三轴循环荷载下页岩变形及破坏特征试验研究

魏元龙, 杨春和, 郭印同, 刘伟, 王磊, 徐敬宾

魏元龙, 杨春和, 郭印同, 刘伟, 王磊, 徐敬宾. 三轴循环荷载下页岩变形及破坏特征试验研究[J]. 岩土工程学报, 2015, 37(12): 2262-2271. DOI: 10.11779/CJGE201512016
引用本文: 魏元龙, 杨春和, 郭印同, 刘伟, 王磊, 徐敬宾. 三轴循环荷载下页岩变形及破坏特征试验研究[J]. 岩土工程学报, 2015, 37(12): 2262-2271. DOI: 10.11779/CJGE201512016
shu
WEI Yuan-long, YANG Chun-he, GUO Yin-tong, LIU Wei, WANG Lei, XU Jin-bing. Experimental research on deformation and fracture characteristics of shale under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(12): 2262-2271. DOI: 10.11779/CJGE201512016
Citation: WEI Yuan-long, YANG Chun-he, GUO Yin-tong, LIU Wei, WANG Lei, XU Jin-bing. Experimental research on deformation and fracture characteristics of shale under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(12): 2262-2271. DOI: 10.11779/CJGE201512016
shu

三轴循环荷载下页岩变形及破坏特征试验研究  English Version

  • 1. 重庆大学煤矿灾害动力学与控制国家重点实验室,重庆 400044;
    2. 中国科学院武汉岩土力学研究所岩土力学与工程国家重点实验室,湖北 武汉 430071

基金项目: 国家高技术研究发展计划（“863”计划）项目（2013AA064800）; 科技计划项目（2012DFA60760）
详细信息
    作者简介:

    魏元龙(1988- ),男,博士研究生,主要从事页岩水力压裂中的岩石力学问题研究。E-mail: at6wyl@163.com。

Experimental research on deformation and fracture characteristics of shale under cyclic loading

  • 1. State Key Laboratory of Coal Mine Disaster Dynamics and Control, Chongqing University, Chongqing 400044, China;
    2. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China

摘要

    摘要
  • 摘要: 前期工作已经研究了含裂隙页岩在单轴循环荷载下的变形及破裂特征，为进一步认清围压与循环荷载耦合作用下的变形及破坏特征，利用MTS815.03岩石刚性压力机展开了对含裂隙页岩的三轴循环加卸载试验研究。试验结果表明：在三轴循环荷载下，含裂隙页岩的破坏形式主要为混合破坏，呈现出拉剪贯通模式；随围压逐渐增大，页岩的峰值强度呈线性增大，完整页岩经11周加卸载循环后，峰值强度增大9.98%～25.03%；而含裂隙页岩经15周加卸载循环后，峰值强度增大1.47%～6.98%；含裂隙页岩在同一循环内的弹性模量大于变形模量，卸载弹性模量大于加载弹性模量，卸载变形模量大于加载变形模量，并且损伤面积系数F越大，卸载弹性模量与加载弹性模量的差值也越大；随循环加卸载次数逐渐增加，加载变形模量与卸载变形模量呈先增大后单调减小的规律，加载弹性模量与卸载弹性模量表现出先增大，后逐渐呈“波浪式”减小的规律，剧烈波动的弹性模量是内部结构不断发生局部调整的有效证据。该研究为揭示在围压与循环荷载耦合作用下含裂隙页岩破坏形成复杂裂缝网的发展机理提供了有益参考。
    Abstract: The previous researches have studied the deformation and fracture characteristics of shale containing natural cracks subjected to uniaxial compression. In order to further indicate how the deformation and fracture characteristics are influenced under coupling effect of confining pressure and cyclic loading, the equipment of MTS815.03 is employed to conduct loading and unloading cyclic triaxial compression tests. The experimental results show that under triaxial cyclic loading, the main failure mode of the shale samples containing natural cracks is a mixed failure, performing tensile-shear propagating mode, and having at least one tensile crack propagating the natural crack for each sample. With the gradually increasing confining pressure, the peak strength rises linearly. For the entire shale sample already subjected to 11 cycles of loading-unloading, the peak strength increases by 9.98%~25.03%; whereas for the shale sample with crack already subjected to 15 cycles, the peak strength increases by only 1.47%~6.98%. For the sample with crack under the same cycle loading, the elastic modulus is larger than the deformation modulus, the unloading elastic modulus is larger than the loading elastic modulus, and the unloading deforamtion modulus is larger than the loading deformation modulus. Simultaneously, the larger the damage-area coefficient F, the larger the difference between the unloading elastic modulus and the loading elastic modulus. With the increase of the cyclic times, the loading deformation modulus and the unloading deformation modulus firstly increase and then monotonously decrease; whereas, the elastic moduli of both loading and unloading exhibit increasing initially then decreasing gradually with wave-shape. The serious variant of elastic modulus is the direct evidence that the inner structure coordinates in local locations. The research may provide constructive references for the mechanical investigation of crack propagation to form complex crack net.
    • HTML全文
    • 参考文献(12)
  • [1] CURTIS J B. Fractured shale-gas system[J]. AAPG Bulletin, 2002, 86(11): 1921-1938.
    [2] 杨圣奇, 戴永浩, 韩立军, 等. 断续预制裂隙脆性大理岩变形破坏特性单轴压缩试验研究[J]. 岩石力学与工程学报, 2009, 28(12): 2391-2404. (YANG Sheng-qi, DAI Yong-hao, HAN Li-jun, et al. Uniaxial compression experimental research on deformation and failure properties of brittle marble specimen with pre-existing fissures[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28 (12): 2391-2404. (in Chinese))
    [3] 李银平, 王元汉, 陈龙珠, 等. 含预制裂隙大理岩的压剪试验分析[J]. 岩土工程学报, 2004, 26(1): 120-124. (LI Yin-ping, WANG Yuan-han, CHEN Long-zhu, et al. Experimental research on pre-existing cracks in marble under compression[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(1): 120-124. (in Chinese))
    [4] 林 鹏, 周雅能, 李子昌, 等. 含三维预制单裂隙缺陷岩石破坏试验研究[J]. 岩石力学与工程学报, 2008, 27(增刊2): 3882-3887. (LIN Peng, ZHOU Ya-neng, LI Zi-chang, et al. Experimental study on failure behavior of rock containing three dimensional single pre-existing flaw[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(S2): 3882-3887. (in Chinese))
    [5] 徐建光,张 平,李 宁,等. 循环荷载下断续裂隙岩体的变形特性[J]. 岩土工程学报, 2008, 30(6): 802-806. (XU Jian-guang, ZHANG Ping, LI Ning, et al. Deformation properties of rock mass with intermittent cracks under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(6): 802-806. (in Chinese))
    [6] 胡盛斌, 邓 建, 马春德, 等. 循环荷载作用下含缺陷岩石破坏特征试验研究[J]. 岩石力学与工程学报, 2009, 28(12): 2490-2495. (HU Sheng-bin, DENG Jian, MA Chun-de, et al. Experimental study of failure characteristics of rock containing flaw under cyclic loading[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(12): 2490-2495. (in Chinese))
    [7] KACHANOV L M. On the time to failure during creep, Izv[J]. AN SSSR, Otd Tekhn Nank, 1958, 8: 26-31.
    [8] RABOTNOV Y N. On the equation of state for creep[J]. Progress in Applied Mechanics, 1963: 307-315.
    [9] 魏元龙, 杨春和, 郭印同, 等. 单轴循环荷载下含天然裂隙脆性页岩变形及破裂特征试验研究[J]. 岩土力学, 2015, 36(6): 1649-1658. (WEI Yuan-long, YANG Chun-he, GUO Ying-tong, et al. Experimental research on deformation and fracture characteristics of brittle shale under uniaxial cyclic loading[J]. Rock and Soil Mechanics, 2015, 36(6): 1649-1658. (in Chinese))
    [10] SL 264—2001水利水电工程岩石试验规程[S]. 2001. (SL 264—2001 Specifications for testes in water conservancy and hydroelectric engineering[S]. 2001. (in Chinese))
    [11] 尤明庆, 苏承东. 大理岩试样循环加载强化作用的实验研究[J]. 固体力学学报, 2008, 29(1): 66-75. (YOU Ming-qing, SU Cheng-dong. Experimental study on strengthening of marble specimen in cyclic loading of uniaxial or pseudo- triaxial compression[J]. Chinese Journal of Solid Mechanics, 2008, 29(1): 66-75. (in Chinese))
    [12] 徐速超, 冯夏庭, 陈炳瑞, 等. 矽卡岩单轴循环加卸载试验及声发射特性研究[J]. 岩土力学, 2009, 30(10): 2929-2934. (XU Su-chao, FENG Xia-ting, CHEN Bing-rui, et al. Experimental study of skarn under uniaxial cyclic loading and unloading test and acoustic emission characteristics[J]. Rock and Soil Mechanics, 2009, 30(10): 2929-2934. (in Chinese))
