采场覆岩变形与破坏的分布式光纤监测与分析

张丹, 张平松, 施斌, 王宏宪, 李长圣

张丹, 张平松, 施斌, 王宏宪, 李长圣. 采场覆岩变形与破坏的分布式光纤监测与分析[J]. 岩土工程学报, 2015, 37(5): 952-957. DOI: 10.11779/CJGE201505023
引用本文: 张丹, 张平松, 施斌, 王宏宪, 李长圣. 采场覆岩变形与破坏的分布式光纤监测与分析[J]. 岩土工程学报, 2015, 37(5): 952-957. DOI: 10.11779/CJGE201505023
shu
ZHANG Dan, ZHANG Ping-song, SHI Bin, WANG Hong-xian, LI Chang-sheng. Monitoring and analysis of overburden deformation and failure using distributed fiber optic sensing[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(5): 952-957. DOI: 10.11779/CJGE201505023
Citation: ZHANG Dan, ZHANG Ping-song, SHI Bin, WANG Hong-xian, LI Chang-sheng. Monitoring and analysis of overburden deformation and failure using distributed fiber optic sensing[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(5): 952-957. DOI: 10.11779/CJGE201505023
shu

采场覆岩变形与破坏的分布式光纤监测与分析  English Version

  • 1. 南京大学地球科学与工程学院,江苏 南京 210023; 2. 安理理工大学地球与环境学院,安徽 淮南 232001

基金项目: 国家自然科学基金重点项目（41230636）; 国家重点基础研究发展计划（973计划）课题（2011CB710605）; 地质灾害防治与地质环境保护国家重点实验室开放基金项目（SKLGP2011K011）
详细信息
    作者简介:

    张 丹(1976- ),男,副教授,主要从事地质灾害监测与防治方面的教学和科研工作。E-mail: zhangdan@nju.edu.cn。

Monitoring and analysis of overburden deformation and failure using distributed fiber optic sensing

  • 1. School of Earth Sciences and Engineering, Nanjing University, Nanjing 210023, China; 2. School of Earth and Environment, Anhui University of Science and Technology, Huainan 232001, China

摘要

    摘要
  • 摘要: 提出了采用BOTDR分布式光纤传感技术,对煤层采动过程中覆岩变形与破坏的发育规律进行了监测和分析。以淮南矿区某工作面为例,介绍了监测孔的布置方式和传感光缆的安装方法,提出了采用钻孔安装技术将传感光缆植入到煤层顶板覆岩中,根据工作面回采进度,定期采集传感光缆的应变分布,分析了光缆的应变分布特征及其变化规律,得到了应变分布与地层的对应关系,发现应变分布是不均匀的,传感光缆的应变变化与覆岩模量呈反比,揭示了覆岩变形与破坏的发育规律。根据光缆的应变分布特征、传感光缆光损耗较大的点或者断点所处的层位,结合13-1煤覆岩的岩性组合,得到了垮落带和导水裂缝带的发育高度分别为12.5 m和40.0 m。
    Abstract: BOTDR, a kind of distributed fiber optic sensing technology, is employed to monitor the overburden deformation and failure during the coal mining. As an example in Huainan mining area, the layout and the installation technique of the sensing cables for overburden monitoring are designed. The sensing cables are implanted into the overburden by drilling installation technique. The strain distribution of the sensing cables is collected regularly according to the mining schedule. The characteristics and variation of the strain distribution are studied to reveal the relationship between the strain distribution and strata. The strain distribution is not uniform, which is relatively larger in the soft strata, such as mudstone, than that in the hard strata, such as sandstone. The deformation and failure of the overburden are also obtained. Based on the strain distribution and the breakpoint position of the cables, the heights of the caving zone and fractured zone are 12.5 m and 40.0 m respectively with the consideration of the overburden lithology and stratum combination above 13-1 coal seam.
    • HTML全文
    • 参考文献(20)
  • [1] SINGH M M, KENDORSKI F S. Strata disturbance prediction for mining beneath surface water and waste impoundments[C]// 1st Annual Conf on Ground Control in Mining. Morgantown. West Virginia: West Virginia University, 1981: 76-89.
    [2] 国家安全生产监督管理总局, 国家煤矿安全监察局. 煤矿安全规程[M]. 北京: 煤炭工业出版社, 2011. (State Administration of Work, State Administration of Coal Mine Safety. Coal mine safety regulations[M]. Beijing: Coal Industry Publishing House, 2011. (in Chinese))
    [3] 国家煤炭工业局. 建筑物、水体、铁路及主要井巷煤柱留设与压煤开采规程[M]. 北京: 煤炭工业出版社, 2000. (State Bureau of Coal Industry. Regulations of buildings, water, rail way and main well lane leaving coal pillar and press coal mining[M]. Beijing: China Coal Industry Publishing House, 2000. (in Chinese))
    [4] BISE C J. Modern American coal mining: methods and applications[M]. Englewood: Society for Mining, Metallurgy, and Exploration, Inc. (SME), 2013.
    [5] 许家林, 钱鸣高, 金宏伟. 岩层移动离层演化规律及其应用研究[J]. 岩土工程学报, 2004, 26(5): 632-636. (XU Jia-lin, QIAN Ming-gao, JIN Hong-wei. Study a nd application of bed separation distribution and development in the process of strata movement[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(5): 632-636. (in Chinese))
    [6] 李连崇, 唐春安, 梁正召. 考虑岩体碎胀效应的采场覆岩冒落规律分析[J]. 岩土力学, 2010, 31(11): 3537-3541. (LI Lian-chong, TANG Chun-an, LIANG Zheng-zhao. Investigation on overburden strata collapse around coal face considering effect of broken expansion of rock[J]. Rock and Soil Mechanics, 2010, 31(11): 3537-3541. (in Chinese))
    [7] GAO F, STEAD D, COGGAN J. Evaluation of coal longwall caving characteristics using an innovative UDEC Trigon approach[J]. Computers and Geotechnics, 2014, 55: 448-460.
    [8] 缪协兴, 陈荣华, 浦海, 等. 采场覆岩厚关键层破断与冒落规律分析[J]. 岩石力学与工程学报, 2005, 24(8): 1290-1296. (MIAO Xie-xing, CHEN Rong-hua, PU Hai, et al. Analysis of breakage and collapse of thick key strata around coal face[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(8): 1290-1296. (in Chinese))
    [9] 鞠杨, 左建平, 宋振铎, 等. 煤矿开采中的岩层应力分布与变形移动的DDA模拟[J]. 岩土工程学报, 2007, 29(2): 268-273. (JU Yang, ZUO Jian-ping, SONG Zhen-duo, et al. Numerical simulation of stress distribution and displacement of rock strata of coal mines by means of DDA method[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(2): 268-273. (in Chinese))
    [10] 吴荣新, 张卫, 张平松. 并行电法监测工作面“垮落带”岩层动态变化[J]. 煤炭学报, 2012, 37(4): 571-577. (WU Rong-xin, ZHANG Wei, ZHANG Ping-song. Exploration of parallel electrical technology for the dynamic variation of caving zone strata in coal face[J]. Journal of China Coal Society, 2012, 37(4): 571-577. (in Chinese))
    [11] 张平松, 胡雄武, 吴荣新. 岩层变形与破坏电法测试系统研究[J]. 岩土力学, 2012, 33(3): 952-956. (ZHANG Ping-song, HU Xiong-wu, WU Rong-xin. Study of detection system of distortion and collapsing of top rock by resistivity method in working face[J]. Rock and Soil Mechanics, 2012, 33(3): 952-956. (in Chinese))
    [12] 康永华, 王济忠, 孔凡铭, 等. 覆岩破坏的钻孔观测方法[J]. 煤炭科学技术, 2002, 30(12): 26-28. (KANG Yong-hua, WANG Ji-zhong, KONG Fan-ming, et al. Bore hole survey method for overburden failure[J]. Coal Science and Tehcnology, 2002, 30(12): 26-28. (in Chinese))
    [13] 王忠昶, 张文泉, 赵德深. 离层注浆条件下覆岩变形破坏特征的连续探测[J]. 岩土工程学报, 2008, 30(7): 1094-1098. (WANG Zhong-chang, ZHANG Wen-quan, ZHAO De-shen. Continuous exploration for deformation and failure of overburdens under injecting grouts in separate layers[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(7): 1094-1098. (in Chinese))
    [14] PALCHIK V. Formation of fractured zones in overburden due to longwall mining[J]. Environmental Geology, 2003, 44(1): 28-38.
    [15] PALCHIK V. Localization of mining-induced horizontal fractures along rock layer interfaces in overburden: field measurements and prediction[J]. Environ Geol, 2005, 48(1): 68-80.
    [16] 宋振骐, 蒋金泉. 煤矿岩层控制的研究重点与方向[J]. 岩石力学与工程学报, 1996, 15(2): 128-134. (SONG Zhen-qi, JIANG Jin-quan. The current research situation and developing orientation of strata control in coal mine[J]. Chinese Journal of Rock Mechanics and Engineering, 1996, 15(2): 128-134. (in Chinese))
    [17] 张丹, 施斌, 吴智深, 等. BOTDR分布式光纤传感器及其在结构健康监测中的应用 [J]. 土木工程学报, 2003, 36(11): 83-87. (ZHANG Dan, SHI Bin, WU Zhi-shen, et al. Distributed optical fiber sensor based on BOTDR and its application to structural health monitoring[J]. China Civil Engineering Journal, 2003, 36(11): 83-87. (in Chinese))
    [18] BAO X Y, CHEN L A. Recent progress in brillouin scattering based fiber sensors[J]. Sensors, 2011, 11(4): 4152-4187.
    [19] 施斌, 徐洪钟, 张丹, 等. BOTDR应变监测技术应用在大型基础工程健康诊断中的可行性研究[J]. 岩石力学与工程学报, 2004, 23(3): 493-499. (SHI Bin, XU Hong-zhong, ZHANG Dan, et al. Feasibility study on application of BOTDR to health monitoring for large infrastructure engineering[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(3): 493-499. (in Chinese))
    [20] 滕永海. 综放开采导水裂缝带的发育特征与最大高度计算 [J]. 煤炭科学技术, 2011, 39(4): 118-120. (TENG Yong-hai. Development features and max height calculation of water conducted fractured zone caused by fully mechanized top coal caving mining[J]. Coal Science and Technology, 2011, 39(4): 118-120. (in Chinese))
