盾构衬砌管片接头内力-变形统一模型及试验分析

朱合华; 黄伯麒; 李晓军; 桥本正

doi:10.11779/CJGE201412001

盾构衬砌管片接头内力-变形统一模型及试验分析 English Version

1. 同济大学土木工程防灾国家重点实验室、岩土及地下工程教育部重点实验室,上海 200092; 2. 日本大阪地域地层环境研究所,日本大阪

基金项目: 国家重点基础研究发展计划（973计划）项目; （2011CB013800）; 教育部创新团队发展计划项目（JTR1029）

详细信息

作者简介:
朱合华(1962- ),男,安徽巢湖人,工学博士,教授,主要从事隧道及地下建筑工程领域的教学和科研工作。E-mail: zhuhehua@tongji.edu.cn。

计量
- 文章访问数: 372
- HTML全文浏览量: 3
- PDF下载量: 513
出版历程
- 收稿日期: 2014-03-04
- 发布日期: 2014-12-25

Unified model for internal force and deformation of shield segment joints and experimental analysis

1. State Key Laboratory for Disaster Reduction in Civil Engineering and Key Laboratory of Geotechnical and Underground Engineering of the Ministry of Education, Tongji University, Shanghai 200092, China; 2. Geo-research Institute of Osaka, Osaka, Japan

摘要

摘要: 首先在钢筋混凝土管片系列接头试验的基础上,总结提出了接头弯矩-相对转角关系的线性、双线性和非线性模型,以及接头轴力-相对轴向变形和剪力-相对剪切变形关系的分段式模型,并给出了用于描述荷载偏心距和螺栓初始扭矩对于接头刚度影响的理论模型。其次,基于平板型和弧型管片接头的受弯试验结果,分别给出了在有无防水密封垫情况下各类转动刚度模型参数的取值方法,提出了不同条件下的转动刚度模型选择依据,研究了不同螺栓初始扭矩和轴力对接头转动刚度取值的影响;基于平板型管片接头剪切试验结果,分别给出了在有无防水密封垫情况下三阶段剪切刚度模型的参数取值方法。研究结果验证了各接头刚度模型的有效性,将对盾构衬砌结构梁-接头模型计算理论的应用起到重要的推动作用。
- 钢筋混凝土管片 /
- 管片接头 /
- 内力-变形统一模型 /
- 刚度参数
Abstract: First, based on a series of tests on reinforced concrete segment joints, the rotational moment-angle models for segment joints including linear, bilinear and nonlinear models and the axial force-deformation and shear force-deformation piecewise models are summarized and proposed, and the theoretical models are also given to describe the effect of the initial torque of bolts and axial force on joint stiffness. Second, based on the bending tests on flat plate segments and arch segments with or without sealing materials, the parameter determination methods for various stiffness models and the model selection principles are proposed, and the effect of the initial torque of bolts and axial force on joint stiffness is discussed. Based on the shear tests on flat plate segment joints with or without sealing materials, the parameter determination method for three-stage shear force resistance stiffness model is proposed. The results have proved the applicability of these joint stiffness models and will promote the application of beam-joint model theory in design practice.
- reinforced concrete segment /
- segment joint /
- unified model for internal force and deformation /
- stiffness parameter

HTML全文

参考文献(7)

[1]	朱合华, 崔茂玉, 杨金松. 盾构衬砌管片的设计模型与荷载分布的研究[J]. 岩土工程学报, 2000, 22(2): 190-194. (ZHU He-hua, CUI Mao-yu, YANG Jin-song. Design model for shield lining segments and distribution of loads[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(2): 190-194. (in Chinese))
[2]	张厚美, 过迟, 傅德明. 圆形隧道装配式衬砌接头刚度模型研究[J]. 岩土工程学报, 2000, 22(3): 309-313. (ZHANG Hou-mei, GUO Chi, FU De-ming. A study on the stiffness model of circular tunnel prefabricated lining[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(3): 309-313. (in Chinese))
[3]	蒋洪胜, 侯学渊. 盾构法隧道管片接头转动刚度的理论研究[J]. 岩石力学与工程学报, 2004, 23(9): 1574-1577. (JIANG Hong-sheng, HOU Xue-yuan. Theoretical study of rotational stiffness of joint in shield tunnel segments[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(9): 1574-1577. (in Chinese))
[4]	朱伟, 钟小春, 秦建设. 盾构衬砌管片接头力学分析及双直线刚度模型研究[J]. 岩土力学, 2006, 27(12): 2154-2158. (ZHU Wei, ZHONG Xiao-chun, QIN Jian-she. Mechanical analysis of segment joint of shield tunnel and research on bilinear joint stiff model[J]. Rock and Soil Mechanics, 2006, 27(12): 2154-2158. (in Chinese))
[5]	张冬梅, 樊振宇, 黄宏伟. 考虑接头力学特性的盾构隧道衬砌结构[J]. 岩土力学, 2010, 21(8): 2546-2551. (ZHANG Dong-mei, FAN Zhen-yu, HUANG Hong-wei. Calculation method of shield tunnel lining considering mechanical characteristics of joints[J]. Rock and Soil Mechanics, 2010, 31(8): 2546-2551. (in Chinese))
[6]	郭瑞, 何川, 封坤, 等. 大断面水下盾构隧道管片接头抗弯刚度及其对管片内力影响研究[J]. 中国铁道科学, 2013, 34(5): 46-53. (GUO Rui, HE Chuan, FENG Kun. Bending stiffness of segment joint and its effects on segment internal force for underwater shield tunnel with large cross section[J]. China Railway Science, 2013, 34(5): 46-53. (in Chinese))
[7]	孙钧, 汪炳鉴. 地下结构有限元法解析[M]. 上海: 同济大学出版社, 1988: 223-224. (SUN Jun, WANG Bing-jian. Finite element analysis of underground structure[M]. Shanghai: Tongji University Press, 1988: 223-224. (in Chinese))
