考虑不排水抗剪强度空间变异性的条形基础极限承载力随机分析

祁小辉; 李典庆; 周创兵; 方国光

doi:10.11779/CJGE201406015

考虑不排水抗剪强度空间变异性的条形基础极限承载力随机分析 English Version

祁小辉^{1, 2},
李典庆^1,2,,
周创兵^{1, 2},
方国光^{1, 2}

1. 武汉大学水资源与水电工程科学国家重点实验室,湖北武汉 430072; 2.武汉大学水工岩石力学教育部重点实验室,湖北武汉 430072

基金项目: 国家杰出青年科学基金项目（51225903）; 国家重点基础研究发展计划（973计划）项目（2011CB013506）; 国家自然科学基金项目（51329901）

详细信息

作者简介:
祁小辉(1989- ),男,博士研究生,主要从事岩土工程可靠度与风险分析方面的研究。E-mail：dianqing@whu.edu.cn。

通讯作者:
李典庆

中图分类号: TU471.12
计量
- 文章访问数: 409
- HTML全文浏览量: 3
- PDF下载量: 357
出版历程
- 收稿日期: 2013-10-16
- 发布日期: 2014-06-19

Stochastic analysis of ultimate bearing capacity of strip footing considering spatial variability of undrained shear strength

1. State Key Laboratory of Water Resources and Hydropower Engineering Science, Wuhan University, Wuhan 430072, China; 2. Key Laboratory of Rock Mechanics in Hydraulic Structural Engineering (Wuhan University), Ministry of Education, Wuhan 430072, China

摘要

摘要: 目前有关抗剪强度参数随深度变化对地基稳定性影响的研究还不深入。为此,提出了考虑土体不排水抗剪强度均值和标准差随深度变化的地基稳定性随机分析方法。建立了表征不排水抗剪强度空间变异性的不平稳随机场模型,采用Karhunen-Loeve（KL）展开离散随机场。探讨了土体不排水抗剪强度参数空间变异性对地基极限承载力的影响规律,并比较了不排水抗剪强度参数平稳和不平稳随机场模型对地基稳定的影响。以不排水黏性地基稳定随机分析问题为例验证了所提方法的有效性。结果表明：考虑不排水抗剪强度参数空间变异性时,地基极限承载力均值和标准差随相关距离的增大而增大,地基极限承载力对竖直向相关距离更为敏感。地基极限承载力均值随不排水抗剪强度变异系数的增加而减小,标准差随变异系数的增加而增加。不排水抗剪强度变异性对地基失效概率有明显的影响,安全系数较大时,不排水抗剪强度相关距离越小,地基失效概率越小。与不排水抗剪强度参数的不平稳随机场相比,不排水抗剪强度的平稳随机场模型会高估地基极限承载力的变异性,在相同的安全度水平下,当地基的安全系数较低时,平稳随机场模型会导致对地基失效概率的低估；当地基安全系数较高时,平稳随机场模型会导致对地基失效概率的高估。
- 地基稳定性 /
- 不排水抗剪强度 /
- 空间变异性 /
- 随机场 /
- KL展开 /
- 极限承载力
Abstract: The effect of the variation of shear strength parameters of soils with depth on the stability of footing has not been thoroughly studied. A stochastic method is proposed for bearing capacity analysis of strip footing considering the variation of the mean and standard deviation of undrained shear strength parameters with depth. A non-stationary random field model is established, and the random field is discretized by the Karhunen-Loeve (KL) expansion. The effect of spatial variability of the undrained shear strength parameters on the ultimate bearing capacity is investigated. The results of bearing capacity associated with stationary and non-stationary random field models are compared. An undrained clay foundation is presented to demonstrate the effectiveness of the proposed method. The results indicate that both the mean and standard deviation of bearing capacity increase with the increasing correlation length, and that the ultimate bearing capacity is more sensitive to the vertical correlation length than to the horizontal one. The mean of the ultimate bearing capacity decreases but the standard deviation increases as the coefficient of variance increases. The spatial variability of shear strength parameters of soils has a significant influence on the failure probability of foundation. When the factor of safety is large, the failure probability of foundation decreases with the decreasing correlation lengths. Compared with the non-stationary random field, stationary random field will highly overestimate the variation of the ultimate bearing capacity. When the factor of safety against shear failure is low, the stationary random field model will induce a lower probability of failure than the non-stationary random field model. On the contrary, when the factor of safety against shear failure is high, the stationary random field model will induce a higher probability of failure.
- foundation stability /
- undrained shear strength /
- spatial variability /
- random field /
- Karhunen-Loeve expansion /
- ultimate bearing capacity

HTML全文

参考文献(24)

[1]	刘润, 闫澍旺. 渤海湾地基土随机场特性及可靠度分析[J]. 岩土工程学报, 2004, 26(4): 464-467. (LIU Run, YAN Shu-wang. Random field model and reliability analysis of foundation soil in Bohai gulf[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(4): 464-467. (in Chinese))
[2]	朱红霞, 闫澍旺. 天津港地基土随机场特性及可靠度分析[J]. 岩石力学与工程学报, 2007, 26(增刊2): 3959-3965. (ZHU Hong-xia, YAN Shu-wang. Random field model and reliability analysis of foundation soil in Tianjin port[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(S2): 3959-3965. (in Chinese))
[3]	潘健, 周森. 非均质地基上条形基础沉降的随机有限元分析[J]. 岩土工程学报, 2010, 32(增刊2): 196-199. (PAN Jian, ZHOU Sen. Probabilistic analysis for settlement of strip footing on non-homogeneous soil[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(S2): 196-199. (in Chinese))
[4]	吴振君, 王水林, 汤华, 等. 一种新的边坡稳定性因素敏感性分析方法——可靠度分析方法[J]. 岩石力学与工程学报, 2010, 29(10): 2050-2055. (WU Zhen-jun, WANG Shui-lin, TANG Hua, et al. A new sensitivity analysis approach for slope stability——reliability analysis method[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(10): 2050-2055. (in Chinese))
[5]	张继周, 缪林昌. 基于随机场理论的地基概率沉降分析[J]. 岩土工程学报, 2010, 32(7): 1059-1064. (ZHANG Ji-zhou, MIAO Lin-chang. Probabilistic foundation settlement based on random field theory[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(7): 1059-1064. (in Chinese))
[6]	李典庆, 蒋水华, 周创兵. 基于非侵入式随机有限元法的地下洞室可靠度分析[J]. 岩土工程学报, 2012, 34(1): 123-129. (LI Dian-qing, JIANG Shui-hua, ZHOU Chuang-bing. Reliability analysis of underground rock caverns using non-intrusive stochastic finite element method[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(1): 123-129. (in Chinese))
[7]	李典庆, 蒋水华, 周创兵, 等. 考虑参数空间变异性的边坡可靠度分析非侵入式随机有限元法[J]. 岩土工程学报, 2013, 35(8): 1413-1422. (LI Dian-qing, JIANG Shui-hua, ZHOU Chuang-bing, et al. Reliability analysis of slopes considering spatial variability of soil parameters using non-intrusive stochastic finite element method[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(8): 1413-1422. (in Chinese))
[8]	祁小辉, 李典庆, 周创兵, 等. 考虑土体空间变异性的边坡最危险滑动面随机分析方法[J]. 岩土工程学报, 2013, 35(4): 745-753. (QI Xiao-hui, LI Dian-qing, ZHOU Chuang-bing, et al. Stochastic analysis method of critical slip surfaces in soil slopes considering spatial variability[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(4): 745-753. (in Chinese))
[9]	GRIFFITHS D V, FENTON G A, MANOHARAN N. Undrained bearing capacity of two-strip footings on spatially random soil[J]. International Journal of Geomechanics, 2006, 6(6): 421-427.
[10]	CHO S E, PARK H C. Effect of spatial variability of cross-correlated soil properties on bearing capacity of strip footing[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2010, 34(1): 1-26.
[11]	KASAMA K, WHITTLE A J. Bearing capacity of spatially random cohesive soil using numerical limit analyses[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2011, 137(11): 989-996.
[12]	ZHALEHJOO N, CHENARI RJ, POUYA KR. Evaluation of bearing capacity of shallow foundations using random field theory in comparison to classic methods[C]// Proceeding of Geo-Congress ASCE. Oakland: ASCE, 2012.
[13]	KULHAWY FH, MAYNE PW. Manual on estimating soil properties for foundation design [R]. Report No.: EL-6800. Palo Alto (CA): Electric Power Research Institute, 1990.
[14]	LUMB P. The variability of natural soils[J]. Canadian Geotechnical Journal, 1966, 3(2):74-97.
[15]	ASAOKA A, A-GRIVAS D. Spatial variability of the undrained strength of clays[J]. Journal of the Geotechnical Engineering Division, 1982, 108(5): 743-756.
[16]	PHOON K K, KULHAWY F H. Characterization of geotechnical variability[J]. Canadian Geotechnical Journal, 1999, 36(4): 612-624.
[17]	HICKS M A, SAMY K. Influence of heterogeneity on undrained clay slope stability[J]. Quarterly Journal of Engineering Geology and Hydrogeology, 2002, 35(1): 41-49.
[18]	LACASSE S, NADIM F. Uncertainties in characterizing soil properties[C]// Proceeding of Uncertainty 1996. Madison, Wisconsin: ASCE, 1996.
[19]	SUDRET B, KIUREGHIAN AD. Stochastic finite element methods and reliability: a state-of-the-art report[R]. Report No.: UCB/SEMM-2000/08. Berkeley: Department of Civil and Environmental Engineering, University of California, Berkeley, 2000.
[20]	WU S H, OU C Y, CHING J, et al. Reliability-based design for basal heave stability of deep excavations in spatially varying soils[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2012, 138(5): 594-603.
[21]	BAECHER G B, CHRISTIAN J T. Reliability and statistics in geotechnical engineering[M]. London: John Wiley & Sons Ltd, 2003.
[22]	EL-RAMLY H, MORGENSTERN N R, CRUDEN D M. Probabilistic stability analysis of a tailings dyke on presheared clay shale[J]. Canadian Geotechnical Journal, 2003, 40(1): 192-208.
[23]	唐小松, 李典庆, 周创兵, 等. 基于Copula函数的抗剪强度参数间相关性模拟及边坡可靠度分析[J]. 岩土工程学报, 2012, 34(12): 2284-2291. (TANG Xiao-song, LI Dian-qing, ZHOU Chuang-bing, et al. Modeling dependence between shear strength parameters using Copulas and its effect on slope reliability[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(12): 2284-2291. (in Chinese))
[24]	唐小松, 李典庆, 周创兵, 等. 不完备概率信息条件下边坡可靠度分析方法[J]. 岩土工程学报, 2013, 35(6): 1027-1034. (TANG Xiao-song, LI Dian-qing, ZHOU Chuang-bing, et al. Reliability analysis of slopes with incomplete probability information[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1027-1034. (in Chinese))
