基于锈胀开裂的预应力锚杆（索）使用寿命预测研究

邓东平; 李亮; 赵炼恒; 刘剑豪

doi:10.11779/CJGE201408012

基于锈胀开裂的预应力锚杆（索）使用寿命预测研究 English Version

中南大学土木工程学院,湖南长沙 410075

基金项目: 教育部博士研究生学术新人奖项目（114801045）; 湖南省研究生科研创新项目（CX2012B056）; 贵州省交通运输厅科技项目（2010-122-020）

详细信息

作者简介:
邓东平(1985- ),男,湖南岳阳人,博士研究生,主要从事道路与铁道工程方面的工作。E-mail: dengdp851112@126.com。

中图分类号: TU375
计量
- 文章访问数: 354
- HTML全文浏览量: 2
- PDF下载量: 276
出版历程
- 收稿日期: 2013-09-22
- 发布日期: 2014-08-18

Prediction of service life of pre-stressed anchorage bolt (cable) due to corrosion expansion

College of Civil Engineering, Central South University, Changsha 410075, China

摘要

摘要: 锚杆（索）腐蚀后其体积发生膨胀并形成锈胀力,而锈胀力的增大可导致外围注浆体开裂,从而加速锚杆（索）的腐蚀,故可以此时的锈蚀量作为预测锚杆（索）使用寿命的判别条件。当对外围注浆体进行受力分析时,采用平面应变情况下的圆孔模型弹性理论计算注浆体开裂时的极限锈胀力,并以锚杆（索）与外围注浆体接触面的变形协调条件来计算极限锈胀力时的锚杆（索）锈蚀量。同时,比例参数λ被采用来考虑岩土体对锚固体的约束作用,且将是否考虑注浆体内部裂缝影响作为2种方法计算锈胀力作用下的注浆体变形。然后,将参数选取在一定范围内经曲线拟合得极限锈胀力及对应锚杆（索）锈蚀量的简单表达式,进而根据2种不同适用条件下的锚杆（索）锈蚀速率计算式对锚杆（索）的使用寿命进行预测和分析。经算例对比验证了本文方法的可行性,并对锚杆（索）使用寿命的影响因素进行了参数分析,可知：①不考虑注浆体内部裂缝影响而计算得的锚杆（索）锈蚀量值偏于保守;②外围岩土对注浆体的约束作用对锚杆（索）的使用寿命有积极影响;③铁锈体积膨胀率n对锚杆（索）的使用寿命影响微小,而注浆体泊松比μ_c和保护层厚度c越大则锚杆（索）的使用寿命越长。
- 锚杆（索） /
- 外围注浆体 /
- 锈胀力 /
- 锈蚀量 /
- 锈蚀速率 /
- 使用寿命
Abstract: After it is corroded, the volume of anchorage bolt (cable) expands and corrosion expansion force is generated. With the increase of corrosion expansion force, peripheral grout appears to crack, which accelerates its corrosion, so the corrosion amount at this moment should be taken as the criterion to predict its service life. For analyzing the force of peripheral grout, the elastic theory of hole model under plane strain is adopted to calculate the limit corrosion expansion force at the time of grout cracking, and the deformation compatibility condition of contact surface between anchorage bolt (cable) and peripheral grout is used to calculate its corrosion amount corresponding to the limit corrosion expansion force. Meanwhile, the proportional parameter λ is adopted to consider geotechnical constraints on anchoring body, and two methods (with or without considering effect of internal cracks in grout) are used to calculate deformation of grout generated by corrosion expansion force. Then simple formulas for calculating the limit corrosion expansion force and the amount of its corresponding corrosion are attained after curve fitting in a certain range of parameters, and using two kinds of formulas for calculating corrosion rate of anchorage bolt (cable) under different applicable conditions, the service life of anchorage bolt (cable) can be predicted and analyzed. By comparing with examples, the feasibility of the proposed method is verified, and parameters affecting the service life of anchorage bolt (cable) are analyzed. It shows that: (1) The calculated amount of anchorage corrosion without considering effect of internal cracks in grout is more conservative. (2) The constraint of peripheral geotechnical body on grout has positive impact on the service life of anchorage bolt (cable). (3) The volume expansion rate n of rust has the minimum impact on the service life of anchorage bolt (cable), and the greater the Poisson’s ratio of grout (μ_c) and the thickness of protective layer (c), the longer the service life of anchorage bolt (cable).
- anchorage bolt (cable) /
- peripheral grout /
- corrosion expansion force /
- corrosion amount /
- corrosion rate /
- service life

HTML全文

参考文献(19)

[1]	李英勇. 岩土预应力锚固系统长期稳定性研究[D]. 北京:北京交通大学, 2008: 1-19. (LI Ying-yong. Study on long term stability of geotechnical Pre-stressed anchor system[D]. Beijing：Beijing Jiaotong University, 2008: 1-19. (in Chinese))
[2]	赵晓彦, 张京伍, 梁瑶, 等. 花岗岩类土质边坡主被动组合锚固设计方法[J]. 岩石力学与工程学报, 2013, 32(3): 633-639. (ZHAO Xiao-yan, ZHANG Jing-wu, LIANG Yao, et al. Design method for combined active/passive anchoring for granitoid soil slope[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(3): 633-639. (in Chinese))
[3]	何思明, 王全才, 罗渝. 钢绞线锈蚀对预应力锚索荷载传递特性的影响[J]. 四川大学学报（工程科学版）, 2010, 42(1): 1-4. (HE Si-ming, WANG Quan-cai, LUO Yu. Impact of steel strand corrosion on pr-stressed anchor cable load transfer characteristic[J]. Journal of Sichuan University (Engineering Science Edition), 2010, 42(1): 1-4. (in Chinese))
[4]	洪海春, 徐卫亚. 全长粘结式预应力锚索锈胀开裂时服务年限研究[J]. 岩土力学, 2008, 29(4): 949-953. (HONG Hai-chun, XU Wei-ya. Research on service life of wholly bonded pre-stressed cable when corrosion expansion cracking[J]. Rock and Soil Mechanics, 2008, 29(4): 949-953. (in Chinese))
[5]	吴瑾, 吴胜兴. 氯离子环境下钢筋混凝土结构耐久性寿命评估[J]. 土木工程学报, 2005, 38(2): 59-63. (WU Jin, WU Sheng-xing. Durability assessment for reinforced concrete structures in chloride environment[J]. Journal of China Civil Engineering, 2005, 38(2): 59-63. (in Chinese))
[6]	金伟良, 鄢飞, 张亮. 考虑混凝土碳化规律的钢筋锈蚀率预测模型[J]. 浙江大学学报(工学版), 2000, 34(2): 158-163. (JIN Wei-liang, YAN Fei, ZHANG Liang. A pre-determinate model of steel bar corrosion ratio considered of concrete carbonation model[J]. Journal of Zhejiang University (Engineering Science), 2000, 34(2): 158-163. (in Chinese))
[7]	郑静, 曾辉辉, 朱本珍. 腐蚀对锚索力学性能影响的试验研究[J]. 岩石力学与工程学报, 2010, 29(12): 2469-2474. (ZHENG Jing, ZENG Hui-hui, ZHU Ben-zhen. Test study of influence of erosion on mechanical behavior of anchor[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(12): 2469-2474. (in Chinese))
[8]	赵健, 冀文政, 肖玲, 等. 锚杆耐久性现场试验研究[J]. 岩石力学与工程学报, 2006, 25(7): 1377-1385. (ZHAO Jian, JI Wen-zheng, XIAO Ling, et al. In-situ experimental study on anchor durability[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(7): 1377-1385. (in Chinese))
[9]	杨启贵, 高大水, 吴海斌. 对我国岩土预应力锚索防腐措施和标准的探讨[J]. 岩土工程学报, 2007, 29(10): 1558-1562. (YANG Qi-gui, GAO Da-shui, WU Hai-bin. Discussion on antiseptic measures and standards of geotechnical pre-stressed anchorage cables in China[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(10): 1558-1562. (in Chinese))
[10]	任爱武, 汪彦枢, 王玉杰, 等. 拉力集中全长黏结型锚索长期耐久性研究[J]. 岩石力学与工程学报, 2011, 30(3): 493-499. (REN Ai-wu, WANG Yan-shu, WANG Yu-jie, et al. Research on durability of concentrated tension and full-bonded anchor cables[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(3): 493-499. (in Chinese))
[11]	赵羽习, 金伟良. 混凝土构件锈蚀胀裂时的钢筋锈蚀率[J]. 水利学报, 2004, 49(11): 97-101. (ZHAO Yu-xi, JIN Wei-liang. Corrosion ratio of reinforcement bar in reinforced concrete construction at the moment of cracking due to corrosion expansion[J]. Journal of Hydraulic Engineering, 2004, 49(11): 97-101. (in Chinese))
[12]	金伟良, 赵羽习, 鄢飞. 钢筋混凝土构件的均匀钢筋锈胀力的机理研究[J]. 水利学报, 2001, 46(7): 57-62. (JIN Wei-liang, ZHAO Yu-xi, YAN Fei. The mechanism of corroded expansion force of reinforced concrete members[J]. Journal of Hydraulic Engineering, 2001, 46(7): 57-62. (in Chinese))
[13]	李海波, 鄢飞, 赵羽习, 等. 钢筋混凝土结构开裂时刻的钢筋锈胀力模型[J]. 浙江大学学报(工学版), 2000, 34(4): 415-422. (LI Hai-bo, YAN Fei, ZHAO Yu-xi, et al. Model of corroded expansion force at cracking on reinforced concrete structures[J]. Journal of Zhejiang University (Engineering Science), 2000, 34(4): 415-422. (in Chinese))
[14]	金伟良, 赵羽习, 鄢飞. 钢筋混凝土构件的均匀钢筋锈胀力及其影响因素[J]. 工业建筑, 2001, 31(5): 6-8. (JIN Wei-liang, ZHAO Yu-xi, YAN Fei. Corroded expansion force of reinforced concrete members and its influence factors[J]. Industrial Construction, 2001, 31(5): 6-8. (in Chinese))
[15]	吴相豪. 海洋环境中钢筋混凝土构件锈胀开裂时间的解析解[J]. 上海海事大学学报, 2006, 27(3): 22-26. (WU Xiang-hao. Analytical solution for cracking time of reinforced concrete structure due to corrosion expansion in marine environment[J]. Journal of Shanghai Maritime University, 2006, 27(3): 22-26. (in Chinese))
[16]	张志亮. 预应力锚索耐腐蚀性及失效研究[D]. 北京: 中国地质大学, 2008: 11-33. (ZHANG Zhi-liang. The research of pre-stressed anchorage cable corrosion resistance and inactivation[D]. Beijing: China University of Geosciences, 2008: 11-33. (in Chinese))
[17]	牛荻涛. 混凝土结构耐久性与寿命预测[M]. 北京: 科学出版社, 2003: 52-74. (NIU Di-tao. Durability and life prediction of concrete structures[M]. Beijing: Science Press, 2003: 52-74. (in Chinese))
[18]	卫军, 桂志华, 王艺霖. 混凝土中钢筋锈蚀速率的预测模型[J]. 武汉理工大学学报, 2005, 27(6): 45-47. (WEI Jun, GUI Zhi-hua, WANG Yi-lin. Modeling on predicting steel corrosion rate in concrete[J]. Journal of wuhan university of technology, 2005, 27(6): 45-47. (in Chinese))
[19]	曾宪明, 雷志梁, 张文巾, 等. 关于锚杆“定时炸弹”问题的讨论—答郭映忠教授[J]. 岩石力学与工程学报, 2004, 23(13): 2235-2242. (ZENG Xian-ming, LEI Zhi-liang, ZHANG Wen-jin, et al. Discussion about “time bomb” question for bolt-an answer to professor Guo Ying-zhong[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(13): 2235-2242. (in Chinese))
