双排桩隔离位移场防护邻近基坑高楼监测研究

李东海; 王梦恕; 杨广武; 刘军; 张顶立

doi:10.11779/CJGE2014S2072

双排桩隔离位移场防护邻近基坑高楼监测研究 English Version

李东海^{1, 2},
王梦恕¹,
杨广武³,
刘军⁴,
张顶立¹

1. 北京交通大学隧道及地下工程教育部工程研究中心,北京 100044;
2. 北京市市政工程研究院,北京 100037;
3. 北京市重大项目建设指挥部办公室,北京 100029;
4. 北京建筑工程学院,北京 100044

详细信息

作者简介:
李东海(1977- ),男,博士,高级工程师,主要从事隧道及地下工程研究与监测工作。E-mail: sidenli2000@163.com。

计量
- 文章访问数: 275
- HTML全文浏览量: 2
- PDF下载量: 330
出版历程
- 收稿日期: 2014-07-27
- 发布日期: 2014-07-27

Monitoring of double-row piles and high buildings adjacent to deep foundation pits

1. Tunnel and Underground Engineering Research Center of Ministry of Education, Beijing Jiaotong University, Beijing 100044, China;
2. Beijing Municipal Engineering Research Institute, Beijing 100037, China;
3. Beijing major Projects Construction Headquarters Office, Beijing 100029, China;
4. Beijing University of Civil Engineering and Architecture, Beijing 100044, China

摘要

摘要: 邻近基坑的既有建筑物由于基坑开挖引起的土体位移作用而产生附加变形甚至造成严重损伤。双排桩作为一种刚度较大的隔离措施成为当前的研究热点。以北京某地铁深基坑邻近高层居民楼为实例,对双排桩的桩排距、冠梁连接、桩间土处理等关键设计参数进行了有针对性的优化。采用数值模拟计算和现场监测,对双排桩、桩后土体及高层建筑等组成的位移场进行了分析,并进一步总结了双排桩、桩后土体及高层建筑的变形规律。同时,通过双排桩与单排桩的变形对比分析,验证了双排桩对位移场的隔离效果明显,围护结构背后土体的水平位移由17 mm降低到8 mm,减少了53%。有效控制了既有建筑的损伤程度,居民楼的最终最大差异沉降为6.9 mm,角变量为0.33‰,确保了邻近基坑居民楼的使用安全。为后续类似工程提供了有益的参考。
- 深基坑 /
- 双排桩 /
- 位移场 /
- 既有建筑 /
- 监测
Abstract: The existing buildings adjacent to a deep foundation pit will be damaged seriously or additionally deformed when the foundation pit is excavated, and it will lead to motion of soils. The double-row piles as one of shielding measures are studied. Based on a deep foundation pit adjacent to high buildings in Beijing, the key design parameters of double-row piles such as distance of row piles, distance of piles, link of top beam, and strength of soils between the piles are analyzed. Through the numerical simulation and in-situ monitoring, the displacement field grouped by the double-row piles, soils after the piles and high buildings is analyzed. The deformation laws of the double-row piles, soils after the piles and high buildings are concluded. At the same time, it is proved that the double-row piles can reduce the displacement field obviously by comparing the double-row piles to the single-row ones. The horizontal displacement of soils after the piles decreases from 17 mm to 8 mm, with a percent of about 53%. The maximum differential settlement of high buildings is 6.9 mm and the angle variance is 0.33‰. In a word, the safety of buildings is ensured by monitoring during the excavation of the deep foundation pit. It may be useful reference to the similar engineering in future.
- deep foundation pit /
- double-row pile /
- displacement field /
- existing building /
- monitoring

HTML全文

参考文献(16)

[1]	应宏伟, 李涛, 王文芳. 基于三维数值模拟的深基坑隔断墙优化设计[J]. 岩土力学, 2012, 33(1): 220-226. (YING Hong-wei, LI Tao, WANG Wen-fang. Optimization design of partition wall in deep excavations based on 3-D numerical simulation[J]. Rock and Soil Mechanics, 2012, 33(1): 220-226. (in Chinese))
[2]	黄茂松, 朱晓宇, 张陈蓉. 基于周边既有建筑物承载能力的基坑变形控制标准[J]. 岩石力学与工程学报, 2012, 31(11): 2305-2311. (HUANG Mao-song, ZHU Xiao-yu, ZHANG Chen-rong. Deformation controlling criterion for excavation based on bearing capacity of adjacent buildings[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(11): 2305-2311. (in Chinese))
[3]	郑刚, 李志伟. 考虑初始不均匀沉降的建筑物受基坑开挖影响的有限元分析[J]. 岩土力学, 2012, 33(8): 2491-2499. (ZHENG Gang, LI Zhi-wei. Finite element analysis of responses of building adjacent to excavation considering initial differential settlement[J]. Rock and Soil Mechanics, 2012, 33(8): 2491-2499. (in Chinese))
[4]	李进军, 王卫东, 邸国恩, 等. 基坑工程对邻近建筑物附加变形影响的分析[J]. 岩土力学, 2007, 28(增刊): 623-629. (LI Jin-jun, WANG Wei-dong, DI Guo-en, et al. Analysis of the influence of excavation engineering on additional deformation of adjacent buildings[J]. Rock and Soil Mechanics, 2007, 28(S0): 623-629. (in Chinese))
[5]	王浩然, 王卫东, 徐中华. 基坑开挖对邻近建筑物影响的三维有限元分析[J]. 地下空间与工程学报, 2009, 5(增刊2): 1512-1517. (WANG Hao-ran, WANG Wei-dong, XU Zhong-hua. Three dimensional analysis of the influence of deep excavation on adjacent building[J]. Chinese Journal of Underground Space and Engineering, 2009, 5(S2): 1512-1517. (in Chinese))
[6]	李东海, 王梦恕, 丁振明, 等. 含砂砾土层SMW围护结构变形的三维数值分析与监测[J]. 岩土工程学报, 2012, 34(增刊): 120-124. (LI Dong-hai, WANG Meng-shu, DING Zhen-ming, et al. Three-dimensional numerical analysis and monitoring of deformation of SMW deep foundation pit enclosure structure in soil containing gravel[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(S0): 120-124. (in Chinese))
[7]	李大勇, 龚晓南, 张土乔. 软土地基深基坑周围地下管线保护措施的数值模拟[J]. 岩土工程学报, 2001, 23(6): 736-740. (LI Da-yong, GONG Xiao-nan, ZHANG Tu-qiao. Numerical simulation of the buried pipelines protection adjacent to deep excavation[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(6): 736-740. (in Chinese))
[8]	翟杰群, 贾坚, 谢小林. 隔离桩在深基坑开挖保护相邻建筑中的应用[J]. 地下空间与工程学报, 2010, 6(1): 162-166. (ZAI Jie-qun, JIA Jian, XIE Xiao-lin. Practice of Partition Wall in the Building Protection Projects near Deep Excavation[J]. Chinese Journal of Underground Space and Engineering, 2010, 6(1): 162-166. (in Chinese))
[9]	MARTIN G R, CHEN C Y. Response of piles due to lateral slope movement[R]. Computers and Structures, 2005, 83: 588-598.
[10]	黄凭, 莫海鸿, 陈俊生. 双排桩支护结构挠曲理论分析[J]. 岩石力学与工程学报, 2009, 28(增刊2): 3870-3875. (HUANG Ping, MO Hai-hong, CHEN Jun-sheng. Theoretical analysis of double-row piles retaining structure deflection[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(S2): 3870-3875. (in Chinese))
[11]	聂庆科, 胡建敏, 吴刚. 深基坑双排桩支护结构上的变形和土压力研究[J]. 岩土力学, 2008, 29(11): 3089-3094. (NIE Qing-ke, HU Jian-min, WU Gang. Deformation and earth pressure of a double-row piles retaining structure for deep excavation[J]. Rock and Soil Mechanics, 2008, 29(11): 3089-3094. (in Chinese))
[12]	吴刚, 白冰, 聂庆科. 深基坑双排桩支护结构设计计算方法研究[J]. 岩土力学, 2008, 29(10): 2753-2757. (WU Gang, BAI Bing, NIE Qing-ke. Research on calculation method of double-row piles retaining structure for deep excavation[J]. Rock and Soil Mechanics, 2008, 29(10): 2753-2757. (in Chinese))
[13]	JGJ8—2007 建筑变形测量规范[S]. 2007. (JGJ8—2007 Code for deformation measurement of building and structure[S]. 2007. (in Chinese))
[14]	GB50026—2007 工程测量规范[S]. 2008. (GB50026—2007 Code for engineering surveying[S]. 2008. (in Chinese))
[15]	GB50299—1999地下铁道工程施工及验收规范[S]. 1999. (GB50299—1999 Code for construction and acceptance of metro engineering[S]. 1999. (in Chinese))
[16]	欧章煜, 谢百钩. 深开挖邻产保护之探讨[J]. 岩土工程学报, 2008, 30(增刊1): 509-517. (OU Zhang-yi, XIE Bai-gou. Building protection measures in deep excavations[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(S1): 509-517. (in Chinese))
