基于透明土的管桩贯入特性模型试验研究

曹兆虎; 孔纲强; 刘汉龙; 周航

doi:10.11779/CJGE201408025

基于透明土的管桩贯入特性模型试验研究 English Version

曹兆虎^{1, 2},
孔纲强^{1, 2},
刘汉龙^{1, 2},
周航^{1, 2}

1. 岩土力学与堤坝工程教育部重点实验室,江苏南京 210098; 2. 河海大学土木与交通学院,江苏南京 210098

基金项目: 国家自然科学基金项目（51278170）; 国家自然科学基金高铁联合基金项目（U1134207）; 长江学者和创新团队发展计划项目（IRT1125）

详细信息

作者简介:
曹兆虎(1986- ),男,江苏盐城人,博士研究生,主要从事岩土工程可视化及桩基础方面的研究工作。E-mail: caozhaohuzj@sina.com。

中图分类号: TU470
计量
- 文章访问数: 498
- HTML全文浏览量: 4
- PDF下载量: 768
出版历程
- 收稿日期: 2013-11-02
- 发布日期: 2014-08-18

Model tests on pipe pile penetration by using transparent soils

CAO Zhao-hu^{1, 2},
KONG Gang-qiang^{1, 2},
LIU Han-long^{1, 2},
ZHOU Hang^{1, 2}

1. Key Laboratory of Geomechanics and Embankment Engineering (Hohai University), Ministry of Education, Nanjing 210098, China; 2. College of Civil and Transportation Engineering, Hohai University, Nanjing 210098, China

摘要

摘要: 由于受土塞效应等因素影响,开口管桩和闭口管桩在贯入过程中的挤土效应存在明显的差异;然而针对该两者贯入特性的研究相对较少。基于透明土和PIV（Particle Image Velocimetry）技术,开发了相应的桩基贯入模型试验系统,用于桩基贯入过程中桩周土体变形的非插入式测量。试验选用的透明土由玻璃砂和具有相同折射率的孔隙液体制成。该试验系统主要包括：线性激光光源、CCD（Charge-Coupled Device）相机、自动沉桩加载仪和计算机控制系统等。激光射入透明土,和透明土之间的相互作用产生了独特的散斑场,通过CCD相机摄取贯入过程中各个时刻散斑场变形的图片,然后通过PIV技术对这些变形前后的图片进行处理,即可得到整个土体位移场。分别进行了开口管桩和闭口管桩的桩基贯入试验,得到了对应的土体位移场,并对桩基贯入引起的桩周土体径向位移试验结果与圆孔扩张法、应变路径法等理论计算结果进行对比分析;研究结果表明,对于闭口管桩,由于竖向位移的影响,试验值比圆孔扩张法结果小,其与应变路径法更为接近;对于开口管桩,由于沉桩过程中土塞作用,试验值比圆孔扩张法大,其影响不可忽略。
- 开口管桩 /
- 闭口管桩 /
- 模型试验 /
- 位移场 /
- 透明土 /
- PIV技术
Abstract: The squeezing effects of open-ended and closed-ended pipe piles are obviously different because of “soil plug”. However, the researches focused on this problem are relatively little. One small-scale model test system is developed to study the non-intrusive measurement of the soil deformation during pile penetration using the transparent soils and PIV (particle image velocimetry) technique. The transparent soils are manufactured by baked quartz with a pore fluid which has the same refraction index. The test system contains a line laser light, a CCD (charge-coupled device) camera, a loading machine and a computer. The whole displacement field during the pile penetration can be obtained as follows: a distinctive laser speckle pattern can be generated by the interaction between the laser and the transparent soils when the light goes through the transparent soils. Then a sequence of speckle pattern images are captured consecutively during the pile penetration by the CCD camera. Finally these images are analyzed by using PIV. The model tests on the penetration of an open-ended pipe pile and a closed-ended pipe pile are both carried out, and the data are compared with the results obtained by the cavity expansion method and strain path method. The results show that, for the closed-ended pipe pile, the radical displacements obtained by the model tests are smaller than those by the cavity expansion method, and are close to those obtained by the strain path method; for the open-ended pipe pile, the “soil plug” obtained by the model tests is larger than that obtained by the cavity expansion method.
- open-ended pipe pile /
- closed-ended pipe pile /
- model test /
- displacement field /
- transparent soil /
- PIV technique

HTML全文

参考文献(17)

[1]	PAIKOWSKY S G, WHITMAN R V, BALIGH M M. A new look at the phenomenon of offshore pile plugging[J]. Marine Geotechnology, 1989, 8(3): 213-230.
[2]	郑俊杰, 聂重军, 鲁燕儿. 基于土塞效应的柱形孔扩张问题解析解[J]. 岩石力学与工程学报, 2006, 25(增刊2): 4004-4008. (ZHENG Jun-jie, NIE Chong-jun, LU Yan-er. Analytical solutions of cylindrical cavity expansion problems considering plugging effects[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(S2): 4004-4008. (in Chinese))
[3]	AZZOUZ A S, BALIGH M M. Behavior of friction piles in plastic empire clays[R]. Cambridge：Massachusetts Institute of Technology, 1984.
[4]	雷华阳, 李肖, 陆培毅, 等. 管桩挤土效应的现场试验和数值模拟[J]. 岩土力学, 2012, 33(4): 1006-1012. (LEI Hua-yang, LI Xiao, LU Pei-yi, et al. Field test and numerical simulation of squeezing effect of pipe pile[J]. Rock and Soil Mechanics, 2012, 33(4): 1006-1012. (in Chinese))
[5]	RANDOLPH M F, STEENFELT J S, WORTH C P. Effect of pile type on design parameters for driven piles[C]// Proceeding of the European Conference on Soil Mechanics and Foundation Engineering, Brighton, 1979: 107-114.
[6]	ISKANDER M, LAI J, OSWALD C, et al. Development of a transparent material to model the geotechnical properties of soils[J]. Geotechnical Testing Journal, 1994, 17(4): 425-433.
[7]	LEHANE B M, GILL D R. Displacement fields induced by penetrometer installation in an artificial soil[J]. International Journal of Physical Modelling in Geotechnics, 2004, 1(1): 25-36.
[8]	WHITE D J, TAKE W A, BOLTON M D. Soil deformation measurement using particle image velocimetry (PIV) and photogrammetry[J]. Géotechnique, 2003, 53(7): 619-631.
[9]	WHITE D J, BOLTON M D. Displacement and strain paths during plane-strain model pile installation in sand[J]. Géotechnique, 2004, 54(6): 375-397.
[10]	ISKANDER M, SADEK S, LIU Jin-yuan. Optical measurement of deformation using transparent silica to model sand[J]. International Journal of Physical Modelling in Geotechnics, 2002, 2(4): 13-26.
[11]	CAO Zhao-hu, LIU Jin-yuan, LIU Han-long. Transparent fused silica to model natural sand[C]// Pan-am CGS Geotechnical Conference. Toronto, 2011.
[12]	孔纲强, 刘璐, 刘汉龙, 等. 玻璃砂透明土与标准砂变形特性对比三轴试验研究[J]. 岩土工程学报, 2013, 35(6): 1140-1146. (KONG Gang-qiang, LIU Lu, LIU Han-long, et al. Comparative analysis on the deformation characteristics of transparent glass sand and standard sand[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1140-1146. (in Chinese))
[13]	孔纲强, 刘璐, 刘汉龙, 等. 玻璃砂透明土与标准砂强度特性对比试验研究[J]. 建筑材料学报, 2014, 17(2): 250-255. (KONG Gang-qiang, LIU Lu, LIU Han-long, et al. Comparative analysis on the strength characteristics of transparent glass sand and standard sand[J]. Journal of Building Materials, 2014, 17(2): 250-255. (in Chinese))
[14]	佘跃心. 基于透明介质和颗粒图像技术的土体变形测量研究进展[J]. 勘察科学技术, 2005(6): 7-10. (SHE Yue-xin. Research progress in soil deformation measurement using transparent media and particle image velocimetry[J]. Chinese Journal of Site Investigation Science and Technology, 2005(6): 7-10. (in Chinese))
[15]	SADEK S, ISKANDER M, LIU Jin-yuan. Accuracy of digital image correlation for measuring deformations in transparent media[J]. Journal of Computing in Civil Engineering, 2003, 17(2): 88-96.
[16]	NI Qing, HIRD C C, GUYMER I. Physical modelling of pile penetration in clay using transparent soil and particle image velocimetry[J]. Géotechnique, 2010, 60(2): 121-132.
[17]	LIU Han-long, CHU Jian, DENG An. Use of large-diameter, cast-in situ concrete pipe piles for embankment over soft clay[J]. Canadian Geotechnical Journal, 2009, 46(8): 915-927.
