浅埋隧道围岩应力及位移的显式解析解

韩凯航; 张成平; 王梦恕

doi:10.11779/CJGE201412013

浅埋隧道围岩应力及位移的显式解析解 English Version

北京交通大学城市地下工程教育部重点实验室,北京 100044

基金项目: 国家自然科学基金项目（51378002,51008015）; 新世纪优秀人才支持计划（NCET-12-0770）; 中央高校基本科研业务费专项资金项目（2012JBZ013）

详细信息

作者简介:
韩凯航(1989- ),男,博士研究生,主要从事隧道及地下工程施工影响预测方面的研究。E-mail: han_kaihang@126.com。

通讯作者:
张成平

计量
- 文章访问数: 355
- HTML全文浏览量: 3
- PDF下载量: 416
出版历程
- 收稿日期: 2014-02-24
- 发布日期: 2014-12-25

Explicit analytical solutions for stress and displacement of surrounding rock in shallow tunnels

MOE Key Laboratory of Urban Underground Engineering, Beijing Jiaotong University, Beijing 100044, China

摘要

摘要: 浅埋隧道施工引起的地层位移将传递至地表进而形成地表沉降,施工前准确预测地层位移是有效控制地表沉降的前提。基于复变函数法,利用逆映射函数求解z平面复势函数的级数形式,并结合柯西-黎曼方程（C-R条件）对Verruijt提出的浅埋隧道围岩应力及位移隐式解析解中的解析函数求导,得出了浅埋隧道应力及位移函数的级数显式表达式;与Verruijt隐式解析解相比,该显式解析解直观,便于被工程人员使用,其编程计算量也较小;为确定显式解析解中的未知系数,基于浅埋隧道洞室变形产生的原因,提出了3种隧道洞室边界的变形模式和2种变形比率,合理调整变形比率可以实现多种边界条件组合。工程实测地层位移与显示解析解的计算结果吻合度高,验证了所提显式解析解的正确性和实用性。
- 浅埋隧道 /
- 应力和位移 /
- 显式解析解 /
- 变形模式 /
- 复变函数法
Abstract: The ground movements caused by urban shallow tunnelling can be passed to the ground surface and then form surface settlements. It is necessary to accurately predict the ground movements before tunnelling for effectively controlling the ground settlements. Based on the complex variable function method, the series forms of complex potential functions in z-plane are first obtained using the inverse mapping function. By taking the derivative of analytical functions proposed by Verruijt with Cauchy-Riemann equations, explicit analytical solutions for the stress and displacement induced by shallow tunnelling are obtained. The explicit solutions are intuitional and easily used by engineers, which have smaller amount of calculation than the solutions proposed by Verruijt. Moreover, by improving the previous researches on deformation modes of shallow tunnels, three deformation modes and two deformation ratios are put forward. Finaly, the explicit solutions are compared with the field test data of two tunnel projects, and the accuracy and practicability of the proposed explicit solutions are proved.
- shallow tunnel /
- stress and displacement /
- explicit analytical solution /
- deformation mode /
- complex variable function method

HTML全文

参考文献(13)

[1]	徐芝纶. 弹性力学[M]. 北京: 高等教育出版社, 2004. (XU Zhi-lun. Theory of elasticity[M]. Beijing: Higher Education Press, 2004. (in Chinese))
[2]	TIMOSHENKO S P, GOODIER J N. Theory of elasticity[M].北京: 清华大学出版社, 2004. (TIMOSHENKO S P, GOODIER J N. Theory of elasticity[M]. Beijing: Tsinghua University Press, 2004. (in Chinese))
[3]	MUSKHELISHVILI N I. Mathematical theory of elasticity[M]. Leyden: Noordhoff International Publishing, 1954.
[4]	VERRUIJT A. A complex variable solution for a deforming circular tunnel in an elastic half-plane[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1997, 21(2): 77-89.
[5]	VERRUIJT A. Deformations of an elastic half-plane with a circular cavity[J]. International Journal for Solids and Structures, 1998, 35(21): 2795-2804.
[6]	王立忠, 吕学金. 复变函数分析盾构隧道施工引起的地基变形[J]. 岩土工程学报, 2007, 29(3): 319-327. (WANG Li-zhong, LÜ Xue-jin. A complex variable solution for different kinds of oval deformation around circular tunnel in an elastic half plane[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(3): 319-327. (in Chinese))
[7]	晏莉, 阳军生, 刘宝琛. 浅埋双孔平行隧道开挖围岩应力和位移分析[J]. 岩土工程学报, 2011, 33(3): 413-419. (YAN Li, YANG Jun-sheng, LIU Bao-chen. Stress and displacement of surrounding rock with shallow twin-parallel tunnels[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(3): 413-419. (in Chinese))
[8]	王志良, 申林方, 姚激, 等. 浅埋隧道围岩应力场的计算复变函数求解法[J]. 岩土力学, 2010, 31(增刊1): 86-90. (WANG Zhi-liang, SHEN Lin-fang, YAO Ji, et al. Calculation of stress field in surrounding rocks of shallow tunnel using computational function of complex variable method[J]. Rock and Soil Mechanics, 2010, 31(S1): 86-90. (in Chinese))
[9]	BOBET A. Analytical solutions for shallow tunnels in saturated ground[J]. Journal of Engineering Mechanics, 2001, 127(12): 1258-1266.
[10]	LOGANATHAN N, POULOS H G. Analytical prediction for tunneling-induced ground movements in clays[J]. Journal of Geotechnical and Geoenvironmental Engineering, 1998, 124(9): 846-856.
[11]	PARK K H. Elastic solution for tunneling-induced ground movements in clays[J]. International Journal of Geomechanics, 2004, 4(4): 310-318.
[12]	PINTO F, WHITTLE A J. Ground movements due to shallow tunnels in soft ground. I: Analytical solutions[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2014, 140(4): 04013040.
[13]	PINTO F, ZYMNIS D M, WHITTLEA J. Ground movements due to shallow tunnels in soft ground. II: Analytical interpretation and prediction[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2014, 140(4): 04013041.
