移动交通荷载下公路软土地基的沉降计算

魏星; 王刚

doi:10.11779/CJGE201512011

移动交通荷载下公路软土地基的沉降计算 English Version

魏星¹,
王刚²

1. 西南交通大学土木工程学院,四川成都 610031;
2. 重庆大学土木工程学院,重庆 400044

基金项目: 国家自然科学基金项目（51209179）; 水沙科学与水利水电工程国家重点实验室开放研究基金课题（sklhse-2015-D-02）

详细信息

作者简介:
魏星（1977- ）,女,博士,副教授,主要从事土的本构理论、数值分析等方面的研究工作。E-mail: weixinghl@163.com。

计量
- 文章访问数: 420
- HTML全文浏览量: 9
- PDF下载量: 458
出版历程
- 收稿日期: 2014-08-22
- 发布日期: 2015-12-19

Predicting settlement of road on soft subsoil induced by moving traffic load

WEI Xing¹,
WANG Gang²

1. School of Civil Engineering, Southwest Jiaotong University, Chengdu 610031, China;
2. School of Civil Engineering, Chongqing University, Chongqing 400044, China

摘要

摘要: 交通荷载是一种移动的重复作用荷载,在地基中产生的附加动应力的路径和大小与移动速度密切相关,目前的简化算法中忽略了移动速度的影响。通过数值积分算法得到了交通荷载在地基中引起的附加动应力,探讨了移动荷载下地基中应力路径特点及其与荷载移动速度的关系,提出在拟静力计算的地基附加应力结果上乘以荷载速度效应的放大系数的简化近似方法,给出了便于工程应用的放大系数的实用图表。根据移动荷载在地基中产生的附加动应力路径的特点,提出了一个适用于循环心形应力路径的饱和软土残余变形的经验模型,通过对已有试验成果的模拟,初步验证了所提模型的有效性。在此基础上,建议了一种考虑荷载移动速度影响的路基沉降实用算法。以Saga机场高速公路的沉降计算为例,初步探讨了不同车速比下的公路沉降发展的特点和规律。
- 移动车辆荷载 /
- 循环心形路径 /
- 移动速度 /
- 饱和黏土 /
- 残余变形
Abstract: The acting position of traffic load moves on road surface with certain velocity. The induced stresses in subsoil imposed by traffic load depend on the moving velocity of load, whereas the simplified procedures nowadays used for induced stresses calculation by traffic load have ignored this velocity effect. The paper studies the long-term settlement of road on soft subsoil with emphasis on the velocity effect of moving traffic load. The numerical integration method is employed to get the induced stresses in the elastic half-space by a surficial moving point load with uniform velocity. By analyzing the characteristics of the induced stresses, a practical procedure is proposed for calculating traffic-load-induced stresses in road subsoil, which combines the results of commonly-used pseudo method with two amplification coefficients accounting for velocity effect. In the other aspect, an empirical model is proposed for quantifying the accumulation of residual strain during the long-term repeated cycles of heart-shaped stress paths, a typical stress path-induced by surficial moving load. The proposed empirical model is validated by the simulated test results. Once the induced stresses and residual strain of the subsoil can be calculated, the road settlement prediction is straightforward following the layer-wise summation procedure. The Saga airport road is taken as an example to analyze the influence of vehicle moving speed on long-term settlements.
- moving wheel load /
- heart-shaped stress path /
- moving velocity /
- saturated clay /
- residual strain

HTML全文

参考文献(20)

[1]	CHAI J C, MIURA N. Traffic-load-induced permanent deformation of road on soft subsoil[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2002, 128(11): 907-916.
[2]	SAKAI A, SAMANG L AND MIURA N. Partially-drained cyclic behavior and its application to the settlement of a low embankment road on silty-clay[J]. Soils and Foundations, 2003, 43(1): 33-46.
[3]	魏星, 黄茂松. 交通荷载作用下公路软土地基长期沉降的计算[J]. 岩土力学, 2009, 30(11): 3342-3346. (WEI Xing, HUANG Mao-song. A simple method to predict trafi-cload-induced permanent settlement of road on soft subsoil[J]. Rock and Soil Mechanics, 2009, 30(11): 3342-3346. (in Chinese))
[4]	魏星, 王刚, 余志灵. 交通荷载下软土地基长期沉降的有限元法[J]. 岩土力学, 2010, 31(6): 2011-2015. (WEI Xing, WANG Gang, YU Zhi-ling. FEM of traffic-load-induced settlement of road on soft clay[J]. Rock and Soil Mechanics, 2010, 31(6): 2011-2015. (in Chinese))
[5]	汤连生, 林沛元, 吴科, 等. 单点动载下路基动应力状态及有效作用半径分析[J]. 岩石力学与工程学报, 2011, 30(增刊2): 4056-4063. (TANG Lian-sheng, LIN Pei-yuan, WU Ke, et al. Analysis of dynamic stress state and effective working radius in subgrade under concentrated load[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(S2): 4056-4063. (in Chinese))
[6]	EASON G. The stresses produced in a semi-infinite solid by a moving surface force[J]. International Journal of Mechanics A: Solids, 1965, 2: 581-609.
[7]	LEKARP F, ISACSSON U, DAWSON A. State of the art. I : Resilient response of unbound aggregates[J]. Journal of Transportation Engineering, ASCE, 2000, 126(1): 66-75.
[8]	POWRIE W, YANG L A, CLAYTON C R I. Stress changes in the ground below ballasted railway track during train passage[J]. Journal of Rail and Rapid Transit, 2007, 221(2): 247-262.
[9]	GRABE P J, CLAYTON C R I. Effects of principal stress rotation on permanent deformation in rail track foundations[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(4): 555-565.
[10]	ISHIKAWA T, SEKINE E, MIURA S. Cyclic deformation of granular material subjected to moving-wheel loads[J]. Canadian Geotechnical Journal, 2011, 48(5): 691-703.
[11]	蒋建群, 周华飞, 张土乔. 弹性半空间体在移动集中荷载作用下的稳态响应[J]. 岩土工程学报, 2004, 26(4): 440-444. (JIANG Jian-qun, ZHOU Hua-fei, ZHANG Tu-qiao. Steady-state response of an elastic half-space under a moving point load[J]. Chinese Journal of Geotechnical Engineering, 2004,26(4): 440-444. (in Chinese))
[12]	丁智, 葛国宝, 魏新江, 等. 地铁列车运营引起的地基土应力状态变化分析[J]. 岩土工程学报, 2013, 35(增刊2): 647-651. (DING Zhi, GE Guo-bao, WEI Xin-jiang, et al. Variation of stress state of foundation soils induced by running subway[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(S2): 647-651. (in Chinese))
[13]	王常晶, 陈云敏. 列车移动荷载在地基中引起的主应力轴旋转[J]. 浙江大学学报(工学版), 2010, 44(5): 950-954. (WANG Chang-jing, CHEN Yun-min. Principal stress axesrotation in ground induced by train moving load [J]. Journal of Zhejiang University (Engineering Science), 2010, 44(5): 950-954. (in Chinese))
[14]	LI D, SELIG E T. Cumulative plastic deformation for fine grained subgrade soils[J]. Journal of Geotechnical Engineering, 1996, 122(12): 1006-1013.
[15]	黄茂松, 李进军, 李兴照. 饱和软黏土的不排水循环累积变形特性[J]. 岩土工程学报, 2006, 28(7): 891-895. (HUANG Mao-song, LI Jin-jun, LI Xing-zhao. Cumulative deformation behaviour of soft clay in cyclic undrainedtests[J]. Chinese Journal of Geotechuical Engineering, 2006, 28(7): 891-895. (in Chinese))
[16]	HIGHT D W, GENS A, SYMES M J. The development of a new hollow cylinder apparatus for investigating the effects of principal stress rotation in soils[J]. Géotechnique, 1983, 33(4): 355-383.
[17]	沈扬, 周建, 龚晓南. 空心圆柱仪（HCA）模拟恒定围压下主应力轴循环旋转应力路径能力分析[J]. 岩土工程学报, 2006, 28(3): 281-287. (SHEN Yang, ZHOU Jian, GONG Xiao-nan. Analysis on ability of HCA to imitate cyclic principal stress rotation under constant confining pressure[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(3): 281-287. (in Chinese))
[18]	王常晶, 温日琨, 陈云敏. 交通荷载引起的主应力轴旋转室内试验模拟探讨[J]. 岩土力学, 2008, 29(12): 3412-3416. (WANG Chang-jing, WEN Ri-kun, CHEN Yun-min. Discussion on laboratory test simulation of principal stress axes rotation induced by traffic loading[J]. Rock and Soil Mechanics, 2008, 29(12): 3412-3416. (in Chinese))
[19]	郭林. 复杂应力路径下饱和软粘土静动力特性试验研究[D]. 杭州: 浙江大学, 2013. (GUO Lin. Experimental study on the static and cyclic behavior of saturated soft clay under complex stress path[D]. Hangzhou: Zhejiang University, 2013. (in Chinese))
[20]	钱建固, 王永刚, 张甲峰, 等. 交通动载下饱和软黏土累计变形的不排水循环扭剪试验[J]. 岩土工程学报, 2013, 35(10): 1790-1798. (QIAN Jian-gu, WANG Yong-gang, ZHANG Jia-feng, et al. Undrained cyclic torsion shear tests on permanent deformation responses of soft saturated clay to traffic loadings[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(10): 1790-1798. (in Chinese))
