盾构掘进地面沉降虚拟镜像算法

林存刚; 夏唐代; 梁荣柱; 吴世明

doi:10.11779/CJGE201408009

盾构掘进地面沉降虚拟镜像算法 English Version

1. 宁波大学建筑工程与环境学院,浙江宁波 315211; 2. 浙江大学建筑工程学院,浙江杭州 310058; 3. 杭州庆春路过江隧道有限公司,浙江杭州 310002

详细信息

作者简介:
林存刚(1986- ),男,山东平邑人,博士,讲师,主要从事盾构隧道施工环境影响及隧道结构稳定性的研究。E-mail: cunganglin@163.com。

中图分类号: TU455.43
计量
- 文章访问数: 432
- HTML全文浏览量: 9
- PDF下载量: 415
出版历程
- 收稿日期: 2014-01-17
- 发布日期: 2014-08-18

Estimation of shield tunnelling-induced ground surface settlements by virtual image technique

1. College of Civil, Construction and Environmental Engineering, Ningbo University, Ningbo 315211, China; 2. College of Civil Engineering and Architecture, Zhejiang University, Hangzhou 310058, China; 3. Hangzhou Qing-chun Road Cross-River Tunnel Company Limited, Hangzhou 310002, China

摘要

摘要: 盾构掘进所致地面沉降的准确预估,对于邻近建（构）筑物的保护至关重要。假定土体为均质各向同性半无限空间不可压缩弹性体,基于虚拟镜像技术,推导了在隧道边界土层不同收敛模式下的地面沉降计算公式,计算结果比数值积分算法更接近实测。由于实际土体具有各向异性、成层性和可压缩性,本文算法与数值积分算法均高估了横向地面沉降槽宽度。引入沉降槽宽度修正参数对理论公式进行修正,修正算法计算结果更符合实际,可简单可靠地估算盾构隧道施工地层损失引起的地面沉降。
- 虚拟镜像技术 /
- 盾构隧道 /
- 现场实测 /
- 地面沉降
Abstract: The accurate estimation of ground surface subsidence induced by shield tunnelling is crucial to the protection of buildings or structures in the vicinity. Under the hypothesis that the soil is a homogeneous isotropic incompressible linear-elastic semi-infinite half-space, equations for calculation of tunnelling-induced ground surface settlements under different surrounding soil intrusion models are derived based on the virtual image technique. Compared with those of numerical integration methods, the predicted results by the proposed method are more accurate. For the soil in reality is anisotropic, layered and compressible, the transverse ground surface settlement trough width is over-estimated both by this study and the numerical integration method. A modification parameter of trough width is introduced into the deduced formula. The modified method is proved by the field observations to be an easy and reliable method for prediction of ground surface settlements resulting from ground loss during construction of shield-driven tunnels.
- virtual image technique /
- shield-driven tunnel /
- field observation /
- ground surface settlement

HTML全文

参考文献(15)

[1]	SAGASETA C. Analysis of undrained soil deformation due to ground loss[J]. Géotechnique, 1987, 37(3): 301-320.
[2]	VERRUIJT A, BOOKER J R. Surface settlements due to deformation of a tunnel in an elastic half plane[J]. Géotechnique, 1996, 46(4): 753-756.
[3]	LOGANATHAN N, POULOS H G. Analytical prediction for tunneling-induced ground movements in clays[J]. Journal of Geotechnical and Geoenvironmental Engineering, 1998, 124(9): 846-856.
[4]	LEE K M, ROWE R K, LO K Y. Subsidence owing to tunneling: I Estimating the gap parameter[J]. Canadian Geotechnical Journal, 1992, 29(6): 929-940.
[5]	LOGANATHAN N, POULOS H G, XU K J. Ground and pile-group responses due to tunnelling[J]. Soils and Foundations, 2001, 41(1): 57-67.
[6]	CHI S Y, CHERN J C, LIN C C. Optimized back-analysis for tunneling-induced ground movement using equivalent ground loss model[J]. Tunnelling and Underground Space Technology, 2001, 16(3): 159-165.
[7]	PARK K H. Elastic solution for tunneling-induced ground movements in clays[J]. International Journal of Geomechanics, 2004, 4(4): 310-318.
[8]	PARK K H. Analytical solution for tunnelling-induced ground movement in clays[J]. Tunnelling and Underground Space Technology, 2005, 20(3): 249-261.
[9]	姜忻良, 赵志民. 镜像法在隧道施工土体位移计算中的应用[J]. 哈尔滨工业大学学报, 2005, 27(6): 801-803. (JIANG Xin-liang, ZHAO Zhi-min. Application of image method in calculating tunneling-induced soil displacement[J]. Journal of Harbin Institute of Technology, 2005, 27(6): 801-803.(in Chinese))
[10]	姜忻良, 赵志民. 盾构施工引起土体位移的空间计算方法[J]. 华中科技大学学报 (城市科学版),2005, 22(2): 1-12. (JIANG Xin-liang, ZHAO Zhi-min. 3-D analysis method used to calculate shield tunneling induced soil displacements[J]. Journal of Huazhong University of Science and Technology (Urban Science Edition), 2005, 22(2): 1-12. (in Chinese))
[11]	卢海林, 赵志民, 方芃, 等. 盾构法隧道施工引起土体位移与应力的镜像分析方法[J]. 岩土力学, 2007, 28(1): 45-50. (LU Hai-lin, ZHAO Zhi-min, FANG Peng, et al. Analytical method of image theory used to calculate shield tunneling induced soil displacements and stresses[J]. Rock and Soil Mechanics, 2007, 28(1): 45-50. (in Chinese))
[12]	LIN C G, ZHANG Z M, WU S M, et al. Key techniques and important issues for slurry shield under-passing embankments: A case study of Hangzhou Qiantang River Tunnel[J]. Tunnelling and Underground Space Technology, 2013, 38: 306-325.
[13]	SAGASETA C. Discussion: Analysis of undrained soil deformation due to ground loss[J]. Géotechnique, 1988, 38(4): 647-649.
[14]	PECK R B. Deep excavations and tunneling in soft ground[C]// State of the Art Report. Proceedings of 7th International Conference on Soil Mechanics and Foundation Engineering. Mexico City, 1969: 225-290.
[15]	VERRUIJT A, BOOKER J R. Discussion: surface settlements due to deformation of a tunnel in an elastic half plane[J]. Géotechnique, 1998, 48(5): 709-713.
