Mechanism of sheet-pile structure with a single anchorage
-
摘要: 板桩结构作为支挡建筑物广泛应用于基坑、码头等工程中,其涉及的主要问题是土压力作用下板桩的受力和变形,而土压力与变形又是相互关联的,属于典型的土与结构相互作用问题。以单锚板桩码头结构为例,基于有限元数值模拟,探讨了板桩结构的工作机理,研究了码头港池开挖过程中前墙两侧的土压力分布、结构的内力与变形、地基土的应力应变关系,以及地基不同位置处土单元的主应力旋转等问题。研究表明：正确地模拟土体的应力应变关系是分析此类问题的关键;港池开挖过程中,前墙陆侧土压力向主动方向发展,而海侧土压力则向被动方向发展;港池开挖造成了土体单元的主应力方向旋转,特别是港池海侧下方的土体主应力方向旋转剧烈。Abstract: The sheet-pile structure is extensively used in deep excavations and wharfs as the retaining structure. The key issue is the forces acting on the sheet piles as well as their deformations under the earth pressure. However, the deformations closely relate to the earth pressure. This issue becomes a typical problem of soil-structure interaction. Based on FEM numerical simulations, the working mechanism of the sheet-pile structure is investigated. The following aspects are studied with regard to a wharf case during its excavation: distribution of earth pressures at both sides of the front wall; internal forces and deformation of the structure, stress-strain relationship of foundation soils and rotation of the principal stresses. The results show that accurate modeling of stress-strain relationship of soils is the key to this kind of problem. During the excavation of the harbor basin, the seaward earth pressure of the front wall develops towards the active direction, while the landward one develops towards the passive direction. The excavation induces the rotation of the direction of the principal stress of soils, especially that of the soils under the harbor basin at the seaward side of the front wall.
-
[1] SIPMSON B. Rankine lecture: retaining structure: displacement and design[J]. Géotechnique, 1992, 42(4): 541-576. [2] 吴明. 深基坑工程若干力学问题研究[D]. 杭州: 浙江大学, 2009. (WU Ming. Study on some problems of soil mechanics in deep excavation engineering[D]. Hangzhou: Zhejiang University, 2009. (in Chinese)) [3] FANG Y S, CHENG F P, CHEN R C, et al. Earth pressures under general wall movements[J]. Geotechnical Engineering, 1993, 24(2): 113-131. [4] 李海光. 新型支挡结构设计与工程实例[M]. 北京: 人民交通出版社, 2011. (LI Hai-guang. Design and engineering cases of new retaining structures[M]. Beijing: China Communications Press, 2011. (in Chinese)) [5] 刘永绣. 板桩和地下墙码头的设计理论和方法[M]. 北京:人民交通出版社, 2006. (LIU Yong-xiu. Design theories and methods for wharfs with sheet piles and diaphragms[M]. Beijing: China Communications Press, 2006. (in Chinese)) [6] 司海宝, 蔡正银, 俞缙. 遮帘式板桩码头结构与土共同作用3D数值模拟分析[J]. 土木工程学报, 2012(5): 182-190. (SI Hai-bao, CAI Zheng-yin, YU Jin. 3D numerical modeling of pile-soil interaction for covered sheet-piled whorf[J]. China Civil Engineering Journal, 2012(5): 182-190. (in Chinese)) [7] ZHANG J M, SHAMOTO Y, TOKIMATSU K. Evaluation of earth pressure under any lateral deformation[J]. Soils and Foundations, 1998, 38(1): 15-33. [8] CHANG M F. Lateral earth pressure behind rotating walls[J]. Canadian Geotechnical Journal, 1997, 34(2): 498-509. [9] 朱百里, 沈珠江. 计算土力学[M]. 上海: 上海科学技术出版社, 1990. (ZHU Bai-li, SHEN Zhu-jiang. Computational soil mechanics[M]. Shanghai: Shanghai Science and Technology Press, 1990. (in Chinese)) [10] 郑颖人, 沈珠江, 龚晓南. 广义塑性力学：岩土塑性力学原理[M]. 北京: 中国建筑工业出版社, 2002. (ZHENG Ying-ren, SHEN Zhu-jiang, GOMG Xiao-nan. Generalized plastic mechanics: principles of geotechnical plastic mechanics[M]. Beijing: China Architecture and Building Press, 2002. (in Chinese)) -
