, 2007. (QU Hai-feng. Study on load mode of road tunnel with extra-large cross-section and low flat-ratio and Its application[D]. Shanghai: Tongji University, 2007. (in Chinese))
[2]	丁文其, 王晓形, 朱合华, 等. 连拱隧道设计荷载的确定方法[J]. 中国公路学报, 2007, 20(5): 78-82. (DING Wen-qi, WANG Xiao-xing, ZHU He-hua, et al. Defining method for designing load of multi-arch tunnel[J]. China Journal of Highway and Transport, 2007, 20(5): 78-82. (in Chinese))
[3]	李俊鹏. 开挖过程中隧道围岩应力释放规律及软岩支护时机研究[D]. 西安: 西安理工大学, 2007. (LI Jun-peng. Rules of stress release in tunnel during excavation and the opportunity of support in soft rock[D]. Xi'an: Xi'an University of Technology, 2007. (in Chinese))
[4]	李奎. 水平层状隧道围岩压力拱理论研究[D]. 成都: 西南交通大学, 2005. (LI Kui. Pressure arch theory study of horizontal bedded tunnel surrounding rock[D]. Chengdu: Southwest Jiaotong University, 2005. (in Chinese))
[5]	梁晓丹, 刘刚, 赵坚. 地下工程压力拱拱体的确定与成拱分析[J]. 河海大学学报(自然科学版), 2005, 33(3): 314-317. (LIANG Xiao-dan, LIU Gang, ZHAO Jian. Definition and analysis of arching action in underground rock engineering[J]. Journal of Hohai University (Natural Sciences), 2005, 33(3): 314-317. (in Chinese))
[6]	黄伦海, 刘伟, 刘新荣. 单洞四车道公路隧道开挖的模型试验[J]. 地下空间, 2004, 24(4): 465-474. (HUANG Lun-hai, LIU Wei, LIU Xin-rong. Model test on single four-lane highway tunnel excavation[J]. Underground Space, 2004, 24(4): 465-474. (in Chinese))
[7]	朱维申, 张玉军, 任伟中, 等. 系统锚杆对三峡船闸高边坡岩体加固作用的块体相似模型试验研究[J]. 岩土力学, 1996, 17(2): 1-6. (ZHU Wei-shen, ZHANG Yu-jun, REN Wei-zhong, et al. Similar model block tests for reinforcing effects of systematic bolts on rock mass of high slope of three gorges flight lock[J] Rock and Soil Mechanics, 1996, 17(2): 1-6. (in Chinese))
