下穿运营高铁及地铁的交通枢纽深基坑数值分析

李明广, 徐安军, 董锋, 陈锦剑, 王建华

李明广, 徐安军, 董锋, 陈锦剑, 王建华. 下穿运营高铁及地铁的交通枢纽深基坑数值分析[J]. 岩土工程学报, 2014, 36(zk2): 386-390. DOI: 10.11779/CJGE2014S2067
引用本文: 李明广, 徐安军, 董锋, 陈锦剑, 王建华. 下穿运营高铁及地铁的交通枢纽深基坑数值分析[J]. 岩土工程学报, 2014, 36(zk2): 386-390. DOI: 10.11779/CJGE2014S2067
LI Ming-guang, XU An-jun, DONG Feng, CHEN Jin-jian, WANG Jian-hua. Numerical study on a deep excavation of transportation hub underlying operating railways and a metro station[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(zk2): 386-390. DOI: 10.11779/CJGE2014S2067
Citation: LI Ming-guang, XU An-jun, DONG Feng, CHEN Jin-jian, WANG Jian-hua. Numerical study on a deep excavation of transportation hub underlying operating railways and a metro station[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(zk2): 386-390. DOI: 10.11779/CJGE2014S2067

下穿运营高铁及地铁的交通枢纽深基坑数值分析  English Version

基金项目: 国家自然科学基金项目(41172251,41330633)
详细信息
    作者简介:

    李明广(1987- ),男,重庆人,博士研究生,主要从事岩土工程、地下工程等领域数值试验工作。E-mail: lmg20066028@163.com。

Numerical study on a deep excavation of transportation hub underlying operating railways and a metro station

  • 摘要: 某地下综合交通枢纽基坑下穿沪宁城际铁路和已建11号线地铁车站,周围环境复杂,铁路路基和地铁车站结构变形控制要求严格。采用有限差分软件FLAC3D对该深基坑施工过程进行三维数值分析,研究邻近铁路基坑、下穿铁路基坑以及已建地铁车站两侧共墙基坑开挖的引起的基坑围护结构和周围已有结构的变形特性,并采用现场实测数据对理论分析进行验证。通过对比分析计算结果和实测数据可知,铁路路基沉降和隧道隆起量均控制在允许范围内;采用坑内土体加固和加厚地连墙等措施可以有效地控制地连墙变形和邻近铁路路基沉降;已建地铁车站两侧共墙基坑开挖卸荷会导致地铁轨道的隆起,隆起量随共墙基坑卸荷量增加而增加;下穿基坑开挖和上部列车移动荷载共同作用下,铁路路基整体表现为上台。
    Abstract: The excavation of the transportation hub is located below Shanghai-Nanjing high-speed railways and metro station of Line 11. The surroundings are extremely complicated and the deformation controls of both the railway subgrade and the metro station are strict. 3D numerical simulation, using the FLAC3D, is carried out to model the construction process of the deep excavation. The deformation behaviors of the retaining structures and the surrounding existing structures are investigated during the construction of the adjacent pit, underlying pit and the pits sharing the same diaphragm walls with the existing structures. Numerical predictions are verified by the monitoring data. The results show that both the settlement of the railway subgrade and the rebound of the metro station are controlled within the allowable values, and the numerical predictions are reasonable and close to the monitoring data. Deformations of diaphragm wall and settlement of railway subgrade can be reduced by deepening and thickening the diaphragm wall and improving the soils. The soils excavated at both sides of the existing metro station will result in rebound of the structures, and the rebound depends on the unloaded volume. The overlying railway subgrade heaves as a result of the interaction of the underlying excavation and the train loads.
  • [1] 刘建航, 刘国彬, 范益群. 软土基坑工程中时空效应理论与实践(上)[J]. 地下工程与隧道, 1999(3): 7-12. (LIU Jian-hang, LIU Guo-bin, FAN Yi-qun. The theory and its practice by using the rule of time-space effect in soft soil excavation[J]. Undergrourd Engineering and Tunnels, 1999(3): 7-12. (in Chinese))
    [2] 刘建航, 刘国彬, 范益群. 软土基坑工程中时空效应理论与实线(下)[J]. 地下工程与隧道, 1999(4): 10-14. (LIU Jian-hang, LIU Guo-bin, FAN Yi-qun. The theory and its practice by using the rule of time-space effect in soft soil excavation[J]. Undergrourd Engineering and Tunnels, 1999(4): 10-14. (in Chinese))
    [3] HSIUNG Bin-Chen Benson. A case study on the behaviour of a deep excavation in sand [J]. Computers and Geotechnics, 2009, 36: 665-675.
    [4] OU Chang-yu, SHIAU Bor-yuan. Analysis of the corner effect on excavation behaviors[J]. Canadian Geotechnical Journal, 1998, 35(3): 532-540.
    [5] HOU Yong-mao, WANG Jian-hua, ZHANG Lu-lu. Finite-element modeling of a complex deep excavation in Shanghai[J]. Acta Geotechnica, 2009, 4(1): 7-16.
    [6] LIU Han-long, LI Ping, LIU Jin-yuan. Numerical investigation of underlying tunnel heave during a new tunnel construction[J]. Tunnelling and Underground Space Technology, 2011, 26(2): 276-283.
    [7] 郑 刚, 李志伟. 基坑开挖对邻近任意角度建筑物影响的有限元分析[J]. 岩土工程学报, 2012, 34(4): 615-624. (ZHENG Gang, LI Zhi-wei. Finite element analysis of response of buildings with arbitrary angle adjacent to excavations[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(4): 615-624. (in Chinese))
    [8] LI Ming-guang, CHEN Jin-jian, XU An-jun, et al. Case study of innovative top-down construction method with channel-type excavation[J]. Journal of Construction Engineering and Management, ASCE, 2014, 140(5): 05014003-1-05014003-10.
    [9] WANG Jian-hua, XU Zhong-hua, WANG Wei-dong. Wall and ground movements due to deep excavations in Shanghai soft soils[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2010, 136(7): 985-994.
