三轴卸荷条件下大理岩扩容与能量特征分析

陈学章; 何江达; 肖明砾; 谢红强; 刘建锋

doi:10.11779/CJGE201406016

三轴卸荷条件下大理岩扩容与能量特征分析 English Version

陈学章^{1, 2},
何江达^{1, 2},
肖明砾^{1, 2},
谢红强^1,2,,
刘建锋^{1, 2}

1. 四川大学水力学与山区河流开发保护国家重点实验室,四川成都 610065; 2. 四川大学水利水电学院,四川成都 610065

基金项目: 国家自然科学基金项目（51079092）

详细信息

作者简介:
陈学章（1990- ）,男,硕士研究生,主要研究方向为岩石力学与工程。E-mail: chenxuezhang90@163.com。

通讯作者:
谢红强

中图分类号: TU456
计量
- 文章访问数: 461
- HTML全文浏览量: 1
- PDF下载量: 346
出版历程
- 收稿日期: 2013-11-28
- 发布日期: 2014-06-19

Dilatancy and energy properties of marble under triaxial unloading condition

CHEN Xue-zhang^{1, 2},
HE Jiang-da^{1, 2},
XIAO Ming-li^{1, 2},
XIE Hong-qiang^1,2,,
LIU Jian-feng^{1, 2}

1. State Key Lab. of Hydraulics and Mountain River Engineering, Sichuan University, Chengdu 610065, China; 2. College of Water Resources & Hydropower, Sichuan University, Chengdu 610065, China

摘要

摘要: 扩容现象是岩石变形破坏过程中的重要特征。基于MTS815 Flex Test GT岩石力学试验平台,采用室内三轴卸荷试验和塑性力学理论分析,揭示了大理岩在卸荷条件下的扩容特征及能量变化特征。结果表明,随着围压的增大,岩样的各特征应力随之增大,其扩容特征随之减弱；岩样的扩容参数——扩容指标以及剪胀角均具有围压效应,即扩容指标与围压呈良好的指数型分布,剪胀角与应力比呈线性分布；岩样的卸荷破坏过程中能量特征为初始时以可释放应变能为主到破坏时的耗散能为主,其间的转折点为初始损伤扩容点,同时卸荷条件下的特征能量值与围压具有良好的指数类型关系；在峰值点与残余点处,岩样的能量损伤值与剪胀角以及能量特征值与扩容指标均存在着较好的指数类型关系。
- 岩石力学 /
- 大理岩 /
- 三轴卸荷 /
- 扩容 /
- 能量特征 /
- 相关性分析
Abstract: Dilatancy is an important feature of rock during deformation and failure processes. By means of the MTS815 servo-controlled test machine, laboratory triaxial unloading experiments and plasticity theory analysis are made to obtain the characteristics of dilatancy and energy change of marble under unloading condition. The results show that the characteristic stress of rock samples increase and the dilatancy characteristics decrease with the increase of the confining pressure. The dilatancy parameters of rock samples, dilatancy index and dilatancy angle, have obvious effects of confining pressure. The dilatancy index and confining pressure have good exponential distribution, and the relationship between dilatancy angle and stress ratio is linearly distributed. The energy characteristics of rock samples under unloading destruction process are that the main energy is releasable strain energy at the initial stage and dissipation energy at the failure stage, and the turning point between these two stages is the initial damage dilatancy point. Meanwhile the characteristic energy value and confining pressure under unloading condition have a good exponential relationship. Both at the peak point and the residual point, the relationship both between the energy damage amount and the dilatancy angle and between the energy eigenvalues and the dilatancy index has a good exponential distribution.
- rock mechanics /
- marble /
- triaxial unloading /
- dilatancy /
- energy property /
- correlation analysis

HTML全文

参考文献(18)

[1]	钱七虎. 深部地下工程空间开发中的关键科学问题[M]// 钱七虎院士论文选集. 北京: 科学出版社, 2007: 549-568. (QIAN Qi-hu. The key problems of deep underground space development[M]// Selections from Academician QIAN Qihu's Theses. Beijing: Science Press, 2007: 549-568. (in Chinese))
[2]	何满潮, 谢和平, 彭苏萍, 等. 深部开采岩体力学研究[J]. 岩石力学与工程学报, 2005, 24(16): 2803-2813. (HE Man-chao, XIE He-ping, et al. Study on rock mechanics in deep mining engineering[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(16): 2803-2813. (in Chinese))
[3]	黄润秋, 黄达. 卸荷条件下岩石变形特性及本构模型研究[J]. 地球科学进展, 2008, 23(5): 441-447. (HUANG Run-qiu, HUANG Da. Study on deformation characteristics and constitutive model of rock on the condition of unloading[J]. Advances in Earth Science, 2008, 23(5): 441-447. (in Chinese))
[4]	王贤能, 黄润秋. 岩石卸荷破坏特征与岩爆效应[J]. 山地研究, 1998, 16(4): 281-285. (WANG Xian-neng, HUANG Run-qiu. Analysis of deformation and fracture features of rock under unloading condition and their effection rock burst[J]. Mountain Research, 1998, 16(4): 281-285. (in Chinese))
[5]	高春玉, 徐进, 何鹏. 大理岩加卸载力学特性的研究[J]. 岩石力学与工程学报, 2005, 24(3): 456-460. (GAO Yu-chun, XU Jin, HE Peng. Study on mechanical properties of marble under loading and unloading conditions[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(3): 456-460. (in Chinese))
[6]	陈卫忠, 刘豆豆, 杨建平. 大理岩卸围压幂函数型Mohr 强度特性研究[J]. 岩石力学与工程学报, 2008, 27(11): 2214-2220. (CHEN Wei-zhong, LIU Dou-dou, YANG Jian-ping. Power function based Mohr strength criterion for marble with unloading confining pressures[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(11): 2214-2220. (in Chinese))
[7]	MATSUSHIMA S. On the flow and fracture of igneous rocks and on the deformation and fracture of granite under high confining pressure[M]. Kyoto: Bulletin of the Disaster Prevention Research Institute, Kyoto University, 1960: 20-26.
[8]	YUAN Shih-che, HARRISON J P. A empirical dilatancy index for the dilatant deformation of rock[J]. International Journal of Rock Mechanics & Mining Sciences, 2004, 41: 679-686.
[9]	ALEJANO L R, ALONSO E. Considerations of the dilatancy angle in rocks and rock masses[J]. International Journal of Rock Mechanics & Mining Sciences, 2005, 32: 481-507.
[10]	MAHMUTOGLU Y, VARDAR M. Effects of inelastic volume increase on fractured rock behaviour[J]. Bulletin of Engineering Geology and the Environment, 2003, 62: 117-121.
[11]	陈宗基, 康文法. 在岩石破坏和地震之前与时间有关的扩容[J]. 岩石力学与工程学报, 1983, 2(1): 11-21. (TAN Tjiong-kie, KANG Wen-fa. Time dependent dilatancy prior to rock failure and earthquakes[J]. Chinese Journal of Rock Mechanics and Engineering, 1983, 2(1): 11-21. (in Chinese))
[12]	陈宗基, 石泽全, 于智海, 等. 用8000 kN 多功能三轴仪测量脆性岩石的扩容、蠕变及松弛[J]. 岩石力学与工程学报, 1989, 8(2): 97-118. (TAN Tjiong-kie, SHI Zhe-quan, YU Zhi-hai, et al. Dilatancy creep and relaxation of brittle rocks measured with the 8000 kN multipurpose triaxial apparatus[J]. Chinese Journal of Rock Mechanics and Engineering, 1989, 8(2): 97-118. (in Chinese))
[13]	陈宗基, 康文法. 岩石的封闭应力、蠕变和扩容及本构方程[J]. 岩石力学与工程学报, 1991, 10(4): 200-312. (TAN Tjiong-kie, KANG Wen-fa. On the locked in stress, creep and dilatation of rocks, and the constitutive equations[J]. Chinese Journal of Rock Mechanics and Engineering, 1991, 10(4): 200-312. (in Chinese))
[14]	谢和平, 鞠杨, 魏立云, 等. 基于能量耗散与释放原理的岩石强度与整体破坏准则[J]. 岩石力学与工程学报, 2005, 24(17): 3003-3010. (XIE He-ping, JU Yang, et al. Criteria for strength and structural failure of rocks based on energy dissipation and energy release principles[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(17): 3003-3010. (in Chinese))
[15]	谢和平, 彭瑞东, 鞠杨, 等. 岩石变形破坏过程中的能量耗散分析[J]. 岩石力学与工程学报, 2004, 23(21): 3565-3570. (XIE He-ping, PENG Rui-dong, JU Yang, et al. Energy dissipation of rock deformation and fracture[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(21): 3565-3570. (in Chinese))
[16]	TSOUTHRELIS C E, EXADAKTYLOS G E. Effect of rock discontinuities on certain rock strength and fracture energy parameters under uniaxial compression[J]. Geotechnical and Geological Engineering, 1993, 11(2): 81-105.
[17]	苏承东, 张振华. 大理岩三轴压缩的塑性变形与能量特征分析[J]. 岩石力学与工程学报, 2008, 27(2): 273-280. (SU Cheng-dong, ZHANG Zhen-hua. Analysis of plastic deformation and energy property of marble under pseudo-triaxial compression[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(2): 273-280. (in Chinese))
[18]	HUA A Z, YOU M Q. Rock failure due to energy release during unloading and application to underground rock burst control[J]. Tunneling and Underground Space Technology, 2001, 16(3): 241-246.
