基于膨润土微观结构确定土水特征曲线的残余含水率

朱赞成, 孙德安, 王小岗, 陈雰, 王古平

朱赞成, 孙德安, 王小岗, 陈雰, 王古平. 基于膨润土微观结构确定土水特征曲线的残余含水率[J]. 岩土工程学报, 2015, 37(7): 1211-1217. DOI: 10.11779/CJGE201507006
引用本文: 朱赞成, 孙德安, 王小岗, 陈雰, 王古平. 基于膨润土微观结构确定土水特征曲线的残余含水率[J]. 岩土工程学报, 2015, 37(7): 1211-1217. DOI: 10.11779/CJGE201507006
ZHU Zan-cheng, SUN De-an, WANG Xiao-gang, CHEN Fen, WANG Gu-ping. Determination of residual water content in SWCC based on microscopic structure of bentonite[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(7): 1211-1217. DOI: 10.11779/CJGE201507006
Citation: ZHU Zan-cheng, SUN De-an, WANG Xiao-gang, CHEN Fen, WANG Gu-ping. Determination of residual water content in SWCC based on microscopic structure of bentonite[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(7): 1211-1217. DOI: 10.11779/CJGE201507006

基于膨润土微观结构确定土水特征曲线的残余含水率  English Version

基金项目: 国家自然科学基金项目(11272194); 浙江省公益性技术应; 用研究计划项目(2014C37085); 浙江省自然科学基金项目(Y15E080014)
详细信息
    作者简介:

    朱赞成(1977- ),男,讲师,博士研究生,主要从事非饱和土等方面的科研和教学。E-mail: zancheng_77@163.com。

Determination of residual water content in SWCC based on microscopic structure of bentonite

  • 摘要: 根据蒙脱石层间水化微观结构,建立了蒙脱石水化后的含水率计算公式,并认为蒙脱石发生第1层水化时的含水率即为残余含水率。用4种膨润土土水特征曲线试验数据,分析探讨了考虑不同初始干密度和同一初始干密度下不同温度环境等因素对膨润土土水特征曲线的残余含水率影响。研究结果表明,膨润土的残余含水率与膨润土的比表面积、水膜厚度以及水膜密度成正比,而与膨润土的初始干密度和温度无关。通过实测和计算残余含水率比较,验证了该公式的合理性。
    Abstract: According to the theory of the interlamellar hydration microscopic structure of montmorillonite proposed by Forslind, a formula for calculating the water content of montmorillonite is established after its hydration. When the montmorillonite absorbs only monolayer of water molecules, the water content is considered as the residual water content. The influences of the initial dry density and temperature on the residual water content of bentonite are investigated by using measured soil-water characteristic curves of four different kinds of bentonites. The results show that the residual water content of bentonite is proportional to the specific surface area of bentonite, the thickness and the density of hydrated layer of water molecules, regardless of the initial density and temperature. The comparison between the measured and predicted residual water contents shows that the proposed formula is reasonable.
  • [1] ROMERO E, GENS A, LLORET A. Suction effects on a compacted clay under non-isothermal conditions[J]. Géotechnique, 2003, 53(1): 65-81.
    [2] VILLAR M V, LLORET A. Influence of temperature on the hydro-mechanical behaviour of a compacted bentonite[J]. Applied Clay Science, 2004, 26: 337-350.
    [3] HOFFMANN C, ALONSO E E, ROMERO E. Hydro- mechanical behaviour of bentonite pellet mixtures[J]. Physics and Chemistry of the Earth, 2007, 32: 832-849.
    [4] JACINTO A C, VILLAR M V, GÓMEZ-ESPINA R, et al. Adaptation of the van Genuchten expression to the effects of temperature and density for compacted bentonites[J]. Applied Clay Science, 2009, 42: 575-582.
    [5] 叶为民, 钱丽鑫, 陈 宝, 等. 高压实高庙子膨润土的微观结构特征[J]. 同济大学学报(自然科学版), 2009, 37(1): 31-35. (YE Wei-min, QIAN Li-xin, CHEN Bao, et al. Characteristics of micro-structure of densely compacted gaomiaozi bentonite [J]. Journal of Tongji University (Natural Science), 2009, 37(1): 31-35. (in Chinese))
    [6] 孙德安, 孟德林, 孙文静, 等. 两种膨润土的土水特征曲线[J]. 岩土力学, 2011, 32(4): 1293-1298. (SUN De-an, MENG De-lin, SUN Wen-jing, et al. Soil-water characteristic curves of two bentonites[J]. Rock and Soil Mechanics, 2011, 32(4): 1293-1298. (in Chinese))
    [7] 张虎元, 张 明, 崔素丽, 等. 混合型缓冲回填材料土水特征曲线测试与修正[J]. 岩石力学与工程学报, 2011, 30(2): 382-390. (ZHANG Hu-yuan, ZHANG Ming, CUI Su-li, et al. Determination and modification of soil-water characteristic curves of bentonite-sand mixtures as high-level waste backfill/buffer material[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(2): 382-390. (in Chinese))
    [8] 秦 冰, 陈正汉, 孙发鑫, 等. 高吸力下持水曲线的温度效应及其吸附热力学模型[J]. 岩石力学与工程学报, 2012, 34(10): 1877-1886. (QIN Bing, CHEN Zheng-han, SUN Fa-xin, et al. Temperature effect on water retention curve under high suction and its modeling based on thermodynamics of sorption[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 34(10): 1877-1886. (in Chinese))
    [9] YE W M, WAN M, CHEN B, et al. Temperature effects on the unsaturated permeability of the densely compacted GMZ01 bentonite under confined conditions[J]. Engineering Geology, 2012, 126: 1-7.
    [10] BROOKS R, COREY A. Hydraulic properties of porous media. Colorado State University, Forty Collins, Hydrology Paper, 1964.
    [11] VAN GENUCHTEN M T H. A closed form equation predicting the hydraulic conductivity of unsaturated soils[J]. Soil Science Society of America Journal, 1980, 44: 892-898.
    [12] LUCKNER L, VAN GENUCHTEN M T H, NEILSEN D R. A consistent set of parametric models for the flow of water and air as immiscible fluids in the subsurface[J]. Water Resources Research , 1989, 25: 2187-2189.
    [13] FAIRBRIDGE R, FINKL C. The encyclopedia of soil science part 1[M]. Stroudsburg: Hutchinson and Ross Inc. 1979.
    [14] VANAPALLI S K, FREDLUND D G, PUFAHL D E, et al. Model for the prediction of shear strength with respect to soil suction[J]. Canadian Geotechnical Journal, 1996, 33: 379-392.
    [15] FLEUREAU Jean-Marie, VEBRUGGE Jean-Claude, HUERGO P J, et al. Aspects of the behaviour of compacted clayey soils on drying and wetting paths[J]. Canadian Geotechnical Journal, 2002, 39: 1341-1357.
    [16] ZHANG F. Soil water retention and relative permeability for full range of saturation[R]. Pacific Northwest National Laboratory, 2010.
    [17] LU N, GODT J W. Hillslope hydrology and stability[M]. London: Cambridge University Press, 2013.
    [18] ZHENG Y, ZAOUI A, SHAHROUR A. A theoretical study of swelling and shrinking of hydrated Wyoming montmorillonite[J]. Applied Clay Science, 2011, 51: 177-181.
    [19] KOZAKI T, INADA K, SATO S, et al. Diffusion mechanism of chloride ions in sodium montmorillonite[J]. Journal of Contaminant Hydrology, 2001, 47: 159-170.
    [20] MCQUEEN I S, MILLER R F. Approximating soil moisture characteristics from limited data: empirical evidence and tentative model[J]. Water Research, 1974, 10(3): 521-527.
    [21] BRADBURY M H, BAEYENS B. Pore-water chemistry in compacted re-saturated MX-80 bentonite[J]. Journal of Contaminant Hydrology, 2003, 61: 329-338.
    [22] FORSLIND E. A theory of water[R]. Stockholm: Swedish Cement and Concrete Research Institute at the Royal Institute of Technology, Stockholm, 1952, 16: 43.
    [23] GRIM R E. Clay mineralogy[M]. 2nd ed. New York: McGraw-Hill Inc, 1968.
    [24] PUSCH R, KARNLAND O, Hökmark H. GMM — A general microstructural model for qualitative and quantitative studies of smectite clays[R]. Stockholm: Swedish Nuclear Fuel and Waste Management Company, 1990.
    [25] 赵珊茸. 结晶学及矿物学[M]. 北京: 高等教育出版社, 2008. (ZHAO Shan-rong. Crystallography and mineralogy[M]. Beijing: Higher Education Press, 2008.(in Chinese))
    [26] HAWKIS R K, EGELSTAFF P A. Interfacial water structure in montmorillonite from neutron diffraction experiments[J]. Clays and Clay Minerals, 1980, 28(1): 19-28.
    [27] DERJAGUIN B V, KARASEV V V, KHROMOVA E N. Thermal expansion of water in fine pores[J]. Journal of Colloid and Interface Science, 1986, 109(2): 586-587.
    [28] JACINTO A C, VILLAR M V, LEDESMA A. Influence of water density on the water-retention curve of expansive clays[J]. Géotechnique, 2012, 62( 8): 657-667.
    [29] VILLAR M V, Gómez-Espina R. Effect of temperature on the water retention capacity of FEBEX and MX-80 bentonites[C]// 1st European Conference on Unsaturated Soils: Advances in Geo-engineering. London, 2008: 257-262.
    [30] 刘月妙, 温志坚. 用于高放射性废物深地质处置的黏土材料研究[J]. 矿物岩石, 2003, 23(4): 42-45. (LIU Yue-miao, WEN Zhi-jian. Study on clay-based materials for the repository of high level radioactive waste[J]. Journal Mineral Petrol, 2003, 23(4): 42-45. (in Chinese))
    [31] SUN D A, SUN W J. Swelling characteristics of GMZ bentonites and its prediction[J]. Journal of Rock Mechanics and Geotechnical Engineering, 2014, 6(2): 103-109.
