Influence of temperature stress on internal force and deformation of retaining structures for deep excavations
-
摘要: 通过对武汉某基坑的地连墙加钢筋混凝土内支撑结构的应力、变形监测,详细分析了温度应力对内支撑杆件轴力和支护结构变形的影响规律,研究表明,当温度从30℃增加到37℃时,内支撑的轴力增幅达41%,冠梁水平位移有较明显的降低;当温度降低时,冠梁顶水平位移增加,坑壁外侧土体的水平位移变化明显滞后于地连墙的位移变化,导致地连墙至边坡范围内土体出现大量裂缝。提出了降低温度应力对基坑施工影响的工程技术措施,以及施工期内温差较大者应将内支撑混凝土强度提高一个等级、考虑支护结构位移的影响宜适当减少支护结构位移允许值、支撑长度大于40 m时温度影响系数宜取1.2及未采取必要保温保湿措施时温度影响系数取1.4以上等建议。研究成果对于类似工程有重要的理论和实践意义。Abstract: The influence of temperature stress upon internal force and deformation of retaining and structures for deep excavations is analyzed by monitoring the foundation pit of Wuhan Changjiang Shipping Center. The results show that the axial force of bracing system is increased by 41% and the horizontal displacement of the crown beams is decreased obviously when the temperature increases from 30℃ to 37℃. When the temperature drops, the horizontal displacement of the top crown beams increases 17 mm, and that of the lateral soils outside the retaining wall significantly lags behind the displacement of concrete retaining wall, resulting in large crack in soils between the wall and the side ditch. Some construction and technical measures are put forward to reduce the effect of temperature stress, and concrete strength should be increased by one grade if large temperature difference occurs during construction period. It is suggested that the allowable values of retaining structures should be appropriately reduced considering the displacement of supporting structures, the temperature influence coefficient should be 1.2 when the supporting length is greater than 40 m, and it should be above 1.4 without necessary thermal insulation and moisturizing measures. This research has important theoretical and practical significance for similar projects.
-
Keywords:
- deep foundation pit /
- temperature stress /
- internal bracing /
- monitoring /
- safety
-
[1] JGJ120—2012 建筑基坑支护技术规程[S]. 2012. (JGJ120—2012 Technical specification for retaining and protection of building foundation excavations[S]. 2012. (in Chinese)) [2] DB42/T159—2012 建筑基坑工程监测技术规范[S]. 2012. (DB42/T159—2012 Code for monitoring of building foundation pit engineering[S]. 2012. (in Chinese)) [3] GB50010—2010 混凝土结构设计规范[S]. 2010. (GB50010—2010 Code for design of concrete structures[S]. 2010. (in Chinese)) [4] SL/T191—96 水工混凝土结构设计规范[S]. 1996. (SL/T191—96 Design code for hydraulic concrete structures[S]. 1996. (in Chinese)) [5] 郑 刚, 顾晓鲁. 考虑支撑-围护桩-土相互作用的基坑支护水平支撑温度应力的简化分析法[J]. 土木工程学报, 2002, 35(3): 87-89. (ZHENG Gang, GU Xiao-lu. Simple method for calculating temperature stress in horizontal strut of foundation pit considering strut-pile-soil interaction[J]. China Civil Engineering Journal, 2002, 35(3): 87-89. (in Chinese)) [6] 吴长胜, 田敬学. 基坑围护结构温度应力分析[J]. 西部探矿工程, 2004, 16(5): 17-18. (WU Chang-sheng, TIAN Jing-xue. Analysis of the thermal stress of excavation enclosure structure[J]. West-China Exploration Engineering, 2004, 16(5): 17-18. (in Chinese)) [7] 陆培毅, 韩丽君. 基坑支撑温度应力的有限元分析[J].岩土力学, 2008, 29(5): 1290-1294. (LU Yi-pei, HAN Li-jun. Finite element analysis of temperature stress in strut of foundation pit[J]. Rock and Soil Mechanics, 2008, 29(5): 1290-1294. (in Chinese)) [8] 陈玉香. 环境温度对某深基坑围护结构内力与变形影响分析[J]. 昆明工学院学报, 2010, 32(3): 100-103. (CHEN Yu-xiang. Analysis on the influence of ambient temperature to enclosure structure internal force and deformation in a deep foundation excavation[J]. Journal of Kunming University, 2010, 32(3): 100-103. (in Chinese)) [9] 庞卫涛. 深基坑支护结构变形随温度变化原因分析及加固处理措施[J]. 建筑工程, 2012(1): 10-12. (PANG Wei-tao. Supporting structure of deep foundation pit deformation with the reasons of temperature change analysis and reinforcement treatment measures[J]. Constructional Engineering, 2012(1): 10-12. (in Chinese))
