热损伤花岗岩三轴卸围压力学特性试验研究

蔡燕燕; 罗承浩; 俞缙; 张黎明

doi:10.11779/CJGE201507002

热损伤花岗岩三轴卸围压力学特性试验研究 English Version

蔡燕燕^{1, 2},
罗承浩¹,
俞缙^{1, 2},
张黎明³

1. 华侨大学岩土工程研究所,福建厦门 361021; 2. 中国矿业大学深部岩土力学与地下工程国家重点实验室,江苏徐州 221008; 3. 青岛理工大学理学院,山东青岛 266033

基金项目: 国家自然科学基金项目（51374112,41472270）; 福建省; 自然科学基金项目（2014J01160）; 中国矿业大学深部岩土力学与地; 下工程国家重点实验室开放基金项目（SKLGDUEK1304）

详细信息

作者简介:
蔡燕燕(1982-),女,福建晋江人,博士,副教授,硕士生导师,主要从事岩土力学与室内实验等方面的研究工作。E-mail: yycai@hqu.edu.cn。

计量
- 文章访问数: 390
- HTML全文浏览量: 12
- PDF下载量: 391
出版历程
- 收稿日期: 2014-12-15
- 发布日期: 2015-07-19

Experimental study on mechanical properties of thermal-damage granite rock under triaxial unloading confining pressure

1. Geotechnical Engineering Institute, Huaqiao University, Xiamen 361021, China; 2. State Key Laboratory for Geomechanics and Deep Underground Engineering, China University of Mining and Technology, Xuzhou 221008, China; 3. College of Science, Qingdao Technological University, Qingdao 266033, China

摘要

摘要: 利用岩石伺服试验系统,对经历25℃~900℃作用后的花岗岩试样进行三轴卸围压试验,研究高温后花岗岩在卸荷路径下的变形特性、参数特征及破坏形态。结果表明：经历300℃后的岩样围压卸荷量最少,最容易发生破坏。基于应变围压增量比,定量揭示了卸荷破坏是由强烈的径向变形和体积扩容所致。随着温度上升,各应变围压增量比均先增大后减小,在300℃时达到最大。卸荷过程中岩样的变形模量逐渐减小,25℃~900℃之间,减小33.20%~59.11%,且温度越高减小越多,与体积应变均呈二次多项式相关;泊松比逐渐增大,25℃~900℃之间,增大164.96%~274.03%,且温度越高增加越多,与体积应变均呈线性相关。高温后的岩样在单轴压缩下均呈轴向劈裂破坏,并存在多个贯通裂纹;在三轴压缩下为宏观单一的贯通剪切破坏形态;三轴卸围压下破坏形态则比较复杂,常温时为高角度的局部剪切破坏,随温度升高,岩样变为贯通剪切破坏,到900℃时又变为局部剪切破坏。
- 热损伤 /
- 花岗岩 /
- 三轴卸围压 /
- 力学性能 /
- 破坏形态
Abstract: The triaxial tests on post-high-temperature granite samples (25℃~900℃) under unloading confining pressure are performed to study the deformation characteristics, parameters and failure patterns by using the servo-controlled rock test system. The results show that the granite rocks undergoing a certain temperature (300℃) resist the lowest level of confining pressure and are the most prone to damage. Based on the ratios of strain increment to confining pressure decrement, it is quantitatively revealed that the unloading damage is caused by the intense radial deformation and volume expansion. The ratios of strain increment to confining pressure decrement all increase firstly and then decrease with the increase of temperature and reach the maximum value at 300℃. The deformation modulus gradually decreases during unloading by 33.20%~59.11% between 25℃~900℃, and the higher the temperature is, the more it decreases. The decreasing tendency is a quadratic polynomial relation with the volume strain. The Poisson's ratio increases gradually during unloading by 164.96%~274.03% between 25℃~900℃, and the higher the temperature is, the more it increases. The increasing tendency is linearly related to the volume strain. The post-high-temperature granite samples fail in the pattern of axial splitting under uniaxial compression with multiple transfixion cracks. And the rocks damage with cutting-through shear failure under triaxial compression. It is most complicated under triaxial unloading. The local shear failure with a large angle at the normal temperature turns into cutting-through with the increase of temperature, and returns to local shear failure again when the temperature reaches 900℃.
- thermal damage /
- granite /
- triaxial unloading confining pressure /
- mechanical property /
- failure pattern

HTML全文

参考文献(27)

[1]	何满潮, 钱七虎. 深部岩体力学基础[M]. 北京: 科学出版社, 2010. (HE Man-chao, QIAN Qi-hu. The basis of deep rock mechanics[M]. Beijing: Science Press, 2010. (in Chinese))
[2]	ZHAO Y S, WAN Z J, KANG J R. Introduction of geothermal extraction of hot dry rock[J]. Beijing: Science Press, 2004. (in Chinese))
[3]	FENG Zi-jun, ZHAO Yang-sheng, ZHOU An-chao, et al. Development program of hot dry rock geothermal resource in the Yangbajing Basin of China[J]. Renewable Energy, 2012(39): 490-495.
[4]	WONG T E. Effects of temperature and pressure on failure and post-failure behavior of westerley grinate[J]. Mechanics of Materials, 1982(1): 3-17.
[5]	吴刚, 邢爱国, 张磊. 砂岩高温后的力学特性[J]. 岩石力学与工程学报, 2007, 26(10): 2110-2116. (WU Gang, XING Ai-guo, ZHANG Lei. Mechanical charactistics of sandstone after high temperatures[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(10): 2110-2116. (in Chinese))
[6]	寇绍全. 热开裂损伤对花岗岩变形及破坏特性的影响[J]. 力学学报, 1987, 19(6): 550-555. (KOU Shao-quan. Effect of thermal cracking damage on the deformation and failure of granite[J]. Acta Mechanics Sinica, 1987, 19(6): 550-555. (in Chinese))
[7]	CHEN You-liang, NI Jing, SHAO Wei, et al. Experimental study on the influence of temperature on the mechanical properties of granite under uni-axial compression and fatigue loading[J]. International Journal of Rock Mechanics & Mining Sciences, 2012(56): 62-66.
[8]	LIU Shi, XU Jin-yu. Mechanical properties of Qinling biotite granite after high temperature treatment[J]. International Journal of Rock Mechanics & Mining Sciences, 2014(71): 188-193.
[9]	杜守继, 刘华, 职洪涛, 等. 高温后花岗岩力学性能的试验研究[J]. 岩石力学与工程学报, 2004, 23(14): 2359-2364. (DU Shou-ji, LIU Hua, ZHI Hong-tao, et al. Testing study on mechanical properties of post-high- temperature granite[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(14): 2359-2364. (in Chinese))
[10]	尹光志, 李小双, 赵洪宝. 高温后粗砂岩常规三轴压缩条件下力学特性试验研究[J]. 岩石力学与工程学报, 2009, 28(3): 598-603. (YIN Guang-zhi, LI Xiao-shuang, ZHAO Hong-bao. Experimental investigation on mechanical properties of coarse sandstone after high temperature under conventional triaxial compression[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(3): 598-603. (in Chinese))
[11]	徐小丽, 高峰, 张志镇. 高温作用后花岗岩三轴压缩试验研究[J]. 岩土力学, 2014, 35(11): 3177-3183. (XU Xiao-li, GAO Feng, ZHANG Zhi-zhen. Research on triaxial compression test of granite after high temperatures[J]. Rock and Soil Mechanics, 2014, 35(11): 3177-3183. (in Chinese))
[12]	哈秋舲. 加载岩体力学与卸荷岩体力学[J]. 岩土工程学报, 1998, 20(1): 114. (HA Qiu-ling. Loading and unloading rock masses mechanics[J]. Chinese Journal of Geotechnical Engineering, 1998, 20(1): 114. (in Chinese))
[13]	WU G, ZHANG L. Studying unloading failure characteristics of a rock mass using disturbed state concept[J]. International Journal of Rock Mechanics and Mining Sciences, 2004, 41(S1): 181-187.
[14]	XIE H Q, HE C H. Study of the unloading characteristics of a rock mass using the triaxial test and damage mechanics[J]. Imitational Journal of Rock Mechanics and Mining Science, 2004: 13-18.
[15]	陶履彬, 夏才初, 陆益鸣. 三峡工程花岗岩卸荷全过程特性的试验研究[J]. 同济大学学报(自然科学版), 1998, 26(3): 330-334. (TAO Lu-bin, XIA Cai-chu, LU Yi-ming. Experimental studies on complete course behavior of unloading of granite on Three Gorges Project of the Yangtze River[J]. Journal of Tongji University (Natural Science), 1998, 26(3): 330-334. (in Chinese))
[16]	黄润秋, 黄达. 卸荷条件下花岗岩力学特性试验研究[J]. 岩石力学与工程学报, 2008, 27(11): 2205-2213. (HUANG Run-qiu, HUANG Da. Experimental research on mechanical properties of granites under unloading condition[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(11): 2205-2213. (in Chinese))
[17]	陈卫忠, 吕森鹏, 郭小红, 等. 脆性岩石卸围压试验与岩爆机理研究[J]. 岩土工程学报, 2010, 32(6): 963-969. (CHEN Wei-zhong, LU Sen-peng, GUO Xiao-hong, et al. Unloading confining pressure for brittle rock and mechanism of rock burst[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(6): 963-969. (in Chinese))
[18]	吕颖慧, 刘泉声, 胡云华. 基于花岗岩卸荷试验的损伤变形特征及其强度准则[J]. 岩石力学与工程学报, 2009, 28(10): 2096-2103. (LU Ying-hui, LIU Quan-sheng, HU Yun-hua. Damage deformation characteristics and its strength criterion based on unloading experiments of granites[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(10): 2096-2103. (in Chinese))
[19]	张黎明, 王在泉, 石磊, 等. 不同应力路径下大理岩破坏过程中的声发射特性[J]. 岩石力学与工程学报, 2012, 31(6): 1230-1236. (ZHANG Li-ming, WANG Zai-quan, SHI Lei, et al. Acoustic emission characteristics of marble during failure process under different stress paths[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(6): 1230-1236. (in Chinese))
[20]	邱士利, 冯夏庭, 张传庆, 等. 不同初始损伤和卸荷路径下深埋大理岩卸荷力学特性试验研究[J]. 岩石力学与工程学报, 2012, 31(8): 1686-1697. (QIU Shi-li, FENG Xia-ting, ZHANG Chuan-qing, et al. Experimental research on mechanical properties of deep marble under different initial damage levels and unloading paths[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(8): 1686-1697. (in Chinese))
[21]	俞缙, 李宏, 陈旭, 等. 砂岩卸围压变形过程中渗透特性与声发射试验研究[J]. 岩石力学与工程学报, 2014, 33(1): 69-79. (YU Jin, LI Hong, CHEN Xu, et al. Experimental study of permeability and acoustic emission characteristics of sandstone during processes of unloading confining pressure and deformation[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(1): 69-79. (in Chinese))
[22]	LI Xi-bing, CAO Wen-zhuo, ZHOU Zi-long, et al. Influence of stress path on excavation unloading response[J]. Tunnelling and Underground Space Technology, 2014, 42: 237-246.
[23]	李建林, 陈星, 党莉, 等. 高温后砂岩三轴卸荷试验研究[J]. 岩石力学与工程学报, 2011, 30(8): 1587-1595. (LI Jian-lin, CHEN Xing, DANG Li, et al. Triaxial unloading test of sandstone after high temperature[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(8): 1587-1595. (in Chinese))
[24]	邱士利, 冯夏庭, 张传庆, 等. 不同卸围压速率下深埋大理岩卸荷力学特性试验研究[J]. 岩石力学与工程学报, 2010, 29(5): 1807-1817. (QIU Shi-li, FENG Xia-ting, ZHANG Chuan-qing, et al. Experimental research on unloading mechanical properties of deep marble under pressures[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5): 1807-1817. (in Chinese))
[25]	高春玉, 徐进, 何鹏, 等. 大理岩加卸载力学特性的研究[J]. 岩石力学与工程学报, 2005, 24(3): 456-460. (GAO Chun-yu, XU Jin, HE Peng, et a1. Study on mechanical propertie of marble under loading and unloading conditions[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(3): 456-460. (in Chinese))
[26]	HEUECK T, PEANO A, PELLEGRINT R. A constitutive law for thermo plastic behavior of rocks: an analogy with clays[J]. Surveys in Geophys, 1994, 15: 643-671.
[27]	谢卫红, 高峰, 李顺才, 等. 石灰岩热损伤破坏机制研究[J]. 岩土力学,2007, 28(5): 1021-1026. (XIE Wei-hong, GAO Feng, LI Shun-cai. Study on mechanism of thermal damage fracture for limestone[J]. Rock and Soil Mechanics, 2007, 28(5): 1021-1026. (in Chinese))
